Summary of Contents for Apevia Signature Series
-
Page 2: Table Of Contents
CONTENTS 1. Product Features………………………………..………………..….2 2. Product Specifications……..………………………………………3 3. Overall Performance………………………………………………..4 4. Protections…………………………………………………….………..4 5. Dimensions……….……………………………………………………..5 6. Cables & Connectors………………………………………………..5 7. Precautions………………………………………………………………6 8. Information………………………………………………………………7 9. Installation………………………………………………….……………7 10. Troubleshooting….………………………………………………….8... -
Page 3: Product Features
1. Product Features a. Stable and reliable b. Cosmic black casing c. Supports single 12v output for higher power usage d. Supports ATX 12v 2.3 version e. Supports Dual/Quad Core CPUs f. Hybrid modular design allows you to use only the cables you need. You get a cleaner look and unobstructed airflow for your PC system. -
Page 4: Product Specifications
2. Product Specifications: a. AC input voltage: 115-230V b. AC input frequency: 60Hz/50Hz c. Operating temperature: The power supply should be operated in an ambient temperature of 0°C to 40°C d. DC output: Model 900W Signature Power AC Input 115-230VAC , 8A/4A , 50-60HZ DC Output Voltage +3.3V +12V... -
Page 5: Protections
4. Protections: a. Under voltage protection. If an under voltage fault occurs, the supply will latch all DC outputs into a shutdown state when +12V,+5V & +3.3V outputs under 60% of its maximum value. b. Over voltage protection Output Minimum Nominal Maximum Unit... -
Page 6: Dimensions
5. Dimensions: 150mm x 158mm x 86mm (5.9” x 6.2” x 3.4”) W x L x H 6. Description of Connectors:... -
Page 7: Precautions
(USA & Canada: 115V; Europe, Central and South America: 230V). c. Avoid exposure to humidity. 8. Information: Thank you for purchasing a high-quality Apevia product! Please visit our website at http://www.apevia.com for complete warranty information and future support for your product. For the latest release information, or should you have any questions,... -
Page 8: Installation
9. Installation:... -
Page 9: Troubleshooting
10. Troubleshooting: If power supply fails to operate properly, please check the following before requesting for an RMA: a. Please make sure the power supply and power cord are connected properly. b. Please make sure the power cord is plugged into the power socket. c.
