Summary of Contents for E.T. Systems E PAD

  • Page 2 Operating voltage 12 – 24V AC or DC Max. Standby current 100mA VDC Lock and Aux relay rating 3A @15VDC Weather resistance IP65 Max. user memory Lock relay 98 user codes Max. user memory Aux. relay 1 user codes Max. Load on alarm output. 100mA VDC (Open collector) Ver.201105.007...
  • Page 3 PLEASE TAKE NOTE BEFORE COMMENCING WITH PROGRAMMING! Master code: The master code is used to access programming mode. (Default master code = 1234)  The master code can be 4 to 8 digits in length.  The number of digits used for the master code will determine the length of all user codes (Lock, Aux and bypass ...
  • Page 4 Deleting Lock relay output user codes: Deleting an individual user code; Master Code + Master Code (chime tone up) + 50 + two digit user number (chime tone up) Deleting all user codes; (user 01 defaults to 3333) Master Code + Master Code (chime tone up) + 50 + 00 (chime tone up...
  • Page 5 NB! All factory settings and codes will be restored to the default values and all previously programmed user codes will be erased. Power the E Pad down. Open the unit to access PCB Place jumper in the “system restore” position.
  • Page 6 ADVANCED PROGRAMMING OPTIONS AND QUICK REFERENCE TABLE. Factory Need Action Response Default Buzzer Enter programming mode Master code + Master code 1234 Chime tone up 00 + new master code (4-8 digits) Note the number of digits the Change master code No chime tone master is set to will be the number of digits all user codes, lock, aux and bypass.
  • Page 7 Using the keypad Normal operation:- To activate the lock relay, simply type in a valid code for that relay or press and release the free exit push button if one has been installed: -The lock relay will activate as it was setup by the installer. -The green LED indicator will activate as per the relay.
  • Page 8 WARRANTY: All goods manufactured by G&C Electronics cc T/A ET Systems carry a 12 month factory warranty from date of invoice. All goods are warranted to be free of faulty components and manufacturing defects. Faulty goods will be repaired or replaced at the sole discretion of ET Systems free of charge. This warranty is subject to the goods being returned to the premises of ET Systems.
  • Page 9 Cape Town (Southern Suburbs) 15 Nelson Road, Observatory, Cape Town, 7925 Tel: +27 (0)21 404 0800 – Fax: +27 (0)21 447 7794 – Email: sales@et.co.za Cape Town (Northern Suburbs) Unit 5, 2 Kiewiet Close, Okavango, Brackenfell Tel: +27 (0)21 982 8556 – Fax: +27 (0)21 982 8299 – Email: sales@et.co.za Port Elizabeth 12 Parkin Street, North End, Port Elizabeth, 6001...
