VANTAGE USER MANUAL

Warnings & Notifications:

This system is to be powered ONLY with the power supply provided.

The rechargeable batteries in the Vantage Harness and Zin Tool are not user replaceable.

The Vantage Harness and ZIN uses batteries that may need charged before use.

Connect the detachable power supply cord to the wall power outlet.

Connect the attached power supply cord to the rear of the sensor at the location marked DC Power In.

Ensure that your computer is connected to the Internet before plugging in the USB Dongle for the first time.

Plug the USB wireless device into your computer USB port.

Connect the black power supply cord to the wall power outlet.

Connect the black/red power supply cord with circular connector to the circular port on the side of the wireless harness or

Zin body.

Windows Operating System (Windows 7, Vista, or XP SP3)

Running Windows on a Mac via Fusion or Parallels is possible, but may yield issues when attempting to use the Retül

software version 5 video functionality due to file-saving speeds.

3 x USB ports for communication with Retül, webcam (optional accessory), and Powerbeam trainer (optional accessory)

Supply Input Voltage: 100-240 V ~

Supply Input Amperage: 0.5-0.3 A

Supply Input Frequency: 50-60 Hz

Supply Ouput Characteristics: 15W Max, 12V DC, 1.25A

Operating Temperature: 0° C to 60° C

Operating Relative Humidity: 5% to 95% non-condensing

Storage Temperature: 0° C to 60° C

Table of Contents

Need help?

Do you have a question about the Vantage and is the answer not in the manual?

Page 1 Warnings & Notifications: This system is to be powered ONLY with the power supply provided. The rechargeable batteries in the Vantage Harness and Zin Tool are not user replaceable. The Vantage Harness and ZIN uses batteries that may need charged before use.
Page 2 Primary Operation Section: Set up the Vantage Sensor on the tripod provided and position it 2 meters from the rider or bicycle to be measured. Make sure all direct sunlight is shielded from the front of the Vantage Sensor and that no other bright lights (indoor or outdoor) are in direct view of the front of the Vantage Sensor.
Page 3 This equipment is for use by Retül customers and clients only for the Retül Vantage System and must not be incorporated into any other device or system. This device may not be sold separately to the general public. FCC approval of this device only covers the original configuration of this device as supplied.
Page 4 47 C.F.R. Sec.15.105(b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
