RG-PBOX Series Power Adapter

Hardware Installation and Reference Guide V1.01

Table of Contents

Need help?

Do you have a question about the RG-PBOX Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Ruijie Networks RG-PBOX Series

Page 1 RG-PBOX Series Power Adapter Hardware Installation and Reference Guide V1.01...
Page 2 This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.
Page 3: Obtaining Technical Assistance
It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts. Obtaining Technical Assistance  Ruijie Networks Website: http://www.ruijienetworks.com/  Service Email: service_rj@ruijienetworks.com ...
Page 4: Product Overview
Product Overview 1 Product Overview The PoE-capable RG-PBOX series power adapter, teaming up with RG-S2910-H series switches, is developed to meet the power supply requirement of the terminal device. Currently, there are two available models with up to 60W loading capacity: RG-PBOX-DC12 and RG-PBOX-AC24.
Page 5: Product Appearance
Hardware Installation and Reference Guide Product Overview Product Appearance The RG-PBOX-DC12 power adapter provides two 10M/100M/1000M Ethernet ports and one 12V DC power port Figure 1-1 Appearance of RG-PBOX-DC12 Power Adapter Front Panel Figure 1-2 Front Panel of RG-PBOX-DC12 Power Adapter ①...
Page 6 Hardware Installation and Reference Guide Product Overview ① Grounding connector (screw hole) Note Power Supply The RG-PBOX-DC12 power adapter adopts PoE power supply input. Input voltage range: 43-57V DC Output voltage: 12VDC Rated current: 5A Rated output power: 60W Heat Dissipation System The RG-PBOX-DC12 power adapter adopts fanless design.
Page 7 Hardware Installation and Reference Guide Product Overview Fanless Temperature Alarm Not supported Protection Level IP40 EMI Standards GB 9254－2008,FCC Part 15, CISPR (EN55022) class A, EMS Standards IEC/EN 61000-4-2 ESD Safety Standards contact discharge air discharge 15kV IEC/EN 61000-4-4 EFT communication line IEC/EN 61000-4-5 Surge power cord, cord/cord...
Page 8 Hardware Installation and Reference Guide Product Overview ① 24V AC Power Output port ⑤ Power and Data Input port (PoE) Note ② 24V AC Power Out indicator ③ PoE Power In indicator ④ Data Output port Back Panel Figure 1-6 Back Panel of RG-PBOX-AC24 Power Adapter ①...
Page 9 Hardware Installation and Reference Guide Product Overview The RG-PBOX-DC12 power adapter adopts fanless design. For airflow for proper ventilation, the chassis should be mounted in a place with sufficient space(10cm at least) for air circulation. Identification Status Meaning on the panel Abnormal PoE or no power supply Power-in Solid green...
Page 10: Preparation Before Installation
Hardware Installation and Reference Guide Preparation before Installation 2 Preparation before Installation 2.1 Safety Suggestions To prevent device damage and bodily injury, please read carefully the safety recommendations described in this chapter. The recommendations do not cover all possible hazardous situations. 2.1.1 General Suggestions ...
Page 11: Installation Site Requirements
Hardware Installation and Reference Guide Preparation before Installation Although much has been done in RG-PBOX to prevent static electricity, great damage may be caused to the circuitry and equipment when the static electricity exceeds a certain limit. In the communication network of the RG-PBOX, electrostatic induction may come from the following sources: External electric field produced by the high-voltage supply cable, lightning, etc;...
Page 12: Cleanness Requirements
Hardware Installation and Reference Guide Preparation before Installation 2.2.3 Cleanness Requirements Dust poses the top threat to the running of the equipment. The indoor dust falling on the equipment may be adhered by the static electricity, causing bad contact of the metallic joint. Such electrostatic adherence may occur more easily when the relative humidity is low, not only affecting the use life of the equipment, but also causing communication faults.
Page 13: Emi Consideration
Hardware Installation and Reference Guide Preparation before Installation 2.2.7 EMI Consideration Various interference sources, from either outside or inside the equipment or application system, affect the system in the conductive ways such as capacitive coupling, inductive coupling, and electromagnetic radiation. There are two types of electromagnetic interferences: radiated interference and conducted interference, depending on the type of the propagation path.
Page 14: Product Installation
The installation location meets the temperature and humidity requirements of the equipment.  The related network cables have already been deployed at the installation location.  The selected power supply meets the system power. 3.3 Installing RG-PBOX Series Power Adapter Cautions...
Page 15: Wall Mounting
Hardware Installation and Reference Guide Product Installation During installation, please note the following points:  Ensure the wall or ceiling where the power adapter to be installed is dry enough and watertight.  Keep the power adapter away from heat sources, electromagnetic radiation areas, power lines, inflammables and explosives.
Page 16 Hardware Installation and Reference Guide Product Installation Connect network cable 1. Connect one end of the network cable to the "Data Out" port of the RG-PBOX power adapter and the other end to a terminal device such as a camera. Figure 3-3 Connect network Cable 1 Connect the power cable.
Page 17 Hardware Installation and Reference Guide Product Installation Power cable of a camera Power port of the power adapter Figure 3-5 Connect the Power Cable Fasten with the screw using a screwdriver Connect power cable 2. Connect the uplink (connected to any HPoE port) network cable to the "Data&Power in" port of the power adapter. Figure 3-6 Connect Power Cable 2 Connect network cable 2...
Page 18 Hardware Installation and Reference Guide Product Installation Connect the grounding cable. Fasten one end of the grounding cable to the screw hole on the back panel of the power adapter using screws, and ensure proper grounding of the other end. Figure 3-8 Connecting the Grounding Cable 3.3.2 Pole Mounting (for V1.XX Products) Insert a hose clamp to the holes on the mounting brackets, attach the mounting brackets to the power adapter...
Page 19 Hardware Installation and Reference Guide Product Installation The following steps are the same as step 3)-7) for wall mounting. 3.4 Installation Verification To avoid device damage or body injury, please ensure power is turned off before verifying the installation.  Verify that the grounding cable has been connected.

This manual is also suitable for:

Rg-pbox-ac24 Rg-pbox-dc12
