Exhibit 9
HIT-NOT Proximity System
Magnetic Field Generator
Including Collision Avoidance Module
User's Manual v1.0
FREDERICK ENERGY PRODUCTS, LLC
1769 Jeff Road
Huntsville, AL 35806
1.800.489.6915
US7,420,471; US8,169,335; US8,232,888; US5,939,986;
US6,810,353; AU2005289704; ZA2007/02919; ZA2008/02673;
ZA2010/06816, ZA2010/09068 Patent Pending

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HN-MFG-C and is the answer not in the manual?

Questions and answers

Summary of Contents for Hit-Hot HN-MFG-C

  • Page 1 Exhibit 9 HIT-NOT Proximity System Magnetic Field Generator Including Collision Avoidance Module User’s Manual v1.0 FREDERICK ENERGY PRODUCTS, LLC 1769 Jeff Road Huntsville, AL 35806 1.800.489.6915 US7,420,471; US8,169,335; US8,232,888; US5,939,986; US6,810,353; AU2005289704; ZA2007/02919; ZA2008/02673; ZA2010/06816, ZA2010/09068 Patent Pending...

  • Page 2: Table Of Contents

    Exhibit 9 Table of Contents 1. Overview………………………………………………………………………………………………………….. 2-5 Theory of Operation……………………………………………………………………………… 2 Operating Frequency….………………………………………………………………………… 3 Label Information…………………………………………………………………………………. 3-4 FCC/IC Information……………………………………………………………………………….. 4-5 2. Operation…………………………………………………………………………………………………………. 6-11 Installation Information………………………………………………………………………… 6 2.1.1 Interoperability Warning…………………………………………………………………. 6 Charging……………………………………………………………………………………………….. 6 Alerts……………………………………………………………………………………………………. 6 Maintenance………………………………………………………………………………………… 6 Adjustments…………………………………………………………………………………………. 6-7 Interferences………………………………………………………………………………………… 7 2.7.1 Generator Specifications……………………………………………………………………….

  • Page 3: Overview

    Exhibit 9 Overview The Magnetic Field Generator with CAM is part of a complete HIT-NOT Proximity Detection system from Frederick Energy Products which provides warnings to both individuals and to vehicle operators to alert them that the individual or vehicle has entered too close to an operating piece of equipment and is in a dangerous situation.

  • Page 4: Operating Frequency

    The CE label is on both the serial number label and the main label. MAGNETIC FIELD GENERATOR Serial No: MFG00200 www.hitnot.com MAGNETIC FIELD GENERATOR HN-CAM Model No: HN-MFG-C Installed 3 Vdc Lithium Button Cell Must be Recycled or Disposed of Properly Power In: 12Vdc 3A Refer to User’s Manual US7,420,471;...

  • Page 5: Fcc/Ic Information

    FCC and IC Label for Proximity Module 1.4 FCC/IC Information The FCC ID for the Personal Alarm Device is QUI-HN-MFG-C and complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: 1. This device may not cause harmful interference.
  • Page 6 Exhibit 9 Cet équipement génère, utilise et peut émettre des fréquences radio et, s'il n'est pas installé et utilisé conformément ment aux instructions du fabricant, peut causer des interférences nuisibles aux communications radio. Rien ne garantit cependant que l’interférences ne se produira pas dans une installation particulière.

  • Page 7: Operation

    Exhibit 9 Operation 2.1 Installation Information The Magnetic Field Generator with CAM is mounted on a vehicle or piece of machinery. The Collision Avoidance Module is connected to the Generator via an interface header. Metal near the Magnetic Field Generator may impact performance by reducing the field size. The CAM can be blinded by a Xenon strobe light or a cab silencer if installed within 21 inches of the CAM.

  • Page 8: Interferences

    Exhibit 9 adjust the magnetic field size, turn the screw located on the PWM pot. The volume to the Warning Module can be adjusted by turning the screw on the VOL pot. Turning in a clockwise direction will increase while turning counterclockwise will decrease the field or volume. If a CAM is installed and adjustments need to be made on the generator, the CAM must be disconnected to make the adjustments and then replaced.

  • Page 9: Installation Guides

    Exhibit 9 Magnetic Field Frequency: none Receiver Frequency: 73 kHz signal 916.48 Transmitter Frequency: Transmitter Power: 0.001W (typical) Operating Temperature Range: -20°C to + 50°C ; -4°F to 122°F Environmental Considerations: 85 dBa nominal at 14 in. (35.6cm) 2.8 Generator System Installation Guide (Factory Installed CAM) The CAM can be 1) Factory Installed when ordered, or 2) Retrofitted.
  • Page 10 Exhibit 9 Cab Silencer Warning Module to Generator Warning Module Cable In order to avoid battery drain while the vehicle is off, connect Cab Silencer to a switched and fused (5A) circuit. Place within 21” of the Operator’s PAD 4ft away from the generator.
  • Page 11 Exhibit 9 CAM Placement Determine CAM Configuration Place the 2 holes at the end of the CAM board over the 2 white plastic screws. Align the pins in the board with the Has 2 white plastic screws, Has 2 black plastic header and press with plastic nuts, standing raised circles.

  • Page 12: Potential Safety Consideration

    Exhibit 9 Secure with Silicone Attach the Antenna Put Silicone #388 on all 6 connection The top housing points and make good (with label) contains contact with the the antenna. Screw the antenna into the board. This is port on the CAM electronic grade board.
  • Page 13 Exhibit 9 ACCEPTANCE AND DEFINITIONS. Acceptance of Terms. These Warranty Terms and Conditions (these “Terms”) are a legal agreement between You, as a purchaser and end user of the System and Frederick Energy Products, LLC. By installing the System or using the System in any way, You are (1) agreeing to be bound by these Terms.
  • Page 14 Exhibit 9 (A) Indemnification. You agree to indemnify and hold FEP, any and all parent, subsidiary, and affiliate organizations, and their respective officers, directors, agents, shareholders, members, managers, advisors, consultants, employees, successors and assigns (collectively, the “Protected Parties”) harmless from and against all losses, costs, liabilities, expenses (including reasonable attorneys’ fees and expenses), claims, demands, and damages, actual and consequential, of every kind and nature, known and unknown, suspected and unsuspected, disclosed and undisclosed (collectively, “Losses”), that are in any way due to or arising out of Your use of the System, unless caused by the gross negligence or willful...

  • Page 15: Warranty

    Exhibit 9 addition to its other rights hereunder, to recover its reasonable litigation costs and reasonable attorneys’ fees. Nothing in this Section shall preclude any party from seeking equitable relief from a court of competent jurisdiction or exercising any self-help remedies, whether before, during or after the pendency of any arbitration proceeding.

  • Page 16: Revision History

    Exhibit 9 Revision History 4.1 Version 1.0 – October 4, 2013 Original Release. No revision history. 4.2 Version 2.0 – January 21, 2014 CAM Installation information included. 4.3 Version 3.0 – April 10, 2014 Health information updated Section 2.10 added 4.4 Version 3.1 –...
