This manual is applicable for MOCA XP, where in the wireless routing capabilities introductory
section only applicable for MOCA XP
Thank you for choosing MOCA! Easier for you to use the product after unpacking PLEASE READ
This manual thoroughly, and keep it.
Circuit board assembly includes printed circuit board and its component parts, such as resistors,
integrated circuits, connectors, ect
Indicates that the hazardous substance in all homogeneous materials of the part of the content of
the (electronic information products limited requirements for hazardous substances standards)
about the limit requirement
Indicates that the hazardous substance in at least one of the homogeneous materials for this part
is the content exceeds (Electronic Information Products limits for hazardous substances required
standard) standard limit requirement, but this part is still in line with EU RoHs Directive (2002/95 /
EC). required to exempt part of the
Indicates that the component does not contain the hazardous substance
Brand Story
WOWi dea a fashion creative electronics brand. Based on the Clarks new ideas as the brand
philosophy, committed to make the creative ideas into fashion fun, let whimsy dominate life with
fresh, innovative, novel idea to create endless possibilities, sections products are surprised to
experience all show inspiration blooming, life is full of "WOW!" Idea.
Features
MOCA is famous for their slim design. The slim design brings the portable life.
It can charging for your phone pad and other digital terminal
Polymer li‐ion battery cell
Battery Rated voltage
Discharge cut‐off voltage
Charging cut‐off voltage
Resistance AC(1KHz)
Operating temperature range
Storage temperature range
Charging time
Operation time
Cycle life
Weight
Input voltage
User Manual of MOCA XP
Product specification and parameters
MOCA XP
KPL474355‐1600mAh
3.7V
3.0V
4.35±0.05V
<80mΩ
Charge: 0‐45 degrees
Discharge: ‐20 to 60 degrees
One year: ‐20 to 25 degrees
3 months: ‐20 to 40 degrees
1.5 to 2 hours
1 to 1.5 hours
1000 times/60%
About 137g
5‐5.5V
Advertisement
Table of Contents
Summary of Contents for WOW!dea MOCA XP
- Page 1 User Manual of MOCA XP This manual is applicable for MOCA XP, where in the wireless routing capabilities introductory section only applicable for MOCA XP Thank you for choosing MOCA! Easier for you to use the product after unpacking PLEASE READ This manual thoroughly, and keep it. Circuit board assembly includes printed circuit board and its component parts, such as resistors, integrated circuits, connectors, ect Indicates that the hazardous substance in all homogeneous materials of the part of the content of the (electronic information products limited requirements for hazardous substances standards) about the limit requirement Indicates that the hazardous substance in at least one of the homogeneous materials for this part is the content exceeds (Electronic Information Products limits for hazardous substances required standard) standard limit requirement, but this part is still in line with EU RoHs Directive (2002/95 / EC). required to exempt part of the ...
- Page 2 0.5‐1A Output voltage 5‐5.5V Output current 1A Wifi yes Size 84*56*10mm 1. Product schematic and using setup The operating instruction of MOCA XP , take WIN7 system as example. Click the right corner of the computer desktop, and then pop‐up menu, select MOCA XP, click connect and enter the wifi password. The wifi password is on the shell pls keep it When the screen display connected, it means that the computer has been successfully added to the wireless network. ...
- Page 3 2. Wireless internet setting ADSL Internet setting Through the network cable make the modem’s LAN port connect to the MOCA XP The internet via wifi wireless connection to MOCA XP , enter:192.168.169.1. and at the same time the MOCA XP , adm inistration page appearance, enter the user name and password: admin, then pop up a page(as shown below). Then enter your ADSL account name, password and other information, click ok button, then you can set the home view dial up connection status. Notice: if you network service provider requires MAC address binding, enter the appropriate MAC address. ...
- Page 4 When the indicator appears white lights, it indicates that dial‐up success, can visit internet work. Dynamic IP internet setting(such as hotel etc) Let the hotel network cable or the router’s LAN port connected to the network port of MOCA XP The internet via wifi wireless connection to MOCA XP .When the indicator appears white light,it indicates that dial‐up success, can visit internet work. Static IP internet setting(campus network) let the router’s LAN port connect to MOCA XP The internet via wifi wireless connection to MOCA XP , enter:192.168.169.1. then enter user name and password: admin. Then click internet setting—WAN, let the WAN connection mode as static(fixed IP) ...
- Page 5 Selecting the type of encryption and set the WIFI password, in the page of “ wireless security setting”. Clicking”ok” ,after finishing setting. The MOCA XP will auto reboot, then redoing the wireless connection with the new WIFI password. 5. Restore factory settings ...
- Page 6 flashing. MOCA‐XP portable wireless router, with standard USB and Micro USB socket together with one cable network interface. Pressing the switch button (long press for 3 seconds), WIFI working indicator light (green light) is flashing. When the network interface connected to the wired network, the green light will turn to white if networking success. It means that this item is starting and releasing the relative wireless WIFI signal. ...
- Page 7 power has been run out when all the indicator die out. It needs to charging for the power bank again. Do not attempt to disassemble the product Do not closer to or into the fire In charge or access appliances, be careful not to reverse the positive and negative Do not short circuit the battery Avoid percussion and vibration Battery Do not anatomy cell body Do not put in the water Do different manufacturers, different types, different model mix Avoid access to children Battery charger must use the applicable Do not use repaired or damaged charger Do not let the battery charge over 24 hours Store the battery must be charged‐state storage, and requested once every three months discharge If the battery is not used for long, when in use to be fully charged and discharged several times to resume after ...
- Page 8 FCC Information 1. This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including Interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits For a Class B digital device, ...
