Summary of Contents for Quanta Microsystems UWA-C4Z
- Page 1 User Manual USB Wireless Adapter Model No.: UWA-C4Z Version: v0.3 Date: Feb 09, 2012...
- Page 2 Contents Revision History ....................... 4 Related Documents ......................4 Overview ........................... 5 3.1. Scope........................5 3.2. Features ........................5 3.3. Specification ......................6 3.4. Interface definition....................7 RoHS & Green Parter Compliant ................7 EMI EMC certifications..................7...
- Page 3 Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 4 This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Ce dispositif est conforme à...
- Page 5 Revision History Date Release Author Description Apr 13, 2011 Jack Ong First release Feb 06, 2012 Jack Ong Added Engineering Sheet Feb 09, 2012 Jack Ong Added Housing drawing Related Documents Date Author Document(s)
- Page 6 Overview 3.1. Scope This document describes specifications ZU210 IEEE 802.15.4 RF4CE ZigBee transceivers module. power consumption and smaller size are suitable for consumer electronic. ZU210 also provides a cost-effective solution for short-range data links and networks. 3.2. Features Extremely low cost Ease of implementation Reliable data transfer Short range operation...
- Page 7 3.3. Specification Absolute Maximum Ratings Rating Symbol Value Unit Power Supply Voltage -0.3 to 5.5 BATT DDINT Storage Temperature Range Tstg -20 to 70 °C Operating condition Rating Symbol Unit Power Supply Voltage BATT DDINT Operation Temperature Rang °C Operation Frequency 2.405 2.475 Characteristic (operating voltage=V...
- Page 8 3.4. Interface definition Connector 4-PIN Pin Name 3.5. RoHS & Green Parter Compliant ZU210 is fully compliant to RoHS & Green Parter requirement. 3.6. EMI EMC certifications ZU210 is fully compliant with FCC regulatory requirements.
