Controlling Tomorrow's World
EMX34/CK34 Cardkey Interface
Board Installation Guide
The EMX34/CK34 Cardkey Interface Board is designed to convert the signals from up to four
Cardkey Model #L47 readers (or two Model #L40-6 readers, which draw more current) into
Wiegand format, which can be read by the ACX 700/780 family of controllers.
Warranty Registration
Your warranty is effective for 18 months starting on the date the system is shipped.
Site/System Setup Requirements
Before you install the controller, you should map out where you plan to install each inter-
face. When planning the sites, be aware of dimensions, power requirements, and
environmental requirements.
Dimensions
The EMX 34 printed circuit board is approximately 6.125 × 3.625" (160 × 92 mm).
Power Requirements
The EMX 34 receives power from an ACX 700/780 to supply the Cardkey reader. The EMX
34 requires an additional 24 VAC (1 amp) which powers the Cardkey reader incandescent
lamps (LEDs). The EMX 34 board converts the power to 9 VDC output for the lamps.
Environmental Requirements
The EMX 34 operates in the same environment as any Infinet controller.
EMX 34 Installation Guide
1
Technical Manuals Online! - http://www.tech-man.com
