IMI SENSORS 699A07 Installation And Operating Manual

Portable vibration calibrator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model 699A07
PORTABLE VIBRATION CALIBRATOR
Installation and Operating Manual
For assistance with the operation of this product,
contact the PCB Piezotronics, Inc.
Toll-free: 800-959-4464
24-hour SensorLine: 716-684-0001
Fax: 716-684-3823
E-mail: imi@pcb.com
Web: www.imi-sensors.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 699A07 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for IMI SENSORS 699A07

  • Page 1 Model 699A07 PORTABLE VIBRATION CALIBRATOR Installation and Operating Manual For assistance with the operation of this product, contact the PCB Piezotronics, Inc. Toll-free: 800-959-4464 24-hour SensorLine: 716-684-0001 Fax: 716-684-3823 E-mail: imi@pcb.com Web: www.imi-sensors.com...
  • Page 2 Service, Repair, and Return Policies and Instructions The information contained in this document supersedes all similar information that may be found elsewhere in this manual. also good practice to recalibrate after Service – Due to the sophisticated exposure to any severe temperature nature of the sensors and associated extreme, shock,...
  • Page 3 list(s) accompanying the shipment. A complete list of distributors and offices detailed account of the nature of the found www.pcb.com. problem(s) being experienced with the Customers within the United States may equipment should also be included contact their local sales representative inside the package(s) containing any factory customer...
  • Page 4 PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 汞 镉 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 铅 (Pb) (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接...
  • Page 5 Component Name Hazardous Substances Lead Mercury Cadmium Chromium VI Polybrominated Polybrominated (Pb) (Hg) (Cd) Compounds Biphenyls Diphenyl (Cr(VI)) (PBB) Ethers (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.
  • Page 6 User Manual Portable Vibration Calibrator 699A07 69142 REV. A...
  • Page 7 IMI Sensors at 800-959-4464 in the U.S.A. or 716-684-0003, 9 a.m. to 5 p.m. EST. If it is more convenient, fax questions or comments to IMI Sensors at 716- 684-3823 or email our sales staff at imi@pcb.com.

  • Page 8: Table Of Contents

    IMI Sensors: A PCB Piezotronics Div 699A07 User Manual Table of Contents INTRODUCTION ..........................4 Welcome ..........................4 Customer Support ......................4 Cautionary Notes ........................ 4 Supplied Accesories ......................5 Optional Fixturing and Accessories ..................6 Replacement Accessories ....................6 699A07 OPERATION GUIDE ......................

  • Page 9: Introduction

    The 699A07 is designed to provide long-term reliable performance over the frequency range of 5 Hz to 10 kHz. The 699A07 can be used for a variety of applications that include: •...

  • Page 10: Supplied Accesories

    IMI Sensors: A PCB Piezotronics Div 699A07 User Manual • The 699A07 is designed for field test applications but care must be taken to maintain the integrity of the mounting platform assembly. • Hearing protection recommended when operating the 699A07 for an extended amount of time.

  • Page 11: Optional Fixturing And Accessories

    (for adhesive, magnetic and custom thread patterns). Replacement Accessories Accessory Description 600A25 18 Volt, 1 amp power supply/charger for 699A07 Portable Vibration Calibrator, universal 100-240 V, 50/60 Hz. 600A26 Replacement battery for 699A07 Series Portable Vibration Calibrators. MAN-0192 rev A...

  • Page 12: 699A07 Operation Guide

    Selecting Input Mode The 699A07 can accept ICP® as well as AC voltage and AC current output sensors. Press and hold the AMPLITUDE dial to select between ICP®, Voltage Mode or Modulated Current mode. Modulated Current mode is only available if the firmware option is ordered, otherwise user will not see this mode as an option.
  • Page 13 IMI Sensors: A PCB Piezotronics Div 699A07 User Manual Select the correct Amplitude Units for your test by pressing and releasing the AMPLITUDE dial. The following options are available: Acceleration Velocity Displacement g’s pk in/s pk mils p-p g’s RMS in/s RMS µm p-p...

  • Page 14: Report Generation Workbook

    The most current factory calibration date or the calibration due date is displayed on the LCD screen during the 699A07 boot up sequence. The default due date is set for 12 months after the last factory calibration, but the calibration interval can be user defined to be anywhere from 1 to 72 months, or set up to never expire.
  • Page 15 1. Clicking on Import Data from File button prompts the user to select and import a .csv calibration data file previously created by the 699A07 2. Once data is loaded into the table, click View Certificate to see and print a...

  • Page 16: Additional Features

    IMI Sensors: A PCB Piezotronics Div 699A07 User Manual • Route Creator – If firmware option 600A31 is ordered, this tab can be used to create semi-automated tests with instant pass/fail notification for almost any vibration sensor. See “Calibration Route” for more information.
  • Page 17 The “Amplitude Unit Screen” shows all 10 available amplitude scales on model 699A07 Portable Vibration Calibrator. Use the FREQUENCY dial to highlight each scale and press the dial to toggle the scale on or off. A filled circle next to the scale indicates it is active.

  • Page 18: Calibration Route

    (Model 600A31). If ordered at the same time as Model 699A07, the firmware will be activated in the factory prior to shipment. If ordered after the fact, IMI Sensors will provide an activation code that the user can enter in order to activate the firmware in the field.
  • Page 19 The 699A07 can only simulate vibration in CPM values that are multiples of 60. I.e. 1800 CPM, 3600 CPM, 4200 CPM, etc. If a value is entered that is not a multiple of 60, the 699A07 will adjust down to the nearest CPM value that is a multiple of 60.
  • Page 20 If the sensor under test’s sensitivity is above 105 mV/g or below 95 mV/g the 699A07 will alert the user that test point failed. • The file name will be CaseAccel_Route.pvc, when uploading to the 699A07 one would choose this file. •...
  • Page 21 The sensor type is voltage. This means ICP® power is turned off. The proximity probe is being powered by its probe driver. To run this test the technician must connect the output of the probe drive to “Test Sensor In” on the 699A07. •...
  • Page 22 The calibration test has been created and saved to the USB. It has also been uploaded and activated in the 699A07 using the previous section. The following instructions detail usage of the 699A07 while the pre-programmed test is active. To use the 699A07 in manual mode again the calibration route must be de-activated (see next section).

  • Page 23: Definition Of Frequency Units

    Peak (pk) bases calculations on the highest value of the signal generated during testing. For a sinusoidal wave (as is produced by the 699A07), the peak value is calculated by RMS* 2. The 699A07 does not measure a true peak value, but instead estimates the value mathematically based upon the RMS value.

  • Page 24: Mounting Basics

    Input / Output EXTERNAL SOURCE IN Input BNC It is possible to drive the 699A07 by using an external signal source or a function generator. First, connect a signal source to the EXTERNAL SOURCE IN BNC Input located on the top left corner of the unit. To enable the EXTERNAL SOURCE IN input, press the FREQUENCY dial to enter the “Calibration Options”...
  • Page 25 The diagnostic screen can be displayed by holding down the file button for approximately 2 seconds. This screen displays information about the operation of the 699A07. The information found in this menu is displayed in real time: Reference ICP Bias Voltage Test Sensor Bias Voltage Test Sensor Type: Voltage, ICP®...

  • Page 26: Theory Of Operation

    The reference accelerometer is a PCB Piezotronics ICP® quartz shear sensor, integrated into the mounting platform. A calibration “standard” maintained by IMI is used to calibrate the 699A07 as a complete system and provides NIST traceability. Traceability information can be viewed under the tools menu as described in the previous section.
  • Page 27 IMI Sensors: A PCB Piezotronics Div 699A07 User Manual The frequency of the shaker drive signal is controlled by the front panel FREQUENCY dial. The amplitude of the shaker drive signal is controlled through a feedback loop, to maintain the stability of the actual motion. Adjusting the front panel AMPLITUDE dial adjusts the target vibration amplitude.

  • Page 28: Battery And Charger

    Under mild operating conditions (lower mass transducers at lower test amplitudes), a fully charged battery will allow the 699A07 to operate for up to 18 hours. The charge life of the battery depends on both the length of use and the amount of power (dependent upon payload, frequency and amplitude) required for a particular test.

  • Page 29: Specifications And Performance

    IMI Sensors: A PCB Piezotronics Div 699A07 User Manual Specifications and Performance General Frequency Range (for acceleration) 5 Hz – 10 kHz 300 CPM - 600k CPM (operating, 100 gram payload) Maximum Amplitude 20 g pk 196 m/s (100 Hz, no payload)

  • Page 30: Power Requirements

    The chart below shows the maximum vibration levels as a function of both frequency and payloads. Payloads exceeding 800 gram should not be tested on the Model 699A07. Excessive loads may result in damage to the moving coil and flexure. Care must be...
  • Page 31 This is a safeguard against side loading the shaker. In some cases of extremely heavy shaker payloads at high vibration levels (depending on the frequency), the 699A07 may exhibit both frequency and amplitude instabilities. In this case, please reduce the excitation amplitude and/or the payload to eliminate the effect.
  • Page 32 IMI Sensors: A PCB Piezotronics Div 699A07 User Manual MAN-0192 rev A Page 27 of 39 800-959-4464 69142 REV. A...

  • Page 33: Recommended Practices

    699A07 should be evaluated further to determine the root cause of the discrepancy. Field repair of the 699A07 is not possible, so if performance of the 699A07 is out of specification, it should be sent back to IMI Sensors for evaluation, repair and recalibration.

  • Page 34: Typical Accelerometer & Velocity Sensor Checkout

    • 10, 20, 50, 61.44, 100, 200, 500, 1000, 2000, 5000 and 10000 Hz Model 699A07 is not capable of 61.44 Hz, only integer numbers such as 61 or 62. For accelerometers the recommended amplitudes in API 670 are: •...

  • Page 35: Calibrating Charge-Mode Accelerometers

    Calibrating Charge-Mode Accelerometers The output of charge-mode accelerometers is in pico-coulombs per g (pC/g). The “Test Sensor Input” of Model 699A07 can only read AC voltage or current. Charge- mode accelerometers can be tested with the Portable Vibration Calibrator if their signal is first conditioned to mV units using an single-ended or differential charge amplifier.

  • Page 36: Non-Contact Displacement Sensor Test Setup

    IMI Sensors: A PCB Piezotronics Div 699A07 User Manual 600A22 (or 600A23) proximity probe adaptor kit, shown on the next page. The following sections detail the procedure for performing linearity and frequency response checks on a non-contact displacement sensor. Non-Contact Displacement Sensor Test Setup Note: The calculations in these instructions are based on a 200 mV/mil eddy current proximity probe to provide an example based on nominal sensitivity.
  • Page 37 IMI Sensors: A PCB Piezotronics Div 699A07 User Manual 1. Remove the (2) 10-32 pan head screws on the user panel of the portable vibration calibrator (white arrows in picture below). 2. Install the AISI 4140 steel target into the shaker on the mounting platform.
  • Page 38 IMI Sensors: A PCB Piezotronics Div 699A07 User Manual 3. Install the non-contact displacement sensor in the microarm after stringing the probe through the probe bar as shown in the picture below. Please note: An 8 mm probe tip non-contact displacement sensor with 3/8-24 threaded case will mount directly while a 5 probe tip mm non-contact displacement sensor with a ¼-28...
  • Page 39 IMI Sensors: A PCB Piezotronics Div 699A07 User Manual 5. Finalize the assembly by attaching probe bar, microarm, non-contact displacement sensor, and micrometer on top of the spacers and secure with provided panel screws. MAN-0192 rev A Page 34 of 39...

  • Page 40: Proximity Probe Dynamic Linearity Calibration & Confirmation Of Vibration Alarms

    When complete, rotate FILE dial to display END RECORD then press FILE dial. Note: if “Bias Fault” appears at top left on display the 699A07 is supplying ICP power to the proximity probe. This will not damage the probe. But ICP power must be turned off by pressing and holding the AMPLITUDE dial.

  • Page 41: Troubleshooting The Proximity Probe System

    USB drive. Each time tests are exported from 699A07 to USB they are saved within a folder representing the date and time they were exported. Once data is imported press View Certificate. Enter any desired notes or comments into the report, save and/or print.

  • Page 42: Testing 4-20 Ma Vibration Transmitters

    Remove the vibration transmitter from the machine and mount to the shaker table. Users may need a mounting adaptor such as ¼” NPT available from IMI Sensors. The shaker table should be brought to the sensor.
  • Page 43 10. The starting point should be 0.0, record this in cell H14. Read the mA value on the multi- meter and record in cell I14. 11. For first amplitude test point, read vibration value from display of 699A07, record in column H then read mA value from multi-meter and record in column I. Repeat until test is complete.

  • Page 44: Maintenance

    IMI Sensors: A PCB Piezotronics Div 699A07 User Manual Maintenance Recalibration and certification is recommended on an annual basis. Service of internal parts should only be performed by factory personnel. If the unit is removed from the case, the NIST calibration is void. Recertification can only performed after re-assembly.
  • Page 45 Model Number Revision: A PORTABLE VIBRATION CALIBRATOR 699A07 ECN #: 48972 Performance ENGLISH OPTIONAL VERSIONS Maximum Load 800 gm 800 gm Optional versions have identical specifications and accessories as listed for the standard model except where noted below. More than one option may be used.
