AV RECEIVER
TX-SR393
Instruction Manual
En
Table of contents
Connections
- Connecting Speakers
Playback
Setup
Troubleshooting
Appendix
Supplementary Information
Front Panel≫ Rear Panel≫ Remote≫
≫
≫
≫
≫
≫
≫
≫
≫

Advertisement

Table of Contents
loading

Related Manuals for Onkyo TX-SR393

Summary of Contents for Onkyo TX-SR393

  • Page 1 AV RECEIVER ≫ Table of contents TX-SR393 ≫ Connections Instruction Manual ≫ - Connecting Speakers ≫ Playback ≫ Setup ≫ Troubleshooting ≫ Appendix ≫ Supplementary Information Front Panel≫ Rear Panel≫ Remote≫...

  • Page 2: Table Of Contents

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ What’s in the box Connecting an AV Component in a Separate Room (ZONE B Connection) Additional Function (Firmware Update) Connecting a Pre-main Amplifier (ZONE B) Update Information of the firmware Connecting Antennas Operation of added new functions Connecting the Power Cord Firmware Update Procedure...

  • Page 3: Troubleshooting

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Input Formats and Selectable Listening Modes Setup Setup Menu Menu list Menu operations 1. Input/Output Assign 2. Speaker 3. Audio Adjust 4. Source 5. Hardware 6. Miscellaneous Quick Menu Menu operations Initial Setup with Auto Start-up Wizard Operations Troubleshooting When the unit is operating erratically...

  • Page 4: What's In The Box

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ What’s in the box 1. Main unit (1) 2. Remote controller (RC-970R) (1), Batteries (AAA/R03) (2) 3. Speaker setup microphone (1) • Used during Initial Setup. 4. Indoor FM antenna (1) 5. AM loop antenna (1) •...

  • Page 5: Additional Function (Firmware Update)

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Additional Function (Firmware Update) This unit is equipped with a function to update the firmware via USB port when the firmware update is announced after purchase. This enables various functions to be added and operations to be improved.

  • Page 6: Firmware Update Procedure

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Firmware Update Procedure Approx. 30 minutes are required for updating. Existing settings are kept after Update updating. 1. Connect the USB storage device to your PC. 2. Download the firmware file from the our company's website to your PC and Disclaimer: The program and accompanying online documentation are furnished unzip.
  • Page 7 Contents Connections Playback Setup ≫ ≫ ≫ ≫ 6. Select "6. Miscellaneous" - "Firmware Update" - "Update via USB" with the Connect the USB storage device to an external power source if it has its own cursors in order, then press ENTER. power supply.

  • Page 8: Part Names

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Part Names Front Panel ❏ For details, see ( Front Panel≫ Rear Panel≫ Remote≫...
  • Page 9 Contents Connections Playback Setup ≫ ≫ ≫ ≫ ON/STANDBY button 2. MUSIC OPTIMIZER button: Turns on/off the MUSIC OPTIMIZER function that improves the quality of the compressed audio. 3. BLUETOOTH indicator: Lights up when this unit and a BLUETOOTH-enabled device are connected. 4.

  • Page 10: Display

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Display 1. Speaker/Channel display: Displays the output channel that corresponds to the selected listening mode. 2. Displays the audio output destination. A: Outputs audio only to the main room (ZONE A). B: Outputs audio only to the separate room (ZONE B). AB: Outputs audio to both the main room (ZONE A) and separate room (ZONE 3.

  • Page 11: Rear Panel

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Rear Panel ❏ For details, see ( p12) Front Panel≫ Rear Panel≫ Remote≫...
  • Page 12 Contents Connections Playback Setup ≫ ≫ ≫ ≫ 1. HDMI OUT jacks: Transmit video signals and audio signals with an HDMI cable connected to a TV. 2. HDMI IN jacks: Transmit video signals and audio signals with an HDMI cable connected to an AV component.

  • Page 13: Remote Controller

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Remote Controller ON/STANDBY button 2. Input selector buttons: Switches the input to be played.  3. Play buttons: Used for playback operation of a BLUETOOTH-enabled device. If the unit  is switched to "CEC MODE" using the MODE button, an HDMI CEC function-enabled AV ...

  • Page 14: Connections

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connections Connecting speakers Connecting the TV Connecting Playback Devices Connecting an AV Component in a Separate Room (ZONE B Connection) Connecting Antennas Connecting the Power Cord Front Panel≫ Rear Panel≫ Remote≫...

  • Page 15: Connecting Speakers

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connecting speakers You can select the layout of speakers to be installed from various patterns when using this unit. Use the following flow chart to select the speaker layout that suits your speakers and usage environment.

  • Page 16: Speaker Installation

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Speaker Installation „ 5.1 Channel System This is a basic 5.1 Channel System. Front speakers output the front stereo sound, and a center speaker outputs the sound of the center of the screen, such as dialogs and vocals.
  • Page 17 Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ 3.1.2 Channel System A 3.1.2 Channel System is a speaker layout consisting of a 3.1 Channel System that includes front speakers, center speaker and powered subwoofer, and added height speakers. Select the height speakers that suit your speakers and usage environment from the following three types. ❏...
  • Page 18 Contents Connections Playback Setup ≫ ≫ ≫ ≫ ❏ Front High Speakers Installation Example This is a 3.1-channel system consisting of front speakers, a center speaker, and a powered subwoofer, with the addition of front high speakers, a type of height speaker.
  • Page 19 Contents Connections Playback Setup ≫ ≫ ≫ ≫ ❏ Ceiling Speakers Installation Example This is a 3.1-channel system consisting of front speakers, a center speaker, and a powered subwoofer, with the addition of top middle speakers, a type of height speaker.
  • Page 20 Contents Connections Playback Setup ≫ ≫ ≫ ≫ ❏ Dolby Enabled Speakers (Dolby Speakers) This is a 3.1-channel system consisting of front speakers, a center speaker, and a powered subwoofer, with the addition of Dolby enabled speakers (front), a type Installation Example of height speaker.

  • Page 21: Speaker Connections And "Speaker Setup" Settings

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Speaker Connections and "Speaker Setup" Settings Connections „ (Note) Speaker Impedance Connect speakers with an impedance of 4 Ω to 16 Ω. If any of the speakers to be connected has an impedance of 4 Ω or more and less than 6 Ω, set "Speaker Impedance"...
  • Page 22 Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ Connect the Subwoofer a Subwoofer cable Connect a powered subwoofer with this unit using a subwoofer cable. Up to two powered subwoofers can be connected. The same signal is output from each SUBWOOFER PRE OUT jack.
  • Page 23 Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ 5.1 Channel System "Speaker Setup" settings during „ Initial Setup ( p80) Speaker Setup Speaker Channels 5.1 ch Subwoofer Height Speaker - - - Speaker Impedance 6 ohms or above Select how many speakers you have. Next ENTER •...
  • Page 24 Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ 3.1.2 Channel System "Speaker Setup" settings during „ Initial Setup ( p80) Speaker Setup Speaker Channels 3.1.2 ch Subwoofer Height Speaker Front High Speaker Impedance 6 ohms or above Select how many speakers you have. Next ENTER •...

  • Page 25: Speaker Combinations

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Speaker combinations • Up to two powered subwoofers can be connected in either combination. Speaker Channels FRONT CENTER SURROUND HEIGHT 2.1 ch 3.1 ch 4.1 ch 5.1 ch 2.1.2 ch 3.1.2 ch Front Panel≫...

  • Page 26: Connecting The Tv

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connecting the TV Connect this unit between a TV and AV component. Connecting this unit with the TV can output the video and audio signals of the AV component to the TV, or play the audio of the TV on this unit.

  • Page 27: To Arc Tv

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ To ARC TV If the TV supports the ARC (Audio Return Channel) function (*), use only the HDMI cable to connect with the TV. Use the ARC-compatible HDMI IN jack of the TV for connection.

  • Page 28: To Non-Arc Tv

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ To Non-ARC TV If the TV does not support the ARC (Audio Return Channel) function (*), connect an HDMI cable and digital optical cable. • If you use a cable set-top box, etc. connected to the input jack of this unit to watch TV (without using a TV’s built-in tuner), connection with a digital optical cable or analog audio cable is not required.

  • Page 29: Connecting Playback Devices

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connecting Playback Devices Connecting an AV Component with HDMI Jack Mounted This is a connection example of an AV component equipped with an HDMI jack. When connecting with an AV component that conforms to the CEC (Consumer Electronics Control) standard, you can use the HDMI CEC function (*) that enables linking with input selectors, etc.

  • Page 30: Connecting An Audio Component

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connecting an Audio Component This is a connection example of an audio component. Connect a CD player using a digital coaxial cable or analog audio cable. a Analog audio cable, b Digital coaxial cable Front Panel≫...

  • Page 31: Connecting An Av Component In A Separate Room (Zone B Connection)

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connecting an AV Component in a Separate Room (ZONE B Connection) Connecting a Pre-main Amplifier (ZONE B) While performing playback in the main room (ZONE A), you can enjoy 2-ch audio of the same source in the separate room (ZONE B) at the same time. Use an analog cable to connect the ZONE B LINE OUT jack of this unit and the LINE IN jack of the pre-main amplifier in the separate room.

  • Page 32: Connecting Antennas

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connecting Antennas Connect the antenna to this unit, and set up the antenna at the best position for listening while receiving radio signals. Attach the indoor FM antenna to the wall using push pins or adhesive tape. (European, (North Australian and...

  • Page 33: Connecting The Power Cord

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connecting the Power Cord Connect the power cord after all the connections are completed. a Power cord Front Panel≫ Rear Panel≫ Remote≫...

  • Page 34: Playback

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Playback AV Component Playback BLUETOOTH Playback ® Listening To the AM/FM Radio ZONE B Playback Convenience functions Listening Mode Front Panel≫ Rear Panel≫ Remote≫...

  • Page 35: Av Component Playback

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ AV Component Playback You can play the audio from AV components, such as Blu-ray disc players through this unit. Basic Operations Perform the following procedure when this unit is on. 1. Switch the input on the TV to the input connected to the unit. TV’s REMOTE 2.

  • Page 36: Bluetooth Playback

    If a password is requested, enter "0000". • This unit is displayed as "Onkyo TX-SR393 XXXXXX". • To connect another BLUETOOTH-enabled device, press and hold the BLUETOOTH button until "Now Pairing..." is displayed, and then perform step 2.

  • Page 37: Listening To The Am/Fm Radio

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Listening To the AM/FM Radio You can receive AM and FM radio stations on this unit with the built-in tuner. Tuning into a Radio Station Perform the following procedure when this unit is on. Tuning Automatically 1.
  • Page 38 Contents Connections Playback Setup ≫ ≫ ≫ ≫ When FM broadcasts reception is poor: Perform the procedure for "Tuning Manually" ( p38). Note that if you tune manually, the reception for FM broadcasts will be monaural rather than stereo, irrespective of the sensitivity of the reception.

  • Page 39: Presetting A Radio Station

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Presetting a Radio Station Registration Procedure You can preset up to 40 of your favorite AM/FM radio stations. After tuning in to the AM/FM radio station you want to register, perform the following procedure.
  • Page 40 Contents Connections Playback Setup ≫ ≫ ≫ ≫ Selecting a Preset Radio Station 1. Press TUNER. 2. Press the cursors to select a preset number. Deleting a Preset Radio Station 1. Press TUNER. 2. Press the cursors to select the preset number to delete. 3.

  • Page 41: Using Rds (European, Australian And Asian Models)

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Using RDS (European, Australian and Asian models) RDS stands for Radio Data System, and is a method of transmitting data in FM • If no stations are found, the message "Not Found" is displayed. radio signals.

  • Page 42: Zone B Playback

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ ZONE B Playback While performing playback in the main room (ZONE A), you can enjoy the audio of the same source in the separate room (ZONE B) at the same time. Playing Back 1.
  • Page 43 Contents Connections Playback Setup ≫ ≫ ≫ ≫ If "ZONE A+B" is selected as an audio output destination, you can select only the "Stereo" listening mode for the main room (ZONE A) when using the 2.1ch speaker layout. When using a speaker layout of 3.1ch or more, you can select only the "AllCh Stereo"...

  • Page 44: Convenience Functions

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Convenience functions Adjusting the tone Adjusting TREBLE/BASS You can adjust the sound quality of the front speakers. 1. Press TREBLE or BASS to select the setting to adjust. TREBLE: Enhances or moderates the high-tone range of the front speakers. BASS: Enhances or moderates the low-tone range of the front speakers.

  • Page 45: Sleep Timer

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Sleep Timer You can allow the unit to enter standby automatically when the specified time has elapsed. Press SLEEP button on the remote controller to select the time from "30 min", "60 min"...

  • Page 46: Listening Mode

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Listening Mode This unit is equipped with a variety of listening modes, and you can select the optimum listening mode by pressing STEREO, MOVIE/TV or MUSIC. Selecting a Listening mode 1. Press one from among STEREO, MOVIE/TV and MUSIC during playback. 2.
  • Page 47 Contents Connections Playback Setup ≫ ≫ ≫ ≫ Checking the input format and listening mode Pressing button on the remote controller or INFO button on the main unit repeatedly will switch the display of the main unit in the following order. •...

  • Page 48: Speaker Layouts And Selectable Listening Modes

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Speaker Layouts and Selectable Listening Modes See the following table for selectable listening modes for each speaker layout. Speaker layout Listening mode 2.1 ch 3.1 ch 4.1 ch 5.1 ch 2.1.2 ch 3.1.2 ch DD (Dolby Audio - DD) (*1)
  • Page 49 Contents Connections Playback Setup ≫ ≫ ≫ ≫ Speaker layout Listening mode 2.1 ch 3.1 ch 4.1 ch 5.1 ch 2.1.2 ch 3.1.2 ch (*2) DTS 96/24 (*2) DTS-HD HR (DTS-HD High Resolution) DTS-HD Master (DTS-HD Master Audio) DTS Express DTS:X DTS Neural:X DTS Virtual:X...

  • Page 50: Listening Mode Effects

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Listening Mode Effects Updating of listening modes Atmos „ Listening modes such as Atmos 2.0 and DSur 2.0 are added when the (Firmware version supporting Atmos 2.0, etc.) firmware is updated after purchase or the firmware is switched in the product Since this mode calculates the positional data of audio recorded in Dolby Atmos production process.
  • Page 51 Contents Connections Playback Setup ≫ ≫ ≫ ≫ format for DVD-Video and Blu-ray Discs. It is possible to record a maximum of – DSur 4.0/4.1: When front speakers and surround speakers are installed 5.1 channels on a DVD-Video or Blu-ray Disc; two front channels, one center –...
  • Page 52 Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ DTS-HD MSTR (DTS-HD Master Audio) bass region (sound elements for the subwoofer). The content is recorded with a rich volume of data, with a maximum sampling rate of 48 kHz, at a resolution of This mode faithfully reproduces the sound design recorded in the DTS-HD 24 bits and a bit rate of 1.5 Mbps.
  • Page 53 Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ Studio-Mix • To enable transfer of this audio format, connect via an HDMI cable and set audio output on the player to Bitstream output. This mode is suitable for rock or pop music. This mode creates a lively sound „...
  • Page 54 Contents Connections Playback Setup ≫ ≫ ≫ ≫ Input Formats and Selectable Listening Modes „ MOVIE/TV button You can select a variety of listening modes Input Format Listening Mode according to the audio format of the signal to be Direct input.
  • Page 55 Contents Connections Playback Setup ≫ ≫ ≫ ≫ Input Format Listening Mode Input Format Listening Mode Input Format Listening Mode Multich PCM Direct Atmos Direct Direct Multich Atmos *1 *2 *3 DSur TV Logic DSur DTS Neural:X AllCh Stereo TV Logic DTS Virtual:X Full Mono AllCh Stereo...
  • Page 56 Contents Connections Playback Setup ≫ ≫ ≫ ≫ Input Format Listening Mode Input Format Listening Mode Input Format Listening Mode Direct DTS Express Direct DTS-HD MSTR Direct DTS Express DTS-HD MSTR *1 *2 *1 *2 *1 *2 DTS Neural:X DTS Neural:X DTS Neural:X DTS Virtual:X DTS Virtual:X...
  • Page 57 Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ MUSIC button Input Format Listening Mode Input Format Listening Mode DTS:X Direct Multich PCM Direct Input Format Listening Mode DTS:X Stereo Analog Direct Multich DTS Virtual:X *1 *2 Stereo TV Logic DSur DSur AllCh Stereo...
  • Page 58 Contents Connections Playback Setup ≫ ≫ ≫ ≫ Input Format Listening Mode Input Format Listening Mode Input Format Listening Mode Direct Direct DTHD Direct Stereo Stereo Stereo DTHD *1 *2 *1 *2 *1 *2 DSur DSur DSur DTS Neural:X Orchestra Orchestra DTS Virtual:X Unplugged...
  • Page 59 Contents Connections Playback Setup ≫ ≫ ≫ ≫ Input Format Listening Mode Input Format Listening Mode Input Format Listening Mode Direct DTS Express Direct DTS-HD MSTR Direct Stereo Stereo Stereo DTS Express DTS-HD MSTR *1 *2 *1 *2 *1 *2 DTS Neural:X DTS Neural:X DTS Neural:X...
  • Page 60 Contents Connections Playback Setup ≫ ≫ ≫ ≫ Input Format Listening Mode DTS-ES Direct Stereo DTS Neural:X DTS Virtual:X *1 *2 Orchestra Unplugged Studio-Mix AllCh Stereo Full Mono Cannot be selected if "Speaker Virtualizer" is set to "Off". Cannot be selected when height speakers are installed. Surround speakers or height speakers need to be installed.
  • Page 61 Contents Connections Playback Setup ≫ ≫ ≫ ≫ Setup Menu Menu list p63) You can configure advanced settings to have a more enjoyable experience with this unit. For operation details, refer to "Menu operations". ( 1. Input/Output 1. TV Out / OSD Make settings for TV output and On-Screen Displays (OSD) that appear on the TV.
  • Page 62 Contents Connections Playback Setup ≫ ≫ ≫ ≫ 5. Hardware 1. HDMI Change the settings for the HDMI functions. 2. Bluetooth Change the settings for the Bluetooth function. 3. Power Management Change the settings for the power-save function. 6. Miscellaneous 1.
  • Page 63 Contents Connections Playback Setup ≫ ≫ ≫ ≫ Menu operations Use the on-screen displays (OSD) that appear on the TV to make the settings. Press on the remote controller to display the Setup menu. Setup 1. Input/Output Assign 1. TV Out / OSD 2.
  • Page 64 Contents Connections Playback Setup ≫ ≫ ≫ ≫ 1. Input/Output Assign Setting Item Default Value Setting Details Mini Player OSD Always On You can display on the TV the images from another „ 1. TV Out / OSD input selected last while playing the audio from BLUETOOTH input.
  • Page 65 Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ 2. HDMI Input Setting Item Default Value Setting Details "HDMI 1" to "HDMI 4": Assign a desired HDMI IN Change input assignment between the input selectors and HDMI IN jacks. jack to the TV button. If you do not assign a jack, select "---".
  • Page 66 Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ 3. Digital Audio Input „ 4. Analog Audio Input Change input assignment between the input selectors and DIGITAL IN COAXIAL/ Change input assignment between the input selectors and AUDIO IN jacks. If you OPTICAL jacks.
  • Page 67 Contents Connections Playback Setup ≫ ≫ ≫ ≫ 2. Speaker „ 2. Crossover Change the settings of crossover frequencies. „ 1. Configuration Setting Item Default Value Setting Details Change the settings of connection environment of the speakers. Front 100 Hz Select the crossover frequency from "40 Hz"...
  • Page 68 Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ 3. Distance Setting Item Default Value Setting Details Surround 100 Hz Select the crossover frequency from "40 Hz" to Set the distance from each speaker to the listening position. "200 Hz" to start outputting frequencies for each channel.
  • Page 69 Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ 4. Level Calibration „ 5. Dolby Enabled Speaker Adjust the volume level of each speaker. Change the settings of Dolby Enabled Speakers. Setting Item Default Value Setting Details Setting Item Default Value Setting Details Front Left 0 dB...
  • Page 70 Contents Connections Playback Setup ≫ ≫ ≫ ≫ 3. Audio Adjust „ 3. DTS Change the setting of when DTS signals are input. „ 1. Multiplex/Mono Setting Item Default Value Setting Details Change the settings of multiplex audio playback. DTS Auto When inputting DTS signals that include extended Surround channel information, the optimum listening mode is...
  • Page 71 Contents Connections Playback Setup ≫ ≫ ≫ ≫ 4. Source „ 5. Volume Change the Volume settings. „ 1. IntelliVolume Setting Item Default Value Setting Details Adjust the volume level when there are differences in volume level among multiple Mute Level -∞...
  • Page 72 Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ Audio Select Setting Item Default Value Setting Details PCM Fixed Mode Select whether to fix input signals to PCM (except Select the priority for input selection when multiple audio sources are connected multi-channel PCM) when you select "HDMI", to one input selector, for example, connections to both the "BD/DVD"...
  • Page 73 Contents Connections Playback Setup ≫ ≫ ≫ ≫ 5. Hardware Setting Item Default Value Setting Details HDMI Standby When this is set to anything other than "Off", „ 1. HDMI Through you can play the video and audio of an HDMI- connected player on the TV even if the unit is in Change the settings of the HDMI function.
  • Page 74 Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ 2. Bluetooth Setting Item Default Value Setting Details Audio TV Out You can enjoy audio through the speakers of the Change the settings for the Bluetooth function. TV while this unit is on. "On": When this function is used Setting Item Default Value...
  • Page 75 Contents Connections Playback Setup ≫ ≫ ≫ ≫ Setting Item Default Value Setting Details Setting Item Default Value Setting Details Auto Standby On/Off This setting allows the unit to enter standby mode Pairing You can initialize the pairing information stored on automatically after 20 minutes of inactivity without Information this unit.
  • Page 76 Contents Connections Playback Setup ≫ ≫ ≫ ≫ 6. Miscellaneous „ 1. Tuner Change the frequency step for the tuner. Setting Item Default Value Setting Details AM/FM 10 kHz/0.2 MHz Select a frequency step to suit your residential Frequency Step area.
  • Page 77 Contents Connections Playback Setup ≫ ≫ ≫ ≫ Quick Menu Menu operations You can quickly adjust the settings you frequently use, such as tone adjustments, etc. You can make the settings on the TV screen during playback. Press Q on the remote controller to display the Quick Menu.
  • Page 78 Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ Audio Subwoofer: Adjust the speaker level of the subwoofer while listening to the sound. Music Optimizer: Improve the quality of the compressed audio. Playback sound • If you set the unit to the standby mode, the adjustments you made will be of lossy compressed files such as MP3 will be improved.
  • Page 79 Contents Connections Playback Setup ≫ ≫ ≫ ≫ Initial Setup with Auto Start-up Wizard Operations When you turn the unit on for the first time after purchase, the Initial Setup screen is automatically displayed on the TV to allow you to make settings required for TV’s REMOTE startup using simple operations following on-screen guidance.
  • Page 80 Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ 1. Speaker Setup • If the power of this unit suddenly turns off, the wires in the speaker cables have touched the rear panel or other wires, and the protection circuit is 1.
  • Page 81 Contents Connections Playback Setup ≫ ≫ ≫ ≫ Troubleshooting „ Tuner „ BLUETOOTH function Before starting the procedure „ ZONE B function Problems may be solved by simply turning the power on/off or disconnecting/ „ Remote Controller connecting the power cord, which is easier than working on the connection, setting and operating procedure.

  • Page 82: When The Unit Is Operating Erratically

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ When the unit is operating erratically ❏ Try restarting the unit Restarting this unit may solve the problem. After turning the unit to standby mode, press and hold the ON/STANDBY button of the main unit for at least 5 seconds, and then restart the unit.

  • Page 83: Troubleshooting

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ Troubleshooting „ Power ❏ When the power is turned on, "AMP Diag Mode" appears on the display of the main unit. • The protection circuit function may have operated. If the unit suddenly enters the standby state and "AMP Diag Mode" appears on the display of the main unit when the power is turned on again, this function is diagnosing whether or not the main unit is malfunctioning or there is an abnormality with the speaker cable connection.
  • Page 84 Contents Connections Playback Setup ≫ ≫ ≫ ≫ ❏ No sound from the TV • Change the input selector on this unit to the position of the terminal to which the TV is connected. • If the TV does not support the ARC function, along with the connection by an HDMI cable, connect the TV with this unit using a digital optical p28) cable.

  • Page 85: X84; Listening Modes

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ ❏ The beginning of audio received by an HDMI IN cannot be heard • Since it takes longer to identify the format of an HDMI signal than it does for other digital audio signals, audio output may not start immediately. ❏...

  • Page 86: X84; Video

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ Video • Confirm that the connection between the output jack on the connected device and the input jack on this unit is correct. • Make sure that none of the connecting cables are bent, twisted, or damaged. •...

  • Page 87: X84; Tuner

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ Tuner ❏ Poor reception or much noise • Recheck the antenna connection. p32) • Move the antenna away from the speaker cord or power cord. • Move the unit away from your TV or PC. •...

  • Page 88: X84; Zone B Function

    Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ ZONE B function ❏ Cannot ZONE B-output the audio of externally connected AV components • To output audio to ZONE B, set the audio output destination to "ZONE A+B" or "ZONE B". p42) „...
  • Page 89 Maximum 7.1 channels, 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, Operation has been confirmed on the following devices: (As of January 2019) 192 kHz, 16/20/24 bit Toshiba brand televisions; Sharp brand televisions; Onkyo and Integra brand Bitstream: RIHD-compatible players; Toshiba brand players and recorders; Sharp brand...
  • Page 90 Contents Connections Playback Setup ≫ ≫ ≫ ≫ Supported resolutions HDMI IN1 to IN4: • Copyright protection technology: HDCP1.4/HDCP2.2 • Color space (Color Depth): – 720×480i 60 Hz, 720×576i 50 Hz, 720×480p 60 Hz, 720×576p 50 Hz, 1920×1080i 50/60 Hz, 1280×720p 24/25/30/50/60 Hz, 1680×720p 24/25/30/50/60 Hz, 1920×1080p 24/25/30/50/60 Hz, 2560×1080p 24/25/30/50/60 Hz, 4K (3840×2160p) 24/25/30 Hz, 4K SMPTE (4096×2160p) 24/25/30 Hz : RGB/YCbCr4:4:4 (8/10/12 bit), YCbCr4:2:2 (12...
  • Page 91 Contents Connections Playback Setup ≫ ≫ ≫ ≫ General Specifications „ Amplifier Section Speaker Impedance 4 Ω - 16 Ω Rated Output Power (FTC) (North American) Headphone Rated Output With 8 ohm loads, both channels driven, from 20-20,000 Hz; rated 80 watts 80 mW + 80 mW (32 Ω, 1 kHz, 10% THD) per channel minimum RMS power, with no more than 0.08% total harmonic Supported impedance of Headphones...
  • Page 92 Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ HDMI Supported Codecs Input IN1 (BD/DVD), IN2 (GAME), IN3 (CBL/SAT), IN4 (STRM BOX) Transmission range (A2DP) Output 20 Hz - 20 kHz (Sampling frequency 44.1 kHz) Maximum communication range Supported Line of sight approx. 15 m (*) Audio Return Channel, 3D, 4K 60 Hz, 6G, HDR10, BT.2020, HLG, Dolby * The actual range will vary depending on factors such as obstacles between Vision, Auto Lip Sync, CEC...
  • Page 93 Contents Connections Playback Setup ≫ ≫ ≫ ≫ „ Audio Outputs Analog ZONE B LINE OUT 2 SUBWOOFER PRE OUT Speaker Outputs FRONT L/R (North American models support banana plugs.), CENTER, SURROUND L/R Phones PHONES (Front, ø 6.3 mm, 1/4") „...
  • Page 94 SN 29403602A_EN (C) Copyright 2019 Onkyo & Pioneer Corporation Japan. All rights reserved. H1903-1...
