Cinema Crossover/Monitor
User Manual
DCM 100
DCM 300
TD-000517-01-A
*TD-000517-01*
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCM 100 and is the answer not in the manual?

Questions and answers

Related Manuals for QSC DCM 100

Summary of Contents for QSC DCM 100

  • Page 1 Cinema Crossover/Monitor ® User Manual DCM 100 DCM 300 TD-000517-01-A *TD-000517-01*...

  • Page 2: Important Safety Instructions

    EXPLANATION OF TERMS AND SYMBOLS The term “WARNING!” indicates instructions regarding personal safety. If the instructions are not followed the result may be bodily injury or death. The term “CAUTION!” indicates instructions regarding possible damage to physical equipment. If these instructions are not followed, it may result in damage to the equipment that may not be covered under the warranty.

  • Page 3: Maintenance And Repair

    The QSC Cinema Crossover / Monitor is in compliance with European Directive 2011/65/EU – Restriction of Hazardous Substances (RoHS2). The QSC Cinema Crossover / Monitor is in compliance with “China RoHS” directives. The following chart is provided for product use in China and its...

  • Page 4: Warranty

    For a copy of the QSC Limited Warranty, visit the QSC, LLC., website at www.qsc.com Para una copia de la Garantía Limitada de QSC, visite el sitio web de QSC, LLC., en www.qsc.com Pour obtenir une copie de la garantie limitée de QSC, visitez le site de QSC, LLC. à www.qsc.com Besuchen Sie die Webseite von QSC, LLC.

  • Page 5: Package Contents

    (3 Screen Channels) • Booth monitor with front panel control for easy operation 6/8 Channel (5.1,7.1) Bi-Amp • Passive or 2-way crossovers for three screen channels (DCM 100) (3 Screen Channels) • 3-way or 4-way crossovers for three screen channels (DCM 300) 6/8 Channel (5.1,7.1) Tri-Amp...

  • Page 6: Rear Panel Features

    NETWORK (RJ45) – 10/100 Mbps Ethernet port for MODEL and SERIAL number DPM Manager, 3rd-party, or SNMP management and remote DataPort interface for QSC amplifiers – DCM 100 supports up to access. 8 single-port amplifiers, DCM 300 supports up to 11 single-port RS 232 –...

  • Page 7: Setup Overview

    Install the Software – Download the DPM Manager installation file from the QSC website and open file to install. Attach the Amplifiers – Connect DataPort™ outputs on the DCM rear panel to DataPort™ inputs on QSC’s DCA or PL3 Series amplifiers using QSC approved DataPort™...
  • Page 8 Connect the AC power cord into the AC power inlet on the back of the DCM. Plug the AC line connector into an AC outlet. The power supply on the DCM accepts from 100 – 240V, 50 to 60 Hz. If a different type of IEC power cord is required, consult QSC’s Technical Services Group.

  • Page 9: Specifications

    Specifications The following specifications are based on the DCM 300. The DCM 100 varies only in quantity of connectors. Refer to the individual sections in this document for more information. Parameter Specification Parameter Specification Front Panel Controls and Indicators HI/Monitor Outputs (5-pin Euro-style with common GND)
