Summary of Contents for BitaTek NX1-UMTS
- Page 1 2013 NX1‐UMTS Quick Guide V1.2 Handheld Group AB 2013/10/30...
-
Page 2: Technical Specifications
512MB DDR2 SDRAM (EDB816B3PF-8D), upgradable to 1GB. Camera 5M pixels CMOS color camera with MIPI interface. Battery Type：Li-Ion Type：Li-Ion Capacity：1530mAh Capacity：3060mAh Show Screen Size：4" Resolution：800 x 480 Type：Capacitive Wireless Communications WLAN WCDMA、GSM Bluetooth：V2.1 EDR aGPS, geotagging support BitaTek Co. Ltd. - Page 3 USB cover：USB rubber cover must completely pushed to meet IP67 standards Headphone cover：Headphone rubber cover must completely pushed to meet IP67 standards Prevention of Hearing Loss To prevent possible hearing damage, do not listen at high volume levels for long periods. ：Return to the previous work BitaTek Co. Ltd.
- Page 4 As shown, install SIM / memory card and battery. Step 1：Open the back cover Micro SD card SIM card inserting installation Step 2：Insert the SIM card and micro SD card. (Docking Connector is on down side) 1530mAh Step 3：Install the Battery. BitaTek Co. Ltd.
- Page 5 Step 4：Install the back cover. Do not open the phone insert or remove a SIM card. Doing so may be the SIM card or the phone cause permanent damage. Press battery cover must get click sound to ensure IP67 BitaTek Co. Ltd.
-
Page 6: Battery Charging
Insert the micro USB Method 4：Charging eight hours for 1st time use empty battery Low power Positive charging is completed Charging 1. The operating temperature is from -20℃~ 60℃ for NX1-UMTS. 2. The charging temperature is from 0℃~ 40℃. BitaTek Co. Ltd. - Page 7 NX1-UMTS Regulatory Information ****************************************************************************** CE RF Exposure Compliance This device meets the EU requirements (1999/519/EC) on the limitation of exposure of the general public to electromagnetic fields by way of health protection. The limits are part of extensive recommendations for the protection of the general public. These recommendations have been developed and checked by independent scientific organizations through regular and thorough evaluations of scientific studies.
- Page 8 15 mm between this device and your body. RF exposure compliance with any of body-worn accessory, which contains metal, was not tested and certified, and use such body-worn accessory should be avoided. **************************************************************************************************************************** BitaTek Co. Ltd.
