Summary of Contents for Inova FireFly DR31
- Page 1 ® FireFly DR31 Field Operations Quick Reference Guide for FCC Use Release 3.0 100-500nn Rev. A November 2011...
- Page 2 Limited. Copyright violators also may be subject to civil penalties. INOVA Geophysical makes no warranties as to the accuracy, validity, or fitness for use or application of the contents of this document. INOVA reserves the right to revise the information in this document at any time without notice. Although an attempt has been made to ensure the accuracy of the following material, no respon- sibility is assumed by ION for any use, or for any consequences resulting from any use, of the information contained herein.
-
Page 3: Table Of Contents
Contents NavTool Start Up....................................7 NavTool Point Selection...................................8 NavTool Map....................................9 Receiver Station Equipment ................................11 Task – Layout/Deployment (SVSM)..............................12 Task – Layout/Deployment (GDU/Geophone String)........................13 Task – Battery Swap ..................................14 Task – Pickup....................................15 Task – QC .......................................16 Task – Troubleshoot ..................................17 Task – Shooting ....................................18 Task –... - Page 4 FireFly Field Operations Quick Reference Guide This device complies with Part 15 of the FCC and RSS210 Issue 8 rules. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
- Page 5 Warning RF Exposure Compliance The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 120 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
- Page 6 FireFly Field Operations Quick Reference Guide...
-
Page 7: Navtool Start Up
NavTool Start Up Turn on NavTool and click Start NavTool. Select Language, Crew and Operator, and Continue. If messages appear, read and tap OK. Tap Close to show map. FireFly Field Operations Quick Reference Guide... -
Page 8: Navtool Point Selection
FireFly Field Operations Quick Reference Guide NavTool Point Selection From the main Menu select Points. Select the points to add then tap • All for all points on a given line to add points. • Range for a range of points (select the first and last Tap Line to display the list of lines. -
Page 9: Navtool Map
NavTool Map • The Map/Navigation screen shows you the direction and Zoom in and out by tapping + and -. distance to your next task. It also shows hazards/exclusions, • Pan the map by dragging your finger across the screen. nearby roads and buildings, etc. - Page 10 FireFly Field Operations Quick Reference Guide No Permit The NavTool allows you to override a point that is currently • To add a range of points, select the first and last point set as No-Permit. in the range (the selection will turn black). •...
-
Page 11: Receiver Station Equipment
Receiver Station Equipment SVSM Station GDU Station From Left to Right: From Left to Right: GDU (connected to String) SVSM FSU w/Antenna FSU w/Antenna Battery Battery FireFly Field Operations Quick Reference Guide... -
Page 12: Task - Layout/Deployment (Svsm)
FireFly Field Operations Quick Reference Guide Task – Layout/Deployment (SVSM) Locate Station using NavTool map. Place Pole on Sensor. Auger hole and Plant SVSM. (NavTool)Tap Layout, then Fix, then Connect FSU, then Transmit. Connect Equipment in this order: (NavTool) Tap Next Point. ensor (SVSM) ntenna ower (Battery) -
Page 13: Task - Layout/Deployment (Gdu/Geophone String)
Task – Layout/Deployment (GDU/Geophone String) Locate Station using NavTool map. (NavTool)Tap Layout, then Fix, then Connect FSU, then Transmit. Plant geophone array. (NavTool) Tap Next Point. Connect Equipment in this order: ensor (Geophone String to GDU and GDU to FSU) ntenna ower (Battery) FireFly Field Operations Quick Reference Guide... -
Page 14: Task - Battery Swap
FireFly Field Operations Quick Reference Guide Task – Battery Swap A Battery Swap is done with a Troubleshoot task. Unplug Old battery. Locate Station using NavTool map. Plug in New battery. (NavTool) Tap Troubleshoot. (NavTool) Tap Next Point. (NavTool) Tap Battery. -
Page 15: Task - Pickup
Task – Pickup Locate Station using NavTool map c. No FSU? - Tap No FSU. (NavTool) Tap Pickup. Disconnect Equipment in this order: ower (Battery) (NavTool) Confirm FSU ID: a. Match? - Tap FSU ID. ntenna b. No Match? - Tap Other FSU, and enter ID of FSU ensor (GDU then Geophone String, or SVSM) picked up. -
Page 16: Task - Qc
FireFly Field Operations Quick Reference Guide Task – QC Locate Station using NavTool map. (NavTool) Choose Download Type. a. Latest - Enter number of shots to download. Magnet Swipe FSU b. Shot ID - Enter First and Last shot IDs to download. (NavTool) Tap QC then Connect FSU. -
Page 17: Task - Troubleshoot
Task – Troubleshoot Locate Station using NavTool map. d. Antenna (Aerial) (NavTool) Tap Troubleshoot. Pickup? – If picking up all equipment tap Pickup to perform Pickup task. (NavTool) Select Equipment that was troubleshot or swapped. Redeploy? – If redeploy is required (indicated by ) tap Redeploy to perform Layout task. -
Page 18: Task - Shooting
FireFly Field Operations Quick Reference Guide Task – Shooting Locate Station using NavTool map. (NavTool) Wait for the following screens: • In Queue (NavTool) Tap Shoot then Fix above shothole. • Prepare to Arm Connect Firing line to cap lead. •... - Page 19 FireFly Field Operations Quick Reference Guide...
-
Page 20: Task - Wireline Sims
FireFly Field Operations Quick Reference Guide Task – Wireline Sims For Each Sim to be recorded (all traces on all vibes to Contact Observer to Run Sim(s). be tested): (NavTool) QC FSUs. For each FSU: a. Connect FSU to GDU. a. - Page 21 FireFly Field Operations Quick Reference Guide...
-
Page 22: Task - Drilling
FireFly Field Operations Quick Reference Guide Task – Drilling Locate Station using NavTool map. Tap Close to finish ShotLog entry. Drill shothole. Tap Done. (NavTool) Tap Drill then Fix above shothole. Review Drill Log. (NavTool) Tap Data Entry. Tap OK. >>...
