TM
BluePro
Model 510 Bluetooth
Cash Drawer Interface Adapter
User's Guide
Product Specification – Part Numbers and Descriptions
APG Part Number
BA-0510-0101A-02
BA-0510-0102A-02
BA-0510-0101A-03
BA-0510-0102A-03
APG doc no. M-23G-510-06 Rev J
TM
BluePRO
Description
TM
BluePRO
Model 510 Bluetooth Interface Adapter for Direct Drive
Printer-Kick Cash Drawer with CD-101A Cable and USA power adapter
TM
BluePRO
Model 510 Bluetooth Interface Adapter for Direct Drive
Printer-Kick Cash Drawer with CD-102A Cable and USA power
adapter
TM
BluePRO
Model 510 Bluetooth Interface Adapter for Direct Drive
Printer-Kick Cash Drawer with CD-101A Cable and Multi-Country
power adapter
TM
BluePRO
Model 510 Bluetooth Interface Adapter for Direct Drive
Printer-Kick Cash Drawer with CD-102A Cable and Multi-Country
power adapter
Model 510 Bluetooth External Device
1 (7)
Advertisement
Table of Contents
Related Manuals for APG BlueProTM 510
Summary of Contents for APG BlueProTM 510
- Page 1 Model 510 Bluetooth Interface Adapter for Direct Drive Printer-Kick Cash Drawer with CD-101A Cable and Multi-Country power adapter BA-0510-0102A-03 BluePRO Model 510 Bluetooth Interface Adapter for Direct Drive Printer-Kick Cash Drawer with CD-102A Cable and Multi-Country power adapter APG doc no. M-23G-510-06 Rev J 1 (7)
- Page 2 Product Specification – Part Numbers and Descriptions ........1 Introduction and Product Overview ..............3 Operational Description and Antenna Information ..........5 Declaration of Comformity ................5 Product Label Information ................6 Device Dimension and Resource ..............7 APG doc no. M-23G-510-06 Rev J 2 (7)
- Page 3 Bluetooth version 2.1 (Classic Bluetooth Mode with EDR). The operating frequency range is 2402- 2480 MHz. The APG BluePRO sample application supports up to a maximum of seven (7) APG Model 510 BluePRO Bluetooth-enabled Cash Drawer Interface Adapters. APG doc no. M-23G-510-06 Rev J...
- Page 4 Operational Description and Antenna Information Operation Description: The APG BluePRO 510 interface is a cash drawer controller that utilizes Bluetooth signals to communicate to the host device to operate a cash drawer. The product implements Bluetooth version 2.1 (Classic Bluetooth Mode with EDR).
-
Page 5: Declaration Of Conformity
(e.i.r.p.) is not more than that necessary for successful communication. APG doc no. M-23G-510-06 Rev J 5 (7) - Page 6 Style Direct thermal label Material Low-cost paper Adhesive Permanent Overlay None Size 1.20in wide x 0.85in tall Text Color Black Font and Size for Text Reasonably large, easily readable and as shown APG doc no. M-23G-510-06 Rev J 6 (7)
- Page 7 Dimension Height = 1.02IN Width = 2.50IN Length = 2.65IN Resources For product assistance, contact your reseller partner or APG Cash Drawer. Technical Services and Support Group APG Cash Drawer, LLC 5250 Industrial Blvd NE Minneapolis, MN 55421 +1.763.571.5000 ext. 160 apgsupport@apgcd.com...
