- Page 1 User’s Manual Ultra wideband Perimeter Surveillance Pole TIME DOMAIN ® Cummings Research Park 4955 Corporate Drive Suite 101 Huntsville, AL 35805 USA http://www.timedomain.com Tel: +1 256.922.9229 +1 888.826.8378 Fax: +1.256.922.0387 Draft October 23, 2014...
- Page 2 Trademarks Time Domain ® , PulsON ® , and “PulsON Triangle” logo are registered trademarks of Time Domain. Microsoft ® and Windows XP ®, Windows Vista ® , and Windows 7 ® are registered trademarks of Microsoft Corporation. Any trademarks, trade names, service marks or service names owned or registered by any other company and used in this manual are the property of its respective company.
-
Page 3: System Overview
Ultra Wideband Perimeter Surveillance Pole / User’s Manual Overview This document is a User’s Manual for the Time Domain Ultra Wideband (UWB) Perimeter Surveillance Pole (PSP400). The document is divided into the following sections. Section 1 System Introduction & Theory of Operation... - Page 4 Ultra Wideband Perimeter Surveillance Pole / User’s Manual Figure 1 is a conceptual depiction of the USS. As suggested in the figure the USS can track and independently classify multiple people and animals using its system of radars. A server processes data from the radars and provides outputs to external users of the data.
- Page 5 Ultra Wideband Perimeter Surveillance Pole / User’s Manual The number of poles deployed at a given site depends on the length of the perimeter that requires monitoring. The poles are organized into groups of six poles referrred to as networking cells. As shown in Figure 3 the physical footprint of a networking cell is a rectangle that is 100 meters long by 20 meters wide (note the radar coverage area extends up to 20 meters beyond the cells footprint in all directions).
-
Page 6: System Theory Of Operation
Ultra Wideband Perimeter Surveillance Pole / User’s Manual The end user provided server should feature multicore processors and an operator terminal consisting of a keyboard and monitor. Such a server is needed to support the system’s processing and interface operations. The operator terminal is for the purpose of configuring, controlling, and maintaining the system. - Page 7 Ultra Wideband Perimeter Surveillance Pole / User’s Manual Array Server Processing Interface Radio TCP/IP Packet • Tracks Video • Classifications TCP/IP Packet Radio • Scans TCP/IP Packet • Configuration • Status Web Message • Video Relay • Alarm Relay TCP/IP Packet •...
- Page 8 Ultra Wideband Perimeter Surveillance Pole / User’s Manual Each network cell is implemented as a fixed TDMA scheme that supports a 4 Hz update rate. This fixed TDMA cycle and timing information is available to each P400 and ensures only a single P400 (within each cell) is radiating at any given time.
- Page 9 Ultra Wideband Perimeter Surveillance Pole / User’s Manual 1.2.4 Graphical User Interface (GUI) The Graphical User Interface (GUI) function provides visual output to the operator terminal and controls to allow the operator to change configuration data, start and stop the system, enable or disable certain functions, etc.
- Page 10 Ultra Wideband Perimeter Surveillance Pole / User’s Manual 2. Pole Overview An assembled pole is approximately 6 inches in diameter and 10.5 feet tall (Figure 8). It is mounted on an end user provided concrete footing. The footing has four threaded studs that protrude above its top surface.
-
Page 11: Mounting Nuts
Ultra Wideband Perimeter Surveillance Pole / User’s Manual The Base Plate Cover protects the support electronics mounted on the pole’s base plate as shown in Figure 9 the support electronics consist of: An Ethernet switch An AC/DC converter ... - Page 12 Ultra Wideband Perimeter Surveillance Pole / User’s Manual UWB Antenna Ethernet & Power Cable P400 Housing Fiberglass rods (3) Figure 10: UWB Radar (P400) mounted to pole structure Ethernet 12 VDC P400 UWB Module Figure 11: P400 within its housing...
- Page 13 Ultra Wideband Perimeter Surveillance Pole / User’s Manual Pole internals AC Power AC/DC Converter DC Power Terminal block Ethernet Switch Ethernet Bottom Middle P400 P400 P400 AC Power Ethernet 12 V DC Power Figure 12: PSP Block Diagram...
- Page 14 Ultra Wideband Perimeter Surveillance Pole / User’s Manual 3. P400 Radar The radar is Time Domain’s P400 Ultra Wideband (UWB) module (Figure 13) configured to provide monostatic and bistatic radar operation. Monostatic radar operation is a single device receiving scans from its own transmitted pulses. In a bistatic mode one radar receives scans (pulses) transmitted from another radar.
- Page 15 Ultra Wideband Perimeter Surveillance Pole / User’s Manual 1.2.3 scans generated by the P400s are processed by software in order to realize the detection, tracking, and classification capabilities of the system. -0.5 -1000 -500 0 500 1000 Frequency, GHz t, pico seconds...
- Page 16 Ultra Wideband Perimeter Surveillance Pole / User’s Manual To power the board, the user must supply a maximum of 5 Watts at any voltage between 5.75-30V. Indicating lights provide operating status information. The user can interface to the P400 through either USB (standard USB Micro B connector), Serial connection, or Ethernet.
- Page 17 Ultra Wideband Perimeter Surveillance Pole / User’s Manual 4. Broadspec Antenna The P400 is designed to operate with the Broadspec antenna shown in Figure 16. Use with ANY other antenna invalidates the FCC certification. Per FCC 15.203, the Broadspec antenna must be professionally installed and the installer has the responsibility to insure that the Broadspec antenna is used.
-
Page 18: Fcc Compliance
The PSP400 has been designed to be in compliance with the FCC regulations governing UWB Surveillance Systems (Part 15.511). Time Domain as manufacturer is in charge of all marketing. Any purchasers (non- government) by commercial clients will be informed of their responsibility under FCC rules by receiving a copy of Section 15.525 which requires them to co-ordinate their activities and... - Page 19 Ultra Wideband Perimeter Surveillance Pole / User’s Manual Label location Figure 18: PSP400 label location...
