CARVIN S610B User Manual

The S610B powered 10" subwoofer offers extreme portability and
powerful bass in a compact lightweight package. While designed to
integrate perfectly with the S600B StageMate™ portable PA system,
it can add 400 watts of extended low end to any PA system.
Like the S600B StageMate™, the S610B subwoofer can run on AC
power or on it's own internal battery power, and is rechargeable
from either AC power or a 12V car socket. The S610B adds deep
bass to the S600B StageMate™ system while keeping the system
portable and allowing high-power operation where other systems
simply can not go.
The 10-inch high-excursion subwoofer is custom designed to deliver
bass down to 40 Hz and below from a compact enclosure. Built for
professional touring, the cabinet is made from multi-ply Baltic birch,
CNC machined for precise construction, then covered in impact and
weather resistant Duratec™ UV finish.
The S610B subwoofer links to the MAIN volume control of the
S600B StageMate™ for consistent bass balance at any volume. Set
the LEVEL on the S610B sub where it sounds best, then forget it.
The StageMate™ system easily expands by adding a second S610B
sub and S648 extention cabinets driven by the S600B StageMate™.
Advanced compact design and flexible power options in a light
weight and rugged package make the S610B the ultimate portable
subwoofer system.
- Compact subwoofer with outstanding low frequency peformance
- Easy addition to the S600B StageMate™ PA system
- Can run for hours in battery mode on a single charge, rechargeable
from wall AC or car 12V DC accessory socket
- 10-inch subwoofer optimized for small enclosures
- 400w amplifier is electronically optimized for the subwoofer and
enclosure
- Amp limiter built-in for increased source headroom
- Cool running Class D operation
- Dual summing XLR and 1/4" inputs from stereo sources
- Direct Out XLR for linking to another S610B or house system
- Threaded pole mount connection w/SS50T pole
(S600B or S648 fits on top 1-3/8" end of pole)
- "Lock-in" AC cord prevents accidental disconnect

GETTING STARTED QUICKLY

1. With POWER off, set the LEVEL on the S610B subwoofer to the
center "S600" position. This is the normal setting connecting to the
S600B, providing a safe starting point for any system.
2. Connect the Line Out XLR of the S600B StageMate™ (or other
source) to the LINE IN XLR on the S610B subwoofer.
3. On the S600B StageMate™ set the LINK TO MAIN switch to "IN".
4. Turn ON the S600B StageMate™ (or other source), then turn on
the S610B sub.
5. Play music from the S600B (source) at a comfortable volume level.
Adjust the S610B sub's LEVEL control to blend in the desired level of
subwoofer bass.
If no sound is heard from the subwoofer, turn down the S600B MAIN
and check your connection, the LINK TO MAIN switch and POWER LED.
6. Adjust the EQ controls to your liking. For more bass from the
system, turn up the LEVEL on the S610B subwoofer. Turning up the
BASS on the S600B StageMate™ may produce distorted bass while
the S610B remains clear.
7. Need more volume? Even though the S610B is driven by a power-
ful amplifier, connecting an additional S610B is the best way to get
substantially more bass output. We recommend one S610B for each
S600B with S648 extention.
S610B Powered 10" SUBWOOFER with Battery Power

RECEIVING INSPECTION - read before getting started

INSPECT YOUR SYSTEM FOR DAMAGE which may have occurred during shipping.
If damage is found, please notify the shipping company and Carvin Audio immediately.
SAVE THE CARTON & ALL PACKING MATERIALS. In the event you have to re-ship your
unit, always use the original carton and packing material. This will provide the best possible
protection during shipment. Carvin and the shipping company are not liable for any damage
caused by improper packing.
SAVE YOUR INVOICE. It will be required for warranty service if needed in the future.
SHIPMENT SHORTAGE. If you find items missing, they may have been shipped separately.
Please allow several days for the rest of your order to arrive before inquiring.
RECORD THE SERIAL NUMBER on the enclosed warranty card and on this manual for your
records. Keep your portion of the card and return the portion with your name and comments to us.

SPECIFICATIONS: S610B POWERED SUBWOOFER

Amplifier Power:
Frequency Response:
Speaker Configuration:
Sensitivity:
Coverage:
Input Impedance:
Level range:
Direct Out:
Protection:
Power Amp topology:
Power Supply topology:
AC Power Requirements:
DC Battery Charge Input:
Mounting/Transport:
Dimensions:
Weight :
Warranty:
Optional Accessories:
16262 WEST BERNARDO DR. SAN DIEGO, CA 92127
800-854-2235 CARVINAUDIO.COM

USER MANUAL

400W
48Hz-120Hz (-3dB), 33Hz-180Hz (-10dB)
10" Subwoofer, bass reflex
0dBu (775 mVrms), max SPL 118dB
Omni
XLR: 2.2K Ohms, 1/4": 10K Ohms
+/-10dB
unity gain from XLR input, 100 Ohm gnd lift
amp limiter, over current, under voltage, thermal
Class D
High frequency switch mode
90 to 250VAC 50/60 Hz, 100VA
12-15VDC, 2A
(accepts typical car battery voltage via C12VDC cord)
threaded pole mount (M20t), bottom rubber feet,
top foot receptacles for stacking, recessed steel handle
18.25"W x 16.5"D x 12.5"H (720 x 650 x 495 mm)
35 lbs. (15.9 kgs) with battery
One year parts and labor
SS50T threaded mount (M20t) adjustable pole 30"-54"
CV610S nylon cover
C12VDC charging cable for 12V vehicle accessory outlet
B600 replacement battery
