TIC BG50 Instruction Manual

Connection

1) The BG50 speaker should be installed near a suitable power source.
2) Connect the speaker's power cord to the transformer/adapter. Be sure to
tighten the connector properly for water protection.
3) We recommend that the power adapter be plugged into a covered outlet if
the outlet is located outdoor. If the outdoor outlet is not covered, please do
not use during wet condition and unplug when not in use.
4) In order to create a full sound system, you must connect at least two 8-ohm
loudspeakers (not included) to the subwoofer. Additional speaker wire may be
used to extend the distance between speakers and subwoofer.
5) You can optionally connect two additional 8-ohm speakers (four in total).
6) Most industry-standard 8-ohm loudspeakers should be compatible with the
BG50 subwoofer. We recommend using TIC's GS3 or GS5 for optimal
performance and guaranteed compatibility.

Button Layout

Left: Power Button and LED status indicator
Right: Connect/Reset Button

Button/Bluetooth Operation

• Press power button to turn on and off.
• Hold connect/reset button to activate Bluetooth discovery mode or disconnect connected device. Once discovery mode is activated, you can pair
by going to your device's Bluetooth menu. Find and connect to "BT Speaker".
TIC BG50
BG50
Outdoor Bluetooth® In-Ground Subwoofer Instruction Guide
Optional
Speakers
v v
1
Subwoofer
Speakers
Instruction Guide
