User Manual
sofa speaker
Sanjing Electronics Co., Ltd.
Please read all instructions before using your Sofa Audio Kit.
1
1
2
2
2
3
4
4/5
6/7
Advertisement
Summary of Contents for Sanjing Electronics Co., Ltd. S499
- Page 1 User Manual sofa speaker Sanjing Electronics Co., Ltd. Please read all instructions before using your Sofa Audio Kit. Contents Page Contents Page 1 Safety Warning Page 2 Specifications 2 Contents 2 Device Overview 3 Basic Operation 4 Warranty/Cautions/Frequently Asked Questions 4/5 Disclaimer 6/7 ...
- Page 2 Safety warning • Before using the unit please read the manual. • Keep this product away from any water, liquid or wet areas. • Keep this product away from open flames such as candles. • the unit should be powered off before plugging the product into the power outlet. • This item is ONLY to plugged into an AC 100V~240V Power outlet. Adapter: Input AC 100~240V, 50/60Hz, 0.5A; Output: DC 5V, 2.5A(Model: K18S050250B & K18S050250U, Dongguan Guanjin Electronics Technology Co. Ltd) Adapter shall be installed near the equipment and shall be easily accessible. The plug considered asdisconnect device of adapter. • the unit should be powered off before unplugging the product. • Do not place the product in direct sunlight or heat. Keep away from temperatures over 35°C. • Do not use a wet cloth on the product. Always use a dry cloth to clean this product and keep it free from dust. •...
- Page 3 Specifications Electro‐Acoustic spec.: Frequency: 100Hz~20KHz S/N: 75db Separate Degree:45db THD+N:<10% Input power:100~240V; DC12V/2A, Output power: 6Wx2 RMS+22W Output power: 680W PMPO Speaker Unit: 3“(6O，10W)X2+5.25”(2O，15W) Note: Works with all iPhones and iPods except iPhone5 Bluetooth spec.: Frequency: 2402~2480MHz Modulation: GFSK, π/4‐DQPSK, 8‐DPSK Bluetooth Version: V3.0+EDR ...
- Page 4 Contents • Sofa Audio kit(with speaker) 1 set • Power Adaptor 1 piece • User Manual ...
- Page 5 device overview SOFA AUDIO KIT Number Icon Function 1 BASS+ When the unit is turned on it will increase the bass. 2 BASS‐ When the unit is turned on it will decrease the bass. 3 ON/OFF 4 takes you back to the previous track or hold to fast rewind through the current track. 5 Display screens 6 In iPod/iPhone, it will play and pause the music track. 7 IR Remote signal receiver 8 press to skip to the next track, or hold to fast forward through the current track. 9 VOL+ Upward of iPod menu 10 VOL‐ Down ward of menu 11 ...
-
Page 6: Listening To Your Ipod/Iphone/Ipad
BAsic Operation Connecting Power Adaptor Connect the power adaptor plug to the Power DC In socket of the unit and the other end into the standard AC outlet. 1. Do not plug or unplug the power cable while you have wet hands. 2. When planning not to use this unit for a long period of time, disconnect the power cable from the wall outlet. 3. When disconnecting the power cord from the wall outlet, do not pull on the cord. listening to your ipod/iphone/IPAD To listen to your iPod/iPhone/iPad, press the “FUNC” button on the unit to iPhone mode and then connect your iPod/iPhone/iPad with usb cable. The iPhone/iPod/iPad LED light will be on, indicating that the iPod/iPhone/iPad has been selected. NOTE: When the iPod/iPhone/iPad is docked in standby mode, it will automatically begin charging if needed. PLAY MUSIC BY BLUETOOTH To use your music devices by bluetooth, press the “FUNC” button on the unit to BT mode and then select and PAIR the source options to this unit. The BT LED light will be on, indicating that the BT has been selected. NOTE: When the BT is selected, only one device can work and all other bluetooth devices should be turned off. This ... - Page 7 NOTE: When the AUX is selected, MP3/MP4, CD/DVD player, notebook PC are supported. ...
- Page 8 PLAY VIDEO BY RCA (optional) When you connect your iPod/iPhone/iPad with this unit and use RCA cable to connect with your TV, you can play back the pictures/Video from your iPod/iPhone/iPad on TV. iPhone incoming Calls When listening to your iPhone through the Sofa audio kit, the unit will automatically switch over upon any incoming calls. The unit will automatically stop playing music and switch over to ring tone. Warranty This product is covered by 12 month replacement warranty with proof of purchase. The warranty will lose its effectiveness if it is misused and not used if the original device, not to include non‐iPhone/iPod/iPad released by Apple. Any FAILURE WITH the sofa audio kit will result in the replacement of faulty parts only, no other direct or indirect costs or damages. Cautions: Excessive sound pressure from earphones and headphones can cause hearing loss Where an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable. Children under the age of 13 should not use this product without adult supervision. Strictly for indoor use. Do not expose to direct sunlight, moisture or extreme temperatures. If cover becomes wet disconnect power immediately and don't use until completely dry. In order to prevent injury or electrical shock, never attempt to remove the cover or any components. ...
- Page 9 frequently Asked QUestions Problems Possible cause and correction or maintenance When on iPhone mode, a.The iPhone/iPod/iPad is lack of power. Please charge it for few minutes. iPhone/iPod can not play b.The iPhone/iPod/iPad is not connected correctly. Ple try again. automatically. The volume switch is on minimum, the unit isn’t set to the correct No sound at all function. Or the speaker cables are not connected well with main machine. If the speaker units are bad, please replace speaker units ...
- Page 10 Disclaimers “Made for iPod, Made for iPhone, Made for iPad” means that an electronic accessory has been designed to connect specifically to iPod, iPhone, iPad respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. iPod, iPhone and iPad are trademarks of Apple Inc., registered in the U.S. and other countries. iPhone and iPod are trademarks of Apple Inc., registered in the U.S. and other countries. *iPhone/iPod/iPad not included This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user ...
