MODEL: GTT450
GARDEN TRACTOR TRAILER
OWNERS MANUAL
CAUTION:
Before using this product, please read this manual carefully to understand the proper use of your garden
cart. Please keep this manual for future reference.
Product colours may vary.
PLEASE NOTE: NEVER CARRY PASSENGERS IN THE GARDEN TRACTOR TRAILER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GTT450 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cobra GTT450

  • Page 1 MODEL: GTT450 GARDEN TRACTOR TRAILER OWNERS MANUAL CAUTION: Before using this product, please read this manual carefully to understand the proper use of your garden cart. Please keep this manual for future reference. Product colours may vary. PLEASE NOTE: NEVER CARRY PASSENGERS IN THE GARDEN TRACTOR TRAILER...
  • Page 2: Important Safety Instructions

    Important Safety Instructions 1. Read this entire instruction manual carefully before attempting to use or assemble this trailer. 2. Do not load the trailer with more than 660 lbs. (300 kg). 3. Do not allow children to play in or around the trailer. 4.
  • Page 3 Parts & Hardware List Part# Description Quantity Left undercarriage support Right undercarriage support Screw M8x20 Small flat washer M8 Hex nut M8 Front leg Axle Tow bar Wheel Large flat washer Hex nut M16 Side panel Front /back panel Left lock handle Right lock handle Quick release pin Control lever...
  • Page 4 Part# Description Quantity Left undercarriage support Right undercarriage support Screw M8x20 Small flat washer Hex nut Attach the Left Undercarriage Support (2) and Right Undercarriage Support (3) to the cart bed (1) with Screw M8x20 (4), Small Flat Washer (5) and Hex Nut (6) (Fig. 1). Fig.
  • Page 5 STEP 3 - Front Leg Assembly Parts and Hardware Required: Part# Description Quantity Screw M8x20 Small flat washer Hex nut Front leg Align the front leg (7) with screw holes on the front of the bed (1) and attach using Screw M8x20 (4), small flat washer (5) and hex nut (6) (Fig.
  • Page 6 STEP 4 Tow Bar and Axle Assembly Parts and Hardware Required: Part# Description Quantity Tow bar Axle Note: The yoke (20) has been attached to the tow bar (9) with two screws M8x20 (4), small flat washer (5) and hex nut (6). The control lever (18) has been attached to the tow bar using spring (19) and two screws M8x90 (22), flat washer M8 (5) and hex nut M8 (6).
  • Page 7 STEP 5 Wheel Assembly Parts and Hardware Required: Part# Description Quantity Wheel Large flat washer Hex nut M16 Place a wheel (10) on the end of the axle, followed by a large flat washer (11) and hex nut M16 (12). (Note: the wheel valve stem should be facing outward.) (Fig.
  • Page 8 STEP 6 Panel Assembly Parts and Hardware Required: Part# Description Quantity Side panel Front/back panel Left lock handle Right lock handle Release pin Attach the front panel (14) to the front of bed (1) using release pin (17). Attach the side panels (13) to the bed also with release pin (17).
