Summary of Contents for iLumi MeshTek 0-10V SLC
- Page 1 USER MANUAL ilumi MeshTek® 0-10V Smart Lighting Controller (SLC) Horticultural Lighting Control User Manual Revision 1.8 Page © iLumi Solutions, Inc. www.ilumisolutions.com Confidential...
-
Page 2: Table Of Contents
OBILE ........................16 CHEDULING THROUGH SLC ............................. 17 ESET CHAPTER 6 PACKAGING AND LABELING ......................19 ............................19 ACKAGING ........................... 19 ACKAGING ABEL ......................... 20 RDERING NFORMATION CHAPTER 7 REVISION HISTORY ........................21 Page © iLumi Solutions, Inc. www.ilumisolutions.com Confidential... - Page 3 It is our intention to provide you, our valued customer, with the best possible documentation to ensure successful use of your ilumi solutions products. To this end, we will continue to update our publications to better suit your needs. Our publications will be refined and enhanced as new volumes and updates are introduced.
-
Page 4: Chapter 1 Introduction
10V PWM control signal; these signals are interfaced with the LED driver with dimming functionality. The SLC allows user to control the LED fixture remotely through the ilumi iOS and Android app over a simple Bluetooth Low Energy (BLE) protocol. Multiple lighting fixtures can be controlled individually or together as a group. -
Page 5: Chapter 2 Overview
• 0-10V Analog or Single 10V PWM control signal 2.2 Package Contents Package contains the following: • Plug & Play ilumi MeshTek® 1 Channel 0-10V SLC 2.3 0-10V SLC Board • Representation of end user interface and connectors to MeshTek® 1 Channel 0-10V SLC is shown in... -
Page 6: 0-10V Slc Connectors
• The only self-healing BLE Mesh for high data transfer and reliable communication • Built-in antenna with up to 200-meter range with reliable and secured meshing • Input supply current 100mA in Transmit mode at +18.9dBm output power and less than 1mA in ideal mode Page © iLumi Solutions, Inc. www.ilumisolutions.com Confidential... -
Page 7: Control Options
Description Notes Input Supply Voltage Channel-1 (AUX+ / AUX-) Input Supply Current (AUX) 10mA 100mA With ilumi mesh stack running Analog Output Voltage Channel-1 Default: 0-10Vdc (DIM+ / DIM-) Can be configured to 10V PWM Radio Operating Frequencies 2.360 GHz 2.500 GHz... -
Page 8: Chapter 3 Hardware
3.1.3 PROGRAMMING CONNECTOR (J2) J2 is 5X2 1.27mm pitch programming connector Pin No.1 Pin No.2 Pin No.3 Pin no.4 Pin No.5 3.0V SWDIO SWDCLK Pin No.6 Pin No.7 Pin No.8 Pin No.9 Pin no.10 P0.21/RESET Page © iLumi Solutions, Inc. www.ilumisolutions.com Confidential... -
Page 9: Chapter 4 Getting Started
It is recommended that a wrist band or anti-electrostatic glove be used when handling the SLC. 4.1 Connecting the 0-10V SLC to LED driver Application setup for LED driver with dimming functionality (0-10V Analog or 10V PWM) Figure 4-1 Application Setup (Single Channel and Four Channel 0-10V SLC) Page © iLumi Solutions, Inc. www.ilumisolutions.com Confidential... -
Page 10: Chapter 5 Using Mobile Meshtek® Smart Lighting Controller App
1. Launch Settings from your Home Screen. 2. Tap on General. 3. Tap on Device Management. 4. Tap the name of the distributor under the Enterprise App section. (ilumi Solutions, Inc.) 5. Tap to trust. 6. Tap to confirm and now open Horticulture. - Page 11 “Create Account” button, enter your email ID and password as shown in Figure 5- 1. If you are a registered user then click on the Login “button” and enter your account credentials as shown in Figure 5-2. Figure 5-1 ilumi MeshTek® Horticultural Lighting App Page © iLumi Solutions, Inc. www.ilumisolutions.com Confidential...
-
Page 12: Control Through Mobile App
After finishing the installation settings, the New Group Item will appear on the screen, showing the number of SLCs available in the Group. Click on top left “<” button to return to the dashboard screen. Page © iLumi Solutions, Inc. www.ilumisolutions.com Confidential... - Page 13 5-4. The Brightness bar present at the bottom allows users to control the brightness of all the connected channels. For MeshTek® 1 Channel 0-10V SLC change White (CH 1) and Brightness buttons to control the LED Load. Page © iLumi Solutions, Inc. www.ilumisolutions.com Confidential...
- Page 14 Refer to Figure 5-5 and Figure 5-6 to do so. The light will turn on to a Default every time level when powered ON unless there is any other schedule running, which is explained later in this manual. Page © iLumi Solutions, Inc. www.ilumisolutions.com Confidential...
- Page 15 A user can set multiple scenes by clicking on the Scene Tab on the Light Setting Screen. The scenes created can be accessed, modified, renamed, deleted and run from the Scenes screen which can be navigated from the Dashboard screen. Figure 5-5 Set Default Set and Run Scenes Figure 5-6 Page © iLumi Solutions, Inc. www.ilumisolutions.com Confidential...
-
Page 16: Scheduling Through App
Figure 5-7. Click on the Schedule button and then select Light Setting or Scenes as needed for scheduling as in Figure 5-8. Select the SLCs to which the schedule needs to be applied and follow the process until the finished. Page © iLumi Solutions, Inc. www.ilumisolutions.com Confidential... - Page 17 Figure 5-8 Schedule Settings 5.5 Creating additional networks for your MeshTek controllers Please follow the link below which showcases this feature of MeshTek powered ilumi smart bulbs: https://ilumi.zendesk.com/hc/en-us/articles/115000609874-Creating-Additional-ilumi-Networks-Locations- Page © iLumi Solutions, Inc. www.ilumisolutions.com...
-
Page 18: Reset Slc
USER MANUAL 5.6 Sharing Access to Your MeshTek Controller Lights Please follow the link below which showcases this feature of MeshTek powered ilumi smart bulbs: https://ilumi.zendesk.com/hc/en-us/articles/115000626754-Sharing-Access-to-Your-ilumi 5.7 Reset SLC There are two ways to reset a SLC: a hard reset or a soft reset. -
Page 19: Packaging And Labeling
Figure 6-1 Packaging 6.2 Packaging Label Company: ilumi solutions Brand: MeshTek SKU: MTA1SLC Model: MeshTek-MLC-1CHAnalog Description: Single Channel Analog Smart Lighting Controller Quantity: 1 For documentation, please visit www.ilumisolutions.com. Figure 6-2 Packaging Label Page © iLumi Solutions, Inc. www.ilumisolutions.com Confidential... -
Page 20: Ordering Information
Ordering information for the MeshTek® 1 Channel 0-10V SLC Part Number Description MTA1SLC MeshTek® 1 Channel 0-10V SLC MTA4SLC MeshTek® 4 Channel 0-10V SLC Note: For custom applications, contact ilumi Solutions Inc. representative. Page © iLumi Solutions, Inc. www.ilumisolutions.com Confidential... -
Page 21: Chapter 7 Revision History
• Updated electrical specifications • Updated absolute maximum ratings • Updated board, setup images, packaging and label images • Updated MeshTek app images • Nov 2018 Updated with Horticultural Specific Features and Functionality Page © iLumi Solutions, Inc. www.ilumisolutions.com Confidential...
