Savi Technology SMR-650P-210 Quick Reference Manual

Mobile reader
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Quick Reference Guide
Savi Mobile Reader SMR-650P-210
and SMR-650P-211
Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMR-650P-210 and is the answer not in the manual?

Questions and answers

Summary of Contents for Savi Technology SMR-650P-210

  • Page 1 Quick Reference Guide Savi Mobile Reader SMR-650P-210 and SMR-650P-211 Version 1.0...
  • Page 2 Savi, Savi SmartChain, SmartChain, and Batch Collection are registered trademarks, and EchoPoint, Savi GateReader, Savi MobileReader, Savi Retriever, SaviReader, SaviTag, Savi Technology, SmartSeal, UDAP, and Universal Data Appliance Protocol are trademarks of Savi Technology, Inc. Other product names mentioned in this guide may be trademarks or registered trademarks of their respective owners and are hereby acknowledged.

  • Page 3: Table Of Contents

    SMR-650P-211 Reader Components ..... . . 7 SMR-650P-210 Reader Components ..... . . 7 SMR-650P Reader Specifications .
  • Page 4 3 Connecting the SMR-650P Reader and Charging the Battery Connecting the SMR-650P Reader to the Symbol Handheld Device ........21 Batteries .

  • Page 5: Welcome

    Savi RFID tags. The SMR-650P-211 Reader has a customized Symbol cable and works with a Symbol 8100 or 8146 device to provide you with a standalone handheld reader. The SMR-650P-210 Reader has a DB-9 connector for use with a laptop or desktop PC.

  • Page 6: Other Information Resources

    C H A P T E R Welcome Other Information Resources Guides to Read Other documentation for the SMR-650P Reader includes: Handheld Reader Setup Procedure guide, available on a CD ◆ provided by the Savi Training Department. Savi SmartChain Mobile Manager Pocket Guide and the Savi ◆...

  • Page 7: Savi Mobile Reader Smr-650P And Handheld Device Description

    The case is included in the Savi Basic Handheld Mobile Reader Kit. You can purchase an additional carrying case as a separate accessory item. SMR-650P-210 Reader Components The following items are components of the SMR-650P-210 Reader: Rechargeable Lithium-Ion battery (internal and non-removable) ◆ AC adapter to recharge the mobile reader internal battery ◆...
  • Page 8 In this guide, when the model is not specifically mentioned, the information applies to both mobile reader models. For information about using the SMR-650P-210 Reader with PCs, refer to the Savi SmartChain Client Tools User Guide. Figure 2-2 SMR-650P-211 Reader with Symbol handheld device...

  • Page 9: Smr-650P Reader Specifications

    SMR-650P Reader Specifications SMR-650P Reader Specifications Specification Description Physical characteristics Length: 2.5 inches (6.4 cm) Width: 3.5 inches (8.9 cm) Height: 1 inch (2.5 cm) Weight: 4.8 ounces (136.08 grams) Environment Operating temperature: –4°F to +120°F (–20°C to +50°C) when operating from the internal battery; +32°F to +104°F (0°C to +40°C) when operating while being recharged Humidity: 5 to 95% non-condensing at +122°F (+50°C)
  • Page 10 Interfaces SMR-650P-211: Captive cable with Symbol proprietary boot interface. Cable is approximately 11.5 inches (29.21 cm) in length SMR-650P-210: Cable with Serial DB-9 interface. Cable is approximately 4.5 inches (11.43 cm) in length Antenna External UHF: Omni-directional Di-Pole antenna Integrated (LFT): Ferrite Core Shock and vibration Shock: Drop from 4 feet (1.22 meters) height on the...
  • Page 11 (Savi model number: HCC-650P-01) attaches the SMR-650P-211 Reader to a Symbol 8100 or 8146. Includes shoulder strap Options SMR-650P-210 with DB-9 connector for use with laptop and desktop PCs Software requirements SMR-650P-211 requires SmartChain Mobile Manager; SMR-650P-210 requires SmartChain Client Tools...

  • Page 12: Smr-650P Reader Communication

    C H A P T E R Savi Mobile Reader SMR-650P and Handheld Device Description SMR-650P Reader Communication The SMR-650P Reader has both ultra high frequency (UHF) and low frequency (LF) transmitters that communicate with all Savi RFID tags via the integrated antenna. Savi SmartChain Mobile Manager is Savi-provided software with the SMR-650P-211 Reader that you must install on your Symbol 8100 or 8146 handheld.

  • Page 13: Lf Mode Operation

    SMR-650P Reader Communication LF Mode Operation LF mode is controlled by the SmartChain Mobile Manager application running on the handheld device. LF mode is compatible only with SaviTags. To use LF mode, you must turn it on in SmartChain Mobile Manager. You use LF mode to: Disable the UHF mode of SaviTag ST-654 tags to prevent unwanted ◆...

  • Page 14: Optimizing The Smr-650P Reader

    C H A P T E R Savi Mobile Reader SMR-650P and Handheld Device Description Optimizing the SMR-650P Reader Tag Collection Range To optimize the SMR-650P Reader tag collection range, hold the device as shown in Figure 2-3. Parallel to the your body. ◆...
  • Page 15 Optimizing the SMR-650P Reader Tag Collection Range As shown in Figure 2-4, if you face north or south, the radiation pattern of the antenna is strongest to the left and right with a 200-foot maximum tag collection range in either direction. During the first tag collection, most tags within an omni directional pattern of 100 feet will be collected.
  • Page 16 C H A P T E R Savi Mobile Reader SMR-650P and Handheld Device Description After waiting for a few seconds, turn to the right or left (facing east or west) and perform another collection to determine if additional tags can be collected.

  • Page 17: Operating The Smr-650P Reader With The Symbol

    Operating the SMR-650P Reader with the Symbol Handheld Device Operating the SMR-650P Reader with the Symbol Handheld Device The SMR-650P-211 Reader is compatible with Symbol 8100 and 8146 handheld devices, which are Windows Pocket PC devices with options for 37- or 47-character alphanumeric keyboards. Symbol 8100 and 8146 handhelds feature a backlight for the keypad.

  • Page 18: Symbol 8100 And 8146 Keypad

    C H A P T E R Savi Mobile Reader SMR-650P and Handheld Device Description Symbol 8100 and 8146 Keypad Figure 2-6 shows the keypad of the Symbol 8100 or 8146 that is used with the SMR-650P-211 Reader. Figure 2-6 Symbol 8100 and 8146 Keypad 47 keys plus two side scan keys (not shown) Use the Function key to...

  • Page 19: Keys Unique To The Symbol 8100 And 8146

    Operating the SMR-650P Reader with the Symbol Handheld Device Keys Unique to the Symbol 8100 and 8146 Power/Suspend Key When the display is on, press this key to place the handheld in suspend mode. After a minute, the display goes blank. Resume Key All yellow keys on the Symbol 8100 or 8146 can operate as a resume key.
  • Page 20 C H A P T E R Savi Mobile Reader SMR-650P and Handheld Device Description Reset Pinhole The reset pinhole is located on the back panel of the SMR-650P-211 Reader. Inside the pinhole is a reset button, which you can use to reboot the SMR-650P-211 Reader if the unit is not communicating with Savi RFID tags.

  • Page 21: Connecting The Smr-650P Reader And Charging The Battery

    C H A P T E R Connecting the SMR-650P Reader and Charging the Battery Connecting the SMR-650P Reader to the Symbol Handheld Device You connect the custom Symbol cable of the Savi Mobile Reader SMR-650P-211 to a port located at the bottom of the handheld device. Use the SMR-650P-211 Reader carrying case so you can easily hold both the handheld device and mobile reader in one hand.
  • Page 22 C H A P T E R Connecting the SMR-650P Reader and Charging the Battery Figure 3-1 Connecting the SMR-650P-211 Reader For the instructions that correspond to these photos, see “Connecting the SMR-650P Reader to the Symbol Handheld Device” on page 21.

  • Page 23: Batteries

    Batteries Batteries Recharging the SMR-650P Reader Battery The SMR-650P Reader has a Lithium-Ion internal battery that is not replaceable. To recharge the battery, you use the AC adapter that Savi provides. Ensure that your SMR-650P Reader is not connected to a handheld. Disconnect the mobile reader from the handheld to suspend Note: RF operations while it is charging.

  • Page 24: Recharging The Handheld Device In The Carrying Case

    C H A P T E R Connecting the SMR-650P Reader and Charging the Battery Recharging the Handheld Device in the Carrying Case Ensure that your SMR-650P-211 Reader is not connected to a handheld device. Unbutton and unzip the back of the carrying case. Insert the handheld device into its docking station.

  • Page 25: Battery Status Green Led

    Batteries Battery Status Green LED You can determine the percentage of battery power available based on the activity of the green LED on the SMR-650P Reader. Wall adapter Application Green LED activity Percentage of running pattern battery power available (COM port open) Plugged in Not applicable flash, flash, off for two...

  • Page 26: Verifying The Smr-650P Reader Connection

    C H A P T E R Connecting the SMR-650P Reader and Charging the Battery Verifying the SMR-650P Reader Connection To check the connection, you must have SmartChain Mobile Manager installed on the handheld device. For installation instructions, see the Savi SmartChain Mobile Manager Administrator Guide.

  • Page 27: Checking The Smr-650P Reader Battery

    Checking the SMR-650P Reader Battery Checking the SMR-650P Reader Battery Turn on the handheld device. Start SmartChain Mobile Manager. To verify that the SMR-650P Reader battery is charged, check the battery icon in the lower left. SMR-650P Reader battery power is okay No SMR-650P Reader battery power SMR-650P Reader battery power is low Savi Mobile Reader SMR-650P Quick Reference Guide...
  • Page 28 C H A P T E R Connecting the SMR-650P Reader and Charging the Battery...

  • Page 29: Printing Labels

    C H A P T E R Printing Labels Using SmartChain Mobile Manager, you can print using an infrared interface (IrDA) or the serial interface cable (Zebra Pt# 52712). The infrared interface is recommended for printing labels on the Zebra PT47X printer.
  • Page 30 C H A P T E R Printing Labels A Symbol handheld 81XX with a Strong Arm based microprocessor Note: or equipped with a black and white display cannot print using the IrDA Product Reference Guide interface. Check the Symbol to verify the microprocessor type.
  • Page 31 Printing with the Infrared Interface (IrDA) From the Main Menu, select Print Label. Fill in the fields on the Print Label page. Locate the Symbol handheld IrDA lens. Figure 4-2 Symbol handheld IrDA lens IrDA lens Locate the printer IrDA lens. Savi Mobile Reader SMR-650P Quick Reference Guide...
  • Page 32 C H A P T E R Printing Labels Figure 4-3 Zebra printer IrDA lens IrDA lens...
  • Page 33 Printing with the Infrared Interface (IrDA) Align the Symbol handheld IrDA lens with the printer IrDA lens. Figure 4-4 Align printer lens with lens on handheld device Select Print on the SmartChain Mobile Manager Print Label page. See the Savi SmartChain Mobile Manager Administrator Guide or the Savi SmartChain Mobile Manager Pocket Guide for additional printing information.

  • Page 34: Irda Printing Troubleshooting Tips

    C H A P T E R Printing Labels IrDA Printing Troubleshooting Tips If you have problems printing using the IrDA port: Hold the PDT81XX IrDA lens steady 3-inches to 6-inches over ◆ the PT47X IrDA lens and then select Print. Verify that the smm.properties file has the correct information: ◆...
  • Page 35 Printing with the Serial Interface Cable Find the smm.properties file and copy it to the local PC’s desktop. Open the file with a text editor and modify it as follows: PRINT.PrinterPort.Name=COM1: PRINT.PrinterPort.UseIR=False Save and close the smm.properties file and place the newly modified file in the original \Application\Savi\SMM\6.0 My Pocket PC directory.
  • Page 36 C H A P T E R Printing Labels...
