- Page 1 RTDS3 energy saving controls Product Guide Remote Time Delay Switch 3-wire version today, tomorrow and in the future mselectronics.co.uk Issue 1.0...
-
Page 2: Product Overview
Product Overview The RTDS3 Remote Time Delay Switch provides timed switching for lighting, heating, air conditioning and ventilation equipment, to be used with a separate switch or interfaced to a control system such as a building management system (BMS). Housed behind a... -
Page 3: Electrical Requirements
Electrical Requirements Before attempting to install the unit, ensure that the intended load and wiring arrangement comply with the following requirements. Figure 2 shows a typical wiring example. • 3-wire (live/neutral + volt-free switch) connection: The unit requires a permanent live/neutral connection, and as such is not suitable for replacing an existing light switch with no neutral conductor at the switch location. - Page 4 • Relays and other switches: Use 2-core mains-rated cable and connect to the R+ and R- terminals only (polarity does not matter); do not use the V+ terminal. Figure 3 Typical wiring schematic using two TDS-S slave units Figure 4 Typical ceiling rose plan using two TDS-S slave units RTDS3...
-
Page 5: Additional Guidelines
Installation All electrical installation and maintenance must be carried out by a competent person. If in doubt, consult a qualified electrician. Any new wiring must be carried out by qualified personnel in accordance with the current edition of the IET Wiring Regulations (BS7671). Ensure the electrical supply is isolated before making any connections or adjustments. - Page 6 Operation The diagram below illustrates the sequence of operation for the unit. Sequence of Operation RTDS3...
-
Page 7: Fault Finding
Fault Finding Ensure the electrical supply to the unit is isolated before making any adjustments. Load will not switch on a) Unit is not powered • Ensure the unit is correctly connected to an active mains supply. b) Load is not connected correctly •... - Page 8 Product Warranty MS Electronics guarantees all their products against manufacturing defects for 5 years from the purchase date. If your product is found to be faulty, MS Electronics will, at their discretion, repair or replace the product free of charge.
