Cenix MMP-R630 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Safety Instructions
● These instructions describe the precautions and about how to deal with the product to prevent personal injury or
property loss. Please read the following safety precautions carefully.
● Keep this instruction in the place which you can find easily whenever you need.
Warning and Caution
This symbol indicates that personal
injury may occur or the product may
Warning
be damaged when you fail to follow
the given instruction.
This symbol indicates that property
Caution
loss may occur or the product may
malfunction when you fail to follow
the given instruction.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MMP-R630 and is the answer not in the manual?

Questions and answers

Summary of Contents for Cenix MMP-R630

  • Page 1 Safety Instructions ● These instructions describe the precautions and about how to deal with the product to prevent personal injury or property loss. Please read the following safety precautions carefully. ● Keep this instruction in the place which you can find easily whenever you need. Warning and Caution This symbol indicates that personal injury may occur or the product may...

  • Page 2: Table Of Contents

    Contents ■ Safety Instruction ■ Precautions ■ Product Features ■ Names of Parts ■ Before Using - Inserting Battery - Powering On/Off - Button Functions ■ MP3 Mode Playback Scanning File(FF/REW) Deleting MP3 File MP3 Playback Functions Scan and Playback Resume A-B Repeat - Setting Menu...
  • Page 3 Using Frequency Preset Memory Deleting Preset Frequency Recording Broadcast Setting Menu Area ■ PC Interface Installing Driver Download Upload Deleting File ■ Trouble Shooting ■ Specifications ■ Warranty...
  • Page 4 Precautions ■ Precautions for use of the product Do not install the product in a place exposed to these conditions: High temperature (above 40℃) Much moisture Poorly ventilated or closed (humidity, above 75%) (car inside, especially summer) Dusty place Make sure not to place cash cards Do not clean using chemicals such pass cards,...
  • Page 5 Precautions ■ Precautions for use of the battery impose heat Make sure to use the specified disassemble or short-circuit. standard battery. Otherwise, cause damages (‘ AAA’ Alkaline battery) malfunctions to the product. Do not place the metals such as Make sure that the polarities are coins and keys with the battery.
  • Page 6 Precautions ■ Safety Precautions product smokes Do not use the product in an modification occurs due to heating, airplane or a place where electronic remove the battery immediately. devices should not be used. Do not use earphone during driving Do not listen to with a loud volume. or walking.

  • Page 7: Product Features

    Product Features ■ Compact Size Handy to carry due to compact size and light-weight. ■ Adapting flash memory Recorded sound is preserved even if the power is cut off. ■ Automated Power Break Automated power break reduces battery consumption. ■ EL lighting You can see the message on the LCD screen even if the place is dark.

  • Page 8: Names Of Parts

    Names of Parts Left Front Back HOLD Battery Cover Right FF/MENU/REW POWER/PLAY/STOP RECORD/STOP VOLUME Built-in Microphone Bottom Earphone Jack USB Socket...
  • Page 9 Description of LCD Playback Operating Volume Icon Battery Indicator Mode Icon Mode Icon Repeat Mode Stereo Mode EQ mode HOLD ON File No./Playback Time Recording Time/Frequency...

  • Page 10: Before Using

    Before Using ■ Inserting Battery 1. Push the battery cover slightly and slide it in the arrow direction. 2. Insert one AAA alkaline battery. Make sure that the polarities (+, -) are correct. 3. Close the battery cover. ● Make sure to replace the batteries in stop mode. Caution ●...

  • Page 11: Powering On/Off

    Before Using ■ Battery Lifetime ("AAA" Alkaline) Battery MP3 Playback Voice Recording FM Mode Playback with Earphone(VOL. 10) 00 hours 00 hours 00 hours 00 hours Alkaline ☞ Note ☜ ● Battery lifetime is subject to battery type and the volume you use. ●...

  • Page 12: Mp3 Mode

    MP3 Mode ■ Playback You can listen to MP3 file saved in the product. 1. Select a file you wish to playback using FF/REW button. 2. Press the PLAY/STOP ? b utton shortly once to start playback. 2. Press the PLAY/STOP ? b utton shortly once again to stop playback. ☞...

  • Page 13: Scanning File(Ff/Rew)

    MP3 Mode ■ Scanning File (FF/REW) Using the FF/REW b utton, you can move to the file you want. ● Moving to the previous or next file: Press the FF/REW b utton shortly during playback. ● Scanning file: Press the FF/REW b utton longer during playback.

  • Page 14: Mp3 Playback Functions

    MP3 Mode ☞ Note ☜ ◆ If you press the MENU button or other button except the ERASE button, file deletion is cancelled. ● Caution The deleted recording file cannot be recovered. Please make sure to decide carefully and check the file(s) you select to delete.

  • Page 15: A-B Repeat

    MP3 Mode ● A-B Repeat Repeats the selected part. 1. Press the MENU button shortly once to select A point during playback. 2. Press the MENU button shortly once again to select B point, the selected A-B part is repeated. 3.

  • Page 16: Repeating

    MP3 Mode ● Setting USER EQ mode You can set LOW sound(BASS) and HIGH sound(TREBLE) for 5 steps. 1. Select USER in the setting EQ mode, select MENU button shortly once. 2. Set the BASS using the FF/REW button, press the MENU button shortly once. 3.
  • Page 17 MP3 Mode ● Deleting You can delete MP3 files saved in the product. Deleting one file and all files are available. The way of deleting files is the same as Deleting MP3 File, page 13.

  • Page 18: Voice Mode

    Voice Mode ■ Switching to Voice Mode Press the MENU button shortly once, select Voice Mode using the FF/REW button. ■ Recording You can record voice or sound. 1. Press the REC/STOP button shortly once to start recording in stop mode. 2.

  • Page 19: Deleting File

    Voice Mode ■ Deleting Voice File You can delete the voice files saved in the product. ● Deleting one file(FILE ERASE) Deletes one recorded file in the product. The file numbers are decreased by one after deleting file. 1. Select the file to delete in stop mode, press the MENU button longer once and shortly twice to enter ERASE MODE.

  • Page 20: Index Added Recording

    Voice Mode ■ Voice Recording Function ● Index Added Recording Adds the indexing number (file number) of the file being recorded. Press the FF? b utton during recording, the file number of the file being recorded is increased and saved automatically. ◆...

  • Page 21: A-B Repeat

    Voice Mode ● A-B Repeat Repeats the selected part. 1. Press the MENU button shortly once to select A point during playback. 2. Press the MENU button shortly once again to select B point, the selected A-B part is repeated. 3.
  • Page 22 Voice Mode ● Deleting You can delete MP3 files saved in the product. Deleting one file and all files are available. The way of deleting files is the same as Deleting Voice File, page 19.

  • Page 23: Radio Mode

    Radio Mode ■ Switching to Radio Mode Press the MENU button shortly once, select Radio Mode using the FF/REW button. ■ Scanning Frequency Scans the frequency of the broadcast you wish to listen to. ● Auto Frequency Scanning Press the FF/REW button longer while listening to a radio broadcast. ●...
  • Page 24 Radio Mode ■ Listening to Preset Frequency You can listen to the frequency broadcast saved with the preset number. 1. Press the PLAY/STOP? b utton shortly once while listening a radio broadcast. 2. The Preset number and broadcast frequency displays on the LCD screen. 3.
  • Page 25 Radio Mode ■ Recording Broadcast Records the broadcast you are listening to. 1. Press the REC/STOP button longer to start recording while listening to a broadcast. 2. Press the REC/STOP button longer once to stop recording. ☞ Note ☜ ● Recorded file is saved in the VOICE folder as *.WAV. You can check it on the screen after connecting to the PC.
  • Page 26 Radio Mode ■ Setting Menu ● Area You can change the frequency band according to your area. 1. Press the MENU button longer once. 2. Select your area using the FF/REW button and press the MENU button shortly once to complete setting. EUROPE/KOREA JAPAN ☞...
  • Page 27 PC Interface ■ Installing Driver 1. Insert the Driver CD on your CD Rom driver. Open the CD driver on the windows explorer. 2. Double-click the [Setup.exe] item in the right window.
  • Page 28 3. Press the NEXT button sequentially as directed on the screen to finish the installation. Click Click ※ Note Please press the [Continue Anyway] button and keep installing when the below message is shown after installing the driver on the Windows XP. ※...
  • Page 29 PC Interface ■ Downloading 1. Turn the power on and connect the product to the PC after installing the driver using USB cable. 2. [Removable Disk] is created in the windows explorer. The saved files are displayed on the right window.
  • Page 30 3. Select the MP3 file(s) you wish to download to the product.
  • Page 31 4. Click the right button of your mouse. Select [Copy] item.
  • Page 32 5. Select the [Removable Disk] on the left window and click the [Paste]. Or drag and drop to the [Removable Disk].
  • Page 33 PC Interface ■ Uploading ※ You cannot upload MP3 files to the PC. 1. Select file(s) you wish to upload in the right window of the windows explorer.
  • Page 34 2. Click the right button of your mouse and select the [Copy].
  • Page 35 3. Select any folder to save file(s) and click the [Paste]. Or drag and drop file(s) where you want to save.
  • Page 36 PC Interface ■ Deleting File 1. Select file(s) you wish to delete on the right window of the windows explorer.
  • Page 37 2. Click the right button of the mouse and click [Delete].
  • Page 38 3. Click [Yes] to delete the file(s).
  • Page 39 Troubleshooting When you encounter any problem, check the following items. Symptom Cause Action Nothing is displayed on the Check whether the battery runs out. Replace the battery with a new LCD screen. one. Check whether the polarities are Make sure that the polarities are correct.
  • Page 40 Specifications Item Specification Model MMP-R330 MMP-R630 Memory 64 MB 128 MB Battery Life Time MP3 playback: approx. 00 hours Voice playback: approx. 00 hours Voice recording: approx. 00 hours Frequency 500 Hz ~ 3500 Hz Bit Rate 8Kbps ~ VBR...
  • Page 41 Warranty...
  • Page 42 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICES MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE, RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDERSIRED OPERATION. Note : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
