Summary of Contents for HY-LINE CLUX-42E
- Page 1 CLUX-42E 4x2 HDMI v1.3 Distributor with Switcher Operation Manual CLUX-42E...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Introduction................2. Features..................3. Operation Controls and Functions.......... 3.1 Front Panel................3.2 Rear Panel................3.3 Remote Control………………………...……………………... 3.4 RS-232 Control Protocol…………………………………...…. 3.5 RS-232 command…………………………………...…….….. 4. Specifications................ -
Page 3: Introduction
1. Introduction This is a high performance HDMI v1.3 Distributor with Switcher. It allows your various HDMI source to share two HDTV display. Simply press one button to select your desired HDMI source to display on the HDTV. Each product in this series is compatible to HDMI v1.3 specifications, a cutting-age technology which defines to transfer Deep Color (10-bit and 12-bit) video and new lossless compressed (LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, with a high bandwidth up to... -
Page 4: Operation Controls And Functions
3. Operation Controls and Functions 3.1 Front Panel INPUT POWER CLUX-42E v1.3 Dual Output HDMI v1.3 Switcher SIGNAL ENHANCE Remote Control Sensor. HDMI input Select/Indicator: Press the "Input" button sequentially to switch to your desired input (HDMI 1 to HDMI 4), the LED will illuminate to indicate which input source is selected. -
Page 5: Rear Panel
3.2 Rear Panel RS-232 DC 5V OUTPUT 2 OUTPUT 1 INPUT 4 INPUT 3 INPUT 2 INPUT 1 RS232: 9-pin D-Sub connector for connecting to your PC or other control console for remote control. HDMI Outputs 1 and 2: Connect each of the output ports to the HDMI/DVI display. -
Page 6: Remote Control
3.3. Remote Control 1. Power: Press the button to turn on/off the unit. 2. Direct input selector: Press 1, 2, 3 or 4 to select the desired input source. 3.4 RS-232 Control Protocol The connection between splitter and remote controller with RS-232 modem cable. ns definition of modem cable Remote Controller Splitter... -
Page 7: Rs-232 Command
3.5 RS-232 command RS-232 command Operation Select power OFF Select power ON Select port 1 Select port 2 Select port 3 Select port 4 Select Signal Enhance OFF Select Signal Enhance ON 4. Specifications Input port 4x HDMI female ports Output port 2 x HDMI female ports Power Supply... - Page 8 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20080321 MPM-CLUX42E...
