Thank you for choosing Peak Care Homecare Bed. Before use, please: 1. Check that nothing has been damaged during shipping 2. Read this operation manual before operation 3. Keep t h e original packaging and if the bed doesn’t work or i s damaged on receipt, then contact the store from whom you had purchased the bed.
Chapter 1: Introduction of Integrity SS888-FM A brief overview All frames are made of steel with light cream colour powder coating. 2. 24V DC actuator systems. Voltage:230V/50Hz 3. Head/foot board are wooden board with scratch proof 4. Bed surfaces are made of steel board with powder coating.
Page 5
A. Place bed in a horizontal position when transferring the patient to or from the bed. B. Do not confuse the head end and foot end of the bed when placing the patient in the horizontal position. C. Always raise the side rails whenever the patient is lying on the bed in the horizontal position.
Page 6
SS888-FM Homecare Bed parts name Detachable head board Head Motor A Frame Detachable foot board <> <> <> Buttock Motor D Frame Foot 4"Braking castor...
Chapter 2: Actuator system function and control Actuator system overview The bed actuator system must apply to the following requirement: A. 24V low voltage DC actuator system with CE or UL approval. B. Low-noise and water-proof, C. Anti-overload protection, and anti-electric leakage, D.
III. Handset function 1. Bed extension and folding To extend bed, press the Back Up button. To fold the back of the bed, press the Back Down button. 2. Backrest To raise the back of the bed, press the Back Up button. To lower the back of the bed, press the Back Down button.
Page 10
1. Do not unplug anything when the system is broken. 2. Keep the control box in charging condition at any time to maintain battery life. 3. Unplug the power cord before removing the actuator(s) and handset. 4. When bed function is no action, first to check the power supply and then see the handset is well plugged or not 5.
Chapter 3: Bed extension and folding movement I. Extension movement FOLDING Extension...
Page 12
SS-888-FM Motorized extension operation manual Locked both side front castor Released left side of red locking bars Released right side red locking bars Released both side red locking bars Push button to operate the extension Insert both side of red locking bars movements...
Page 13
Set up both side of red locking bars Set up both side of red locking bars Push back-rest movements button 10 Back-rest lifting angle 73° Push knee-rest movements button 12 Knee-rest lifting angle 35°...
Page 14
13 Push trendelenburg button 14 Left side of Trendelenburg angle 12° 15 Push trendelenburg button 16 Right side of Trendelenburg angle 12° hi/lo adjustment range from 17 Push bed Hi/Lo button 300~700 mm...
Page 15
SS-888-FM Motorized folding operation manual Pull out both side of red locking bars Pull out both side of red locking bars Push button to operate the bed folding The bed motorized folding movements movements Bed being folded Locked both side of red safety bars...
Page 16
Locked left side of red safety bars Locked right side of red safety bars Portability 10 Ready for delivery...
Page 17
Step Picture Description Lock the head board castor before unfolding. Note: Always lock before movement. Unlock the red hanger of bed two sides. Same in another side. Note: 1. Please do not take them out until the bed is fully unfolded.
Page 18
Take the red bar out. Repeat for the other side. Note: Make sure the bed is fully unfolded before taking the red bars out. Put the red bar through the button tube. Repeat for the other side. Note: Please do not operate the bed until the red bars have been stowed in the fixed location.
Page 20
Step Picture Description Lock the head board castor before folding. Note: Always lock before movement. Unlock the red bar from the fixed location. Repeat for the other side. Note: Please do not operate the bed until the red bars have been stowed in the fixed location .
Page 21
Put the red bar into the backrest board. Repeat for the other side. Note: Make sure unfolding has finished before taking out. Press backrest up key to fold the bed. Note: Make sure the 2 red bars are inserted into the backrest board. Lock the red hanger of bed two sides.
Chapter 4: Steps in Detach of the Main Parts I. Castor Steps in detach of the castor in accordance with the below steps. II. Actuator Steps in detach of the actuator in accordance with the below steps. (A~B) 1. Before you disassemble the actuator from main structure, you should pull out the plug of actuator from control box.
We reserve the right to make technical changes within the bounds of further development of the hospital beds covered in this service manual. Any alteration, modification, or repair unless performed by, or authorized in writing by Peak Care Innovation Pty Ltd will void this warranty.
Check joints between sleeping surface sections for loose fasteners. III. Cleaning Use mild soap and water or a non-abrasive hospital-grade detergent disinfectant to clean the bed. Wet a cloth with the cleaning product and wring dry. Then gently wipe off the bed. 1.
Chapter 6: Troubleshooting & Spare parts Troubleshooting If you are experiencing any of the following symptoms, please check the following table. The table may help you and indicate how to solve these malfunctions. If, after consulting this table, you are still unable to solve your problem, please contact your dealer as soon as possible.
Page 26
1. Before carrying out any troubleshooting, please ensure that the battery is charged and the bed is connected to the mains supply (power plug inserted to an outlet which is live.). 2. Before starting any repair work, please make sure to disconnect the bed from the mains supply and to separate the battery pack, if necessary.
Spares Parts List Item Part No. Description Picture 4” (100mm) E099 Braking Castor Head SS888-SF(B)001-01 Board SS888-SF(B)002-01 Foot Board Steel bed SS888-BPA(B)001-01 plate (A) Steel bed SS888-BPC(B)001-01 plate (C) Steel bed SS888-BPD(B)001-01 plate (D)
Page 28
Timotion Hand Set TA7-2Q-250425-25122-01015-4 Timotion Head Rest TA1-2Q-400598-253220-01016-4 Actuator Timotion Hi-Lo TA7-2Q-100275-25122-21015-4 Actuator Knee Timotion 220~240 V(AC) Break TC1-3342-1230-20 Actuator Control Timotion 220~240 V(AC) TC1-3342-1230-20 Battery Aluminum GRA-BOM-S1-Y-P Collapsible Side Rail...
