HP Pro Scanner Output Tray User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HP Pro Scanner Output Tray
User Guide

Advertisement

Table of Contents
loading

Summary of Contents for HP Pro Scanner Output Tray

  • Page 1 HP Pro Scanner Output Tray User Guide...
  • Page 2 © Copyright 2017 HP Development Company, The information contained herein is subject to L.P. change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.

  • Page 3: Table Of Contents

    Tips for a successful batch scan ............................. 7 5 Fold the tray for storage ..................................9 6 HP Limited Warranty Statement ................................11 A. Extent of HP Limited Warranty ............................11 B. Limitations of warranty ..............................13 C. Limitations of liability ................................ 13 D.
  • Page 4 ENWW...

  • Page 5: Introduction

    Introduction This accessory for the HP Pro Scanner is designed to stack sheets of paper of the same size scanned as a batch. It has been designed for optimal performance with plain and bond papers (75–80 g/m²) with little tendency to curl.

  • Page 6: Required Space

    Required space The output tray has approximately the following dimensions: 1150 mm long × 1190 mm wide × 1200 mm high (45.3 × 46.9 × 47.2 in). You are recommended to allow some extra space at the left and front of the tray for normal actions while it is in use.

  • Page 7: Items Included In The Box

    Items included in the box Upper tray Paper stoppers (2) Central tray Lower tray Wheels Angle selector touch zone Angle selector Angle knob Height adjusters (2) Main structure Antistatic brushes (SD version only) Safety lock ENWW...

  • Page 8: Stopper Adjustment

    Preinstall the stoppers in the central or lower tray area, depending on the paper size. HP recommends that the edge of the paper should be 5–10 cm outside the edge of the stopper. Put the paper on the tray, ensuring that the trailing edge is above (or at least not below) the upper rod of the fall tray.
  • Page 9 Fix the two stoppers in place by rotating the handle, so that the paper stops with its trailing edge in the indicated position. Remove the sheet of paper. Adjust the angle of the tray if necessary (see Tray angle adjustment on page Start scanning.

  • Page 10: Tray Angle Adjustment

    Tray angle adjustment You may be able to improve the sliding and stacking of the originals on the output tray by adjusting its angle of slope. The ideal angle could vary with paper type, paper size, and ambient conditions. The objective is to adjust the angle of the tray so that paper can fall freely from the scanner. Hold the tray with your hand in the touch zone.

  • Page 11: Tips For A Successful Batch Scan

    Move the tray to the desired angle by pulling it up or down. Release the knob when the tray is at the desired angle. Tips for a successful batch scan The angle of the output tray should be adjusted so that the scanned sheets of paper fall freely from the scanner to the tray without jamming.
  • Page 12 When a sheet falls into the tray, it should hit the stopper gently, to avoid paper damage and future paper jams during the scan session. If a sheet does not lie flat on the tray, the angle of the tray should be decreased, increasing the height of the end of the tray.

  • Page 13: Fold The Tray For Storage

    Fold the tray for storage You can fold the output tray for storage so that it takes up less space: Set the tray to a steep angle (see Tray angle adjustment on page Fold the lower tray upwards over the central tray. Unlock the upper tray, and fold it downwards over the central tray.
  • Page 14 Store the tray wherever convenient. For example, it can be stored under the scanner. Chapter 5 Fold the tray for storage ENWW...

  • Page 15: Hp Limited Warranty Statement

    If, during the diagnosis period, HP identifies that the repair can be accomplished by the use of a CSR part, HP will ship that part directly to you for replacement. There are two categories of CSR parts: ENWW A.
  • Page 16 HP specifies in the materials shipped with a replacement CSR part whether a defective part must be returned to HP. In cases where it is required to return the defective part to HP, you must ship the defective part back to HP within a defined period of time, normally five (5) business days. The defective part must be returned with the associated documentation in the provided shipping material.

  • Page 17: Limitations Of Warranty

    B. Limitations of warranty TO THE EXTENT ALLOWED BY LOCAL LAW, NEITHER HP NOR ITS THIRD PARTY SUPPLIERS MAKE ANY OTHER WARRANTY OR CONDITION OF ANY KIND, WHETHER EXPRESS OR IMPLIED, AND SPECIFICALLY DISCLAIM THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY, SATISFACTORY QUALITY, AND FITNESS FOR A PARTICULAR PURPOSE.
