- Page 1 Pulse induction detector GOLD SCAN IIII User’s Manual KTS-Electronic GmbH & Co. KG Germany KTS-Electronic GmbH & Co. KG – GOLD SCAN III...
-
Page 2: Table Of Contents
General guidelines....................3 Preface ......................3 Important details ....................3 Scope of delivery ..................... 4 Hardware operation .................... 5 Assembly of GOLD SCAN III search coils ............. 5 2.1.1 Search coil 35cm ....................5 2.1.2 Search frame 1x1m ..................... 6 Electronic unit ..................... -
Page 3: General Guidelines
Without the need for an exchange of probes the search power can be chosen in a range of 10 m to 25 m. Besides the KTS 3D software the new "GPA Visualizer" software is pre-installed on the tablet computer; this enables an easy operation without the need for previous knowledge. -
Page 4: Scope Of Delivery
English, German, French or Spanish user's manual. Assembly instruction-video 2 years manufacturer's warranty for the entire scope of delivery (incl. hardware and software) Abb.: 1-1 Complete GOLD SCAN III-Set KTS-Electronic GmbH & Co. KG – GOLD SCAN III... -
Page 5: Hardware Operation
Connect the electronic unit to the armrest (display facing up) and fasten it with the adjusting screw. Plug the search coil in to the “Pulse”-socket of the electronic unit. Fig.: 2-1 35cm search coil with armrest KTS-Electronic GmbH & Co. KG – GOLD SCAN III... -
Page 6: Search Frame 1X1M
Fold the cable and place it into the pipe like shown in the figures. Plug the search frame in to the “Pulse”-socket of the electronic unit. Fig.: 2-2 Search frame (unpluggged) Fig.: 2-3 Folded cable Fig.: 2-4 Placed cable KTS-Electronic GmbH & Co. KG – GOLD SCAN III... -
Page 7: Electronic Unit
The newly developed compact housing has a new design and impresses with it’s simple handling. The GOLD SCAN III is a measuring device, which can measure alterations of ground anomalies caused by metal objects, soil structure or excavations and can discriminate from normal ground magnetism. -
Page 8: Gold Scan Iii Display
Repeat the zero balance process after soil-changes like a dig up or after you changed location. In the beginning please set the frequency to the lowest level. The volume should be set hearable with the help of the Audio control. Generally we KTS-Electronic GmbH & Co. KG – GOLD SCAN III... -
Page 9: Search With 1X1M Search Frame
It is recommendable to keep the search coil parallel and close to the ground while searching. Small scrap iron parts will automatically be filtered. Set frequency like in 4.1.1. KTS-Electronic GmbH & Co. KG – GOLD SCAN III... -
Page 10: Search With Cylindrical Coil
The cable should not have slack. Set frequency like in 4.1.1. Fig.: 4-3 cylindrical coil KTS-Electronic GmbH & Co. KG – GOLD SCAN III... -
Page 11: Battery And Charger
Fig.: 4-6 Batterypack incl. wire and clip The external battery pack is connected to the electronic unit via included cable. The battery pack can be attached to your belt loop or somewhere similar. KTS-Electronic GmbH & Co. KG – GOLD SCAN III... -
Page 12: Android Software
5 Android software There is a tablet computer included in the GOLD SCAN III XS-set for two-dimensional and three-dimensional evaluation of your measurements which connects wirelessly via Bluetooth with the electronic unit. Fig.: 5-1 Tablet computer incl. mount Commissioning of tablet computer ... -
Page 13: Bluetooth-Connection
A confirmation pop up with :”CONNECTED” will appear on the tablet computer. A blue dot will appear on the screen of the electronic unit. Fig.: 5-3 Successful Bluetooth connection KTS-Electronic GmbH & Co. KG – GOLD SCAN III... -
Page 14: Kts Software
The measurement can be deleted with the “RESET”- button. Hint: The Bluetooth pairing has failed if there is no “START”- button on the lower part of the screen . (see 5.2) KTS-Electronic GmbH & Co. KG – GOLD SCAN III... -
Page 15: Evaluation With Kts Gold Scan Iii
Fig.: 5-5 Active measurement with KTS GOLD SCAN III 5.3.2 Evaluation with KTS GOLD SCAN III You can switch to VIEW any time by tapping in the menu (even while still measuring). Here you see the “CURRENT MEASUREMENT”. ... -
Page 16: Settings For Kts Gpa 3D
“Developer Settings”: Please do not change the developer settings except for “Measure-delay”. Here you can change the time between two measurements. Please note that this option will effect the speed options “SLOW”, “NORMAL” and “FAST” under “MEASURE”. KTS-Electronic GmbH & Co. KG – GOLD SCAN III... -
Page 17: Reinstallation
Fig.: 5-8 Settings Reinstallation If you want to reinstall KTS GPA 3D or Visualizer or you want to use a different Android device, the apk.-files are available on an enclosed flash drive. Just copy the files from the flash drive to your device and execute them. In order to do that you need to allow installation of apps from unknown sources. -
Page 18: Terms Of Use
Defective parts will be repaired gratuitous or will be replaced by efficient parts of our choice. KTS-Electronic GmbH & Co. KG reserves the right to exchange a device by an equal valued replacement unit in case the returned product cannot be required in an appropriate budget time frame. -
Page 19: After Expiration Date
After expiration date KTS-Electronic GmbH & Co. KG can agree upon a service after expiry of guarantee. In this case repairing and shipment will be charged. Care Your GOLD SCAN III requires little maintenance, yet there are some items, which you should consider, in order to receive its best functionality. -
Page 20: Contact
9:00 am to 4:00 pm Copyright: KTS-Electronic GmbH & Co. KG, Moerfelden-Walldorf, Germany, 2018. A duplication or usage of graphics and/or text of this publication is not allowed without explicit consent. KTS-Electronic GmbH & Co. KG – GOLD SCAN III...
