Summary of Contents for Bundutec BunduTop
- Page 1 BUNDUTOP MANUAL...
- Page 2 LED light inside. The roof of the BunduTop is a raw aluminium sheet to ensure maximum heat reflection and is the main reason you can sleep comfortably cool inside, even in direct sunlight.
- Page 3 • All aluminium construction ladder Solar Wiring: • Since 2017 we incorporated solar wiring as a fixture with every BunduTop. • The wiring for the solar wiring runs underneath the roof-lining. • There will be a red Brad Harrison plug on the roof of the tent for easy connection to your solar panel.
- Page 4 Extras • Added room • USB port à If you prefer we can add a USB port to your rooftop tent. à It will be accessible from inside. • 12V fan à As an additional extra you can add 12V fans. à...
- Page 5 Electronics All the electronics used in the BunduTop can be found inside the Electronics Box which houses: • The Switch • The Manual Override • 2 x Diodes • 1 x Relay • 1 x Lighter Socket Should you experience any difficulties with your tent’s wiring, this is where everything is located.
- Page 6 Electrical faults and how to pinpoint them Diode If the light inside still works, but your tent won’t lift or lower, it is most probably the diode. The diode blows when there is a short in your wiring system. The short is caused by the wiring touching the body.
- Page 7 If you are doing the wiring from your battery directly to the tent: • Use a Brad Harrison plug • Use 6 mm^2 electrical wire • Use 15 Amp inline fuse – this will help prevent damage if you forget to open the latches. •...
- Page 8 Connect the two with 6mm wiring that can go through the inside of your BunduTop – ensure the length is long enough. To eaten the appearance, you can run it through the canvas sleeve next to the arm that already contains wiring.
- Page 9 To hide wires you can run them underneath the CANVAS edging around the tent – merely lift this edging, run the wiring through and glue down neatly again (you can use the canvas sleeve in the arm to hide any additional wiring). PLEASE NOTE that this can affect the warranty of the tent if not to professional standards.
- Page 10 Repairs The only other faults we have experienced are the following: Tent does not go up or down. à Check that the electric cord to the tent has power (if the light goes on inside the tent then there is power). à...
- Page 11 Our mesh is coated in a rubber compound making it extremely flexible and durable. The roof of the BunduTop is raw aluminium sheet to ensure maximum heat reflection and is the main reason you can sleep comfortably cool inside even in direct sunlight.
- Page 12 The holes in my tent doesn’t have eyelets in them. The eyelets don’t wear well. The holes are actually burned into the canvas, because it’s the strongest way to make the holes. While eyelets make for a better finish, it does not make for a stronger one, and our research suggests that eyelets pose as a weak point and is generally where tears can origi- nate.
- Page 13 All our rungs feature grooves as an added anti slipping measure. If you would prefer a different ladder, kindly let us know when placing your order and we will ex- clude the ladder - that way you can source another one better suited to your needs. Will the shape of the tent affect my fuel consumption? If it does, it is indiscernible.
- Page 14 By phoning the office, Front Desk can follow up on all calls and make sure they are attended to. South Africa BunduTec Front Desk Tel: +27 6 3782 7667 Email: info@bundutec.co.za Australia Bundutec Australia Tel: 04 1450 0430 Email: sales@bundutec.com.au DUbai, Oman &...
