Summary of Contents for Shenzhen Sailwider Electronics Co., Ltd. RCS-Z31C
-
Page 1: Product Specification
Shenzhen Sailwider Electronics Co., Ltd. Product Specification Sailwider Wireless Energy Ethernet Gateway (RCS-Z31C) Page 1 of 15... - Page 2 Shenzhen Sailwider Electronics Co., Ltd. 1. General introduction of RCS-Z31C Wireless Energy Ethernet Gateway. The Sailwider Wireless Energy Ethernet Gateway builds the wireless energy monitoring system into the Ethernet platform and links the energy management system with Ethernet network system (IEEE802.3).
- Page 3 Shenzhen Sailwider Electronics Co., Ltd. • Serial This indicator flashes when there is data flow in the serial port (reserved). Interface and Buttons descriptions: • DC 5V The DC Jack for power supply. • The USB port for power supply (Also reserved for serial devices). •...
- Page 4 Shenzhen Sailwider Electronics Co., Ltd. Now use a slim stick to push into the pairing hole of the transmitter (as shown in below photo) and hold it there for about 3 seconds until the LED light of the transmitter flashes quickly. Then release the slim stick and the transmitter is now starting to pair with the gateway.
- Page 5 Shenzhen Sailwider Electronics Co., Ltd. Press the RF link button of the gateway and hold it there for about 5 seconds until the RF indicator lights up, then the gateway enters the pairing mode and begins to search for pairing signal. Now use a slim stick to push into the pairing hole of the sensor plug socket and hold there for about 6 seconds until the LED light on the sensor plug socket flashes quickly.
- Page 6 Shenzhen Sailwider Electronics Co., Ltd. the LED light on the RF switch will stop flashing and the RF indicator of the gateway begins to flash. And the user can see the RF switch information on the web page. If the gateway can’t receive a pairing signal in 60 seconds, it will also exit the pairing mode automatically.
- Page 7 Shenzhen Sailwider Electronics Co., Ltd. 1) Device Name: The default name is SES001. The user can change it to desired name (its maximum length is 15 characters and it should not contain empty space or symbols not accepted to be url). The device name can be used as the URL address to visit the embedded web server in browser in the format of http://devicename.
- Page 8 Shenzhen Sailwider Electronics Co., Ltd. The default setting is allow NTP server Yes, which means the device synchronizes the time with NTP server every 24 hours. The user can change the NTP server then click the “Sync to Device” button to synchronize.
- Page 9 Shenzhen Sailwider Electronics Co., Ltd. the gateway receives the pairing signal from the sensor terminals, its sensors manager page will automatically display the sensor’s MAC ID and real time data. The gateway will send the received real time data to the distant server according to the set interval. Its “add” button changes to be “del” button. For 2-way sensors, there is a button ON or OFF appearing in its “Switch”...
- Page 10 Shenzhen Sailwider Electronics Co., Ltd. The user should keep the user name and password properly, otherwise the user will not able to login the web server and has to reset to factory setting to visit the web server. In this case, all data will be lost. The user needs to do the pairing and setting again.
- Page 11 Shenzhen Sailwider Electronics Co., Ltd. If sensor clamp is to be used, make sure that the voltage has been set correctly. Plug the sensor clamp into any one of the three CT sockets. Place the transmitter near the input trunk cables for home (usually under the electricity meter). Fix the Sensor Clamp around the live wire or the null wire of the input trunk cables for the home.
- Page 12 Shenzhen Sailwider Electronics Co., Ltd. 3-phase power supply If the monitoring target is 3-phase, the user needs totally three sensor clamps for the transmitter. Attach the DC plug of each sensor clamp into the three CT sockets on the bottom of the Transmitter. Fix the 3pcs of Sensor Clamps around the lines of Phase-A, Phase-B and Phase-C (Don’t fix the clamps around the ground wire and neutral wire).
- Page 13 Shenzhen Sailwider Electronics Co., Ltd. When using LED sensor for the measurement, please make sure that the IMP/KWH of the meter has been correctly set on the gateway. 4. Installation of the 2-way sensor socket The installation of the 2-way sensor socket is quite simple. Just first plug it into a wall socket near the target appliance, then plug the appliance into it.
- Page 14 Shenzhen Sailwider Electronics Co., Ltd. 6. Installation of the temperature transmitter The temperature transmitter uses the same case as the 1-way power transmitter, but without the sockets for the CT or LED sensor. After pairing, the transmitter can be flat in a dry place or be stuck on the wall using the 3M velcro on its back in the environment to be measured.
- Page 15 Shenzhen Sailwider Electronics Co., Ltd. Thank you for reading this user manual and using our product. www.sailwider-smartpower.com Page 15 of 15...
