- Page 1 User Manual...
- Page 2 Product Story The all new PB Series is an 80 PLUS® Gold certified gaming power supply. Gamers can adjust the colors of the built-in RGB LED fan to match personal preferences. Produce a light show in your gaming rig! PB Series Features ▪...
-
Page 3: Specifications
Specifications Model PB-650W PB-750W PB-850W Part Number 650W 750W 850W Total Power IW-PB650-RGB IW-PB750-RGB IW-PB850-RGB Material SECC Type ATX12V V2.4/EPS12V V2.92 Cable Management Fully Modular Active PFC ( >0.9) Efficiency 80 PLUS Gold (Up to 90%) MTBF (Hours) >100,000 hrs. 100 - 240Vac. -
Page 4: Package Contents
Package Contents PB Series Power Supply Unit x1 (PB-650W / PB-750W / PB-850W) Modularized Cables bag x1 - Power Cord x1 - Mounting Screws x4 - Cable Ties x8 QR code card x1... - Page 5 Package Contents PB-850W PB-650W PB-750W 20+4 Pin Motherboard 8 (4+4) Pin CPU Connector Connector PB-850WX3 PB-750WX2 PB-650WX2 8 (6+2) Pin PCI-E 4 Pin Peripheral Connector Connector PB-850W PB-650W PB-750W SATA (90 Degree) Floppy Connector Connector RGB LED Connector Power Cable Modular Cable Cable tie Screw...
-
Page 6: Cable Information
Cable Information 20+4 Pin Motherboard 650mm 8 (4+4) Pin CPU PB-750W PB-850W 650mm 100mm 8 (4+4) Pin CPU PB-650W 650mm 8 (6+2) Pin PCI-E 600mm 100mm SATA (90 Degree) PB-750W PB-850W 100mm 100mm 100mm 550mm SATA (90 Degree) PB-650W 100mm 100mm 550mm 4 Pin Peripheral... -
Page 7: Installation
Installation 1. Make sure the power supply's AC power cable is not connected before installation. 2. Place the power supply unit into the space provided in the case and secure the power supply unit with the screws. 3. Connect 24-pin power to the 24-pin socket on the motherboard. - Page 8 Switch Operation Instructions 1. Power Button - O: Turns off the power - l : Turns on the power 2. Silence Mode: - ON: The fluid dynamic bearing (FDB) 135mm fan will switch to hibernation mode automatically once the system's load is lower than 20%.
- Page 9 RGB Control - PSU (out): Use the provided 4-pin (12V) header to connect the PSU RGB Control port if your motherboard doesn't support the RGB function or if you don't need to sync RGB motherboard together. Please turn off the M/B RGB override button (switch to "O"...
-
Page 10: Troubleshooting
Troubleshooting These troubleshooting points will help you diagnose and solve problems with your power supply if the unit fails to operate properly: 1. Please make sure the power supply and power cord are connected properly. 2. Please make sure the power cord is plugged into the power socket. - Page 11 Any and all alteration of the product. 3. For more detailed warranty information, please visit the InWin retail website at www.in-win.com. 4. The actual product is subject to change without prior notice. In Win Development Inc. reserves the right to make final modifications.
- Page 12 Copyright © 2018 In Win Development Inc. All Rights Reserved.
