Sensor Replacement and Reuse
Scenarios
This section describes sensor replacement and reuse
scenarios for replacing a VMA1410, VMA1415, VMA1420,
or the VMA controller with VMA18 controllers.
Table 3: Sensor Replacement and Reuse Scenarios
Sensor Used With VMA1410,
VMA1415, VMA1420, VMA1440
Controller
TE-6xxx Series (see TE-6xxx Series
Sensor Connected to VMA
AP-TMZ1600-0 (see Replacing an
AP-TMZ1600-0 Sensor Connected to a
VMA Controller)
TE-7710-0 Series Wireless Transmitter
and TE-7720-0 Wireless Receiver (see
Replacing a TE-7710-0 Series Wireless
Transmitter and TE-7720-0 Wireless
Receiver Connected to a VMA
TE-700 Series (see TE-700 Series Sensor
Connected to a VMA Controller)
Sensor Replacement Scenario
Descriptions
TE-6xxx Series Sensor Connected to
VMA Controller
To replace a TE-6xxx Series Sensor with a functionally
equivalent NS Series Network Sensor, follow the
instructions in the Replacing a TE-6xxx Series Sensor
section.
To reuse a TE-6xxx Series Sensor connected to a VMA
controller, follow the instructions in the
Series Sensor section.
VMA1826/1832 VAV Controller Installation Instructions
Sensor Replacement and Reuse
Scenarios
Replace a sensor with an NS Series
Controller) Sensor
Note: Replacing a TE-6xxx Series
Sensor is recommended over
reusing the sensor because it
provides a usable port at the
sensor location for
commissioning.
Reuse a sensor, installing an adapter at
a VMA controller location
Replace a sensor with an NS Series
Sensor
Replace with a WRZ Series Wireless
Sensor and a WRZ7860 Series
One-to-One Receiver
Controller)
Replace a sensor with a TE-730 Series
Sensor
Reuse a sensor
Reusing a TE-6xxx
See Table 3 for a description of the most popular sensor
models used with the VMA1410, VMA1415, VMA1420,
and the VMA controllers, the sensor replacement and
reuse scenarios for that sensor model, and sensor
replacement and reuse instructions.
Important: Complete all the steps in the
section before following the instructions in
this section.
Instructions
Replacing a TE-6xxx Series Sensor
Reusing a TE-6xxx Series Sensor
Replacing an AP-TMZ1600-0 Sensor
Connected to a VMA Controller
Replacing a TE-7710-0 Series Wireless
Transmitter and TE-7720-0 Wireless
Receiver Connected to a VMA Controller
Replacing a TE-700 Series Sensor
Reusing a TE-700 Series Sensor
Replacing the sensor with an NS Series Network
Sensor is preferred to reusing the TE-6xxx Series
Sensor because the NS sensor allows for easier
controller commissioning. Be sure to use an NS sensor
with similar dimensions as the existing sensor in order to
match the original sensor installation.
Note: If temporary occupancy is required for the
application on the TE-67xx and TE-68xx Series
Sensors, set the DIP switch positions on the back
of the sensor to down, up, and down. This setting
only applies to single and no setpoint controller
models (not dual setpoint controller models).
Refer to the NS Series Network Sensors Product Bulletin
(LIT-12011574) for a complete list of available NS Series
Network Sensors.
Mounting
