FHE 300

IMFHE300 V.3

Table of Contents

Need help?

Do you have a question about the FHE300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Essilor FHE300

Page 1 FHE 300 IMFHE300 V.3...
Page 2 Instructions and maintenance manual Ref. man FHE300 Rev. 11/201 4 TECHNICAL DATA AND FEATURES FHE300 Machine Hot air Heaters for frames Reference A200S 315 mm Maximum length (X) 190 mm Maximum width (Y) 215 mm Maximum height (Z) 2.6 kg Machine weight 130 - 175 °C...
Page 3 Instructions and maintenance manual Ref. man FHE300 Rev. 11/201 4 RESIDUAL DANGERS AND RISKS During operation, the hot air conveyor generates heat and can cause a risk of burns. Warning labels are fitted on the machine. The user is responsible for periodically checking their integrity and, if necessary, for replacing the damaged labels with identical ones, by contacting the manufacturer’s Help...
Page 4 Instructions and maintenance manual Ref. man FHE300 Rev. 11/2014 INSTRUCTIONS FOR THE USER CONNECTION AND OPERATION Before connecting the device, check that the line voltage corresponds to that indicated on the label on the machine and that the main switch is set to “0” (zero).
Page 5 In the event of the machine being used incorrectly, or as a result of damage through operations not listed in the manual, Essilor will not accept any liability. Any servicing and special maintenance operations must be carried out with the device switched off and the power supply removed by disconnecting the power cable.
Page 6 Instructions and maintenance manual Ref. man FHE300 Rev. 11/2014 TROUBLE SHOOTING The machine is not heating or does not blow hot Problem: Possible cause ACTION Replace the existing fuse inside the Spent fuse plug(*) Resistance and/or Contact the Help desk broken motor (*)To check the fuse, turn the main switch to “0”...
Page 7 Instructions and maintenance manual Ref. man FHE300 Rev. 11/2014 REFERENCING GUIDELINES AND APPLIED STANDARDS Mandatory directives Reference Part Directive the UE Low voltage(DBT) n°2014/35/UE Directive the UE Electromagnetic compatibility (EMC) n°2014/30/UE Directive the UE Restriction of the use of certain hazardous substances in electrical n°2011/65/UE...
