RS2000 USER MANUAL

Table of Contents

Summary of Contents for Leon RS2000

Page 1 RS2000 USER MANUAL...
Page 2 COMPLIANCE EGULATORY The device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. FCC W ARNING TATEMENT...
Page 3: Table Of Contents
TABLE of CONTENTS Introduction ............2 Requirement ............2 NFC Compatible Smartphone......2 Administrator & Client ........3 RS2000 Parts ............. 4 User Smartphones ..........6 Install APP ............6 Key Butler User Manual ........8 Batch Mode ............9 DIN ...............
Page 4: Introduction
RS2000 is designed to communicate with NFC interface, so please choose smartphones which support NFC function to be a client or an administrator. MIFARE Compatible Contactless Card RS2000 can also be unlocked by contactless cards. The cards must be compatible with MIFARE standards.
Page 5: Administrator& Client
Administrator& Client A NFC smartphone with Key Butler installed, or a contactless card, is called a User. For a User to unlock a lock, it must become a Valid User of the lock. Only Valid Users can unlock the lock. There are two kinds of Valid Users.
Page 6: Rs2000 Parts
RS2000 Parts Status LED Sense Area Keyway Exterior Status LED The Status LED indicator located on the head of the lock which indicates the operating status of the lock. Flashing When an invalid user try to unlock, the status LED will flash red, and generate warning beeps.
Page 7 Sensing Area NFC is a kind of short distance wireless communication technology. Different smartphones’ NFC antennas may not be at the same location.Please try to find your smartphone’s best sensing area at first. Battery Cover Battery Cover Screw Interior Battery Cover Screw The location of Battery Cover Screw is not only just a screw, but also a Setup Button behind here.
Page 8: Usersmartphones
UserSmartphones Whether it’s an administrator or a client, all smartphone usersneed to install the app ‘Key Butler’. Make sure your phone is already connected to internet before installing the app. Install APP Step 1.Open ‘Apps’ group Step 2. Tip ‘Play Store’ Step 4.Press ‘INSTALL’...
Page 9 Step 5. After read permissions, Step 6.Tip ‘OPEN’ to start app click ‘ACCEPT’...
Page 10: Key Butler User Manual
Key Butler User Manual About how to operate app on smartphone, please refer to the Key Butler user manual. You can find the Key Butler user manual inside the app: Or check the web site: http://www.keybutlerapp.com/manual.html...
Page 11: Batch Mode
Batch Mode For a use-case that only cards are used and no one uses NFC smartphone, the lock provides a method to add/delete cards. 1. Click the Setup button on the inner side of the lock. 2. Before time-out, use a card to tap the lock. The card will become a Client of this lock.
Page 12: Din
Correct DIN must be entered for start the pairing process. The DIN of RS2000 is lower case of model name ‘rs2000’.
Page 13: Low Battery
Low Battery RS2000 has low battery caution function. When the voltage is lower than safety power, RS2000 will give warnings while unlock every time. During low-battery state, there are two kinds of sound for different status: (1) Unlock success: The sound is 1 beep, then 10 beeps for low battery warning.
Page 14: Resetto Factory Default
Resetto Factory Default STEP 1.Remove at least a battery. STEP 2. Push the Setup Button. Push the Setup Button...
Page 15 STEP 3. Fit in the battery while keeping pushing the Setup Button. Push the Setup Button STEP 4. Keep pushing Setup Button until it generates 4 beeps. Release the Setup Button now. And the lock is restored to factory default now.
Page 16: Eventsand Beeps
Eventsand Beeps Events Beeps Phone or Card Unlock 3 raising tone beeps 1 beep, then 10 beeps for low battery Low Battery Unlock warning 1 long and 4 short beeps, the long beep Phone or Card Unlock fail pitch is higher 1 long and 4 short beeps, the long beep Low Battery Unlock fail pitch is higher...
Page 17: Trouble Shooting
Trouble Shooting Problems and Solutions  No response. If the lock does not have any response, change batteries and try again.  Lock work but no sound. If unlock function is normal, but there is not any sound, check the parameter is not in mute mode.Please check ‘Lock Configuration’...
Page 18: Specification
Specification Length = 200 mm Exterior Width = 80 mm Height = 50 mm Length = 200 mm Interior Width = 80 mm Height = 35 mm Communication Type: NFC (Near Field Communication) Radio Frequency: 13.56MHz...
