® Cleaning System. We appreciate your business and look forward to serving you in the future. As with all SpeedClean products, you can be assured that the finest quality components and workmanship have gone into this unit. Please take a few minutes to read the following Operating and Maintenance Instructions.
• Do not use the unit if it does not operate properly or has been damaged. Do not try to service the unit yourself - call SpeedClean for assistance. Service must be performed only by qualified repair personnel. Service performed by unqualified personnel could result in a risk of injury and voids the warranty.
Assembly CJ-125 The CoilJet® CJ-125 is shipped fully assembled. However, the battery leads need to be connected before first use. Open the battery door, remove the battery, and connect the leads – red wire to the positive terminal and black wire to the negative terminal. NOTE: The battery should be fully charged before first use.
Changing the Battery 1. The battery can be quickly removed from the unit, allowing the insertion of a fresh battery. Spare batteries and chargers are available – contact your local distributor or SpeedClean. 2. To replace the battery: a. Turn power switch off.
Chemical Dilution Ratios Turn Chemical Valve counter-clockwise to open, clockwise to close. Turn Open 30:1 Turns Open 20:1 Turns Open 10:1 Turns Open Fully Open WARNINGS: • The motor is equipped with an automatic shut-off that disconnects power when the spray gun trigger is released to maximize battery life.
CJ-125 Technical Data SPECIFICATIONS CJ-125 Motor Power 0.2 HP Input Power 15 amps, 12V, DC rechargeable VRLA battery Recharge Power Standard: 0.3 amps, 115/230 V, 50/60 Hz AC Water Requirements On-Board Output Water Pressure 125 PSI Output Water Flow 0.7 GPM Pump Positive displacement diaphragm Water Tank...
Si desea información sobre la garantía o reparaciones, no se ponga en contacto con el centro donde lo adquirió. Llame directamente a SpeedClean al número (888) 700-3540. Instrucciones importantes...
Page 11
• No utilice el dispositivo si no funciona correctamente o si ha resultado dañado. No intente repararlo usted mismo: acuda a SpeedClean. Las reparaciones deben ser efectuadas únicamente por personal cualificado. Una reparación llevada a cabo por una persona no cualificada entraña riesgos de lesiones y anula la garantía.
Montaje CJ-125 El sistema CoilJet CJ-125 se envía completamente montado. Aun así, será necesario conectar las tomas de alimentación de la batería antes de la primera puesta en marcha. Abra la puerta de la batería, extraiga la batería y conecte las tomas: el cable rojo al terminal positivo;...
Page 13
*No se muestran: CJ2-24 Cargador de batería CJ2-06-S Conjunto de bomba de motor CJ2-07 Válvula pequeña de verificación CJ2-07-1 Válvula grande CJ2-17 Fusible de 15 amperios Comunes los Accesorios Opcionales CJ125-KIT-SB Kit de batería y cargador 8944 Adaptador de vehículo, para cargador de batería 90º...
1. La batería se puede extraer del dispositivo rápidamente, permitiendo la inserción de una nueva. Hay baterías y cargadores de repuesto disponibles. Comuníquese con SpeedClean. 2. Para reemplazar la batería: a. Coloque el interruptor en la posición de apagado (OFF).
Funcionamiento habitual del limpiado de serpentines 1. Rellene los tanques (de agua y productos químicos). Antes de cebar la bomba, compruebe que la válvula de productos químicos está completamente cerrada y retire las boquillas que hubiera en la pistola rociadora. 2.
Generalidades relativas al CJ-125 mantenimiento y almacenamiento 1. Cuando haya terminado de utilizar el dispositivo, haga pasar agua limpia por la bomba. 2. Proteja el dispositivo frente a temperaturas de congelación. No lo guarde al aire libre. 3. El dispositivo se podrá guardar a temperaturas superiores a las de congelado durante intervalos cortos (de menos de 1 semana) con líquidos en los tanques.
CJ-125 Solución de problemas CJ-125 PROBLEMA CAUSA PROBABLE SOLUCIÓN Presión • Boquilla desgastada • Reemplazar boquilla irregular o • Boquilla atascada • Limpiar orificio de boquilla errática • Bajo nivel de agua/producto químico • Añadir agua o producto • Aire succionado en el sistema •...
Page 18
SpeedyFoam ® CoilJet Condenser Mini-Split ® Needle™ ® SpeedClean is a registered trademark of Crossford International. SpeedClean reserves the right to improve products; contact the P/N : M NL- C J125 1118 factory for the latest configuration and uses.
