ASY AAR1000X User Manual

3.5mm
connector
2.5mm Power

Features:

•
Enhance Bluetooth Class (AD2P) Performance
•
12hrs of Music Playback Time
•
Remember up to Six (6) Paired Devices

Status Indicator:

−
Red = 2.5mm connected and charging (Red light will turn off after charge completed)
−
Blue (one long blink) = Power OFF
−
Blue (slow continuously blink) = Bluetooth connected
−
Blue (double-blink) = Power ON and Standby
−
Blue (fast continuously blink) = Waiting to be paired (paring mode)

Charge your AAR10000

Highly recommend to charge your AAR10000 100% before usage.
It takes approximately 5 hours to charge the AAR10000 from 0% ~ 100% the first time.
1. Using computer: connect the 2.5mm connector to the AAR10000 power
connector and the standard USB port to computer's USB port
2. Using an electrical outlet: connect the 2.5mm connector to the AAR10000 and
the standard USB port to a DC 5V adapter
3. Indicator status:
a.
b.

Power ON/OFF your AAR10000

1． Power ON: Press and hold the power button for 2 seconds until the indicator
double-blinks in blue
2． Power OFF: Press and hold the power button for 2 seconds until the indicator
turns on in blue for a whole second then off

Use your AAR10000

1. Connect AAR10000 3.5mm connector to the AUX-In / Line-In port of your
AAR1000X – ASY Audio Bluetooth Receiver
RED = charging
OFF = charge completed
User Manual
Power button
Status Indicator
