- Page 1 SLE111GW Application Gateway User Manual Dec. 2013...
-
Page 2: Table Of Contents
Table of Contents INTRODUCTION ......................1 .......................... 1 EATURES ......................1 ACKAGE ONTENTS HARDWARE ........................ 2 ........................2 RONT ANEL ........................3 ANEL CONNECTION......................4 ......................4 ONNECTION ........................4 YSTEM OGIN APPENDIX A. HARDWARE SPECIFICATIONS ..............5 APPENDIX B. COMPLIANCES ..................6... -
Page 3: Introduction
1 Introduction The SLE111 is an integrated gateway for power and sensors data collection and transmission. Features Offering the total visibility and detail analysis data on the energy consumption status with clear and intuitive reports Offering automatic control on office equipments, appliances and devices by both user remote control and automatic scheduler settings Offering monitoring policy to manage equipments, appliances, and devices more efficiently, while providing electrical usage safety... -
Page 4: Hardware
2 Hardware The Gateway connects to the broadband modem (Cable/DSL) using its RJ-45 WAN port. It connects directly to your PC or to a local area network using its RJ-45 Fast Ethernet LAN ports. The Gateway includes an LED display on the front panel for system information display, and LEDs for system status and touch buttons for system modes changing. -
Page 5: Rear Panel
Rear Panel Antennas Ethernet Port 0-2 Power Switch DC Jack Name Description Connecter for a power adapter. This Gateway requires a DC 12V adapter of 12VDC/ 1.5A~2A. Power Switch Switch to power on/off the Gateway. Port 0 For engineer troubleshooting purpose only. For connect to a broadband router to build Internet connection. -
Page 6: Connection
3 Connection The Gateway offers a user-friendly web-based management interface for the configuration of all the unit’s features. Any PC directly attached to the unit can access the management interface using a web browser, such as Internet Explorer, Firefox, Chrome, and etc. Hard Connection Connect your broadband modem (Cable/DSL) to Ethernet port 1 on the Gateway. -
Page 7: Appendix A. Hardware Specifications
Appendix A. Hardware Specifications ZigBee Pro standard IEEE 802.15.4 compliant, 2.4GHz Ethernet: RJ-45 10BaseT/100BaseTX x 3 USB 2.0 x 2, 1 @internal & 1 @front Antenna x 2 LED Panel LED Indicator x 3 Function Touch Button x4 Power Switch Button Power Supply: 12V DC external power adapter Input: 100 ~ 240VAC Output: 12V DC, 1.5 ~ 2A... -
Page 8: Appendix B. Compliances
Appendix B. Compliances FCC Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against radio interference in a commercial environment. This equipment can generate, use and radiate radio frequency energy and, if not installed and used in accordance with the instructions in this manual, may cause harmful interference to radio communications. - Page 9 IMPORTANT NOTE: FCC RADIATION EXPOSURE STATEMENT This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
