ONE TOUCH V101 USER MANUAL V101 About more help information and Frequently Asked Question please browse website www.alcatelonetouch.com CJA18K001AAA...
Contents 1. YOUR DEVIDE ..........3 What’s in the box ........3 Appearance illustration ......3 Installation ..........4 2. QUICK START TO MIRROR ......6 3. DISPLAY MEDIA FILES IN LNA ..... 7 Install Software ........7 Set Wi-Fi network for your V101 ..... 7 Push media files to TV ......
YOUR DEVIDE What’s in the box Appearance illustration Indicator LED The LED will light when V101 starts up. Micro USB Port Connect V101 to USB port of TV or charger(5V, 1A) using an USB cable HDMI Port Connect V101 to the HDMI port of TV using an HDMI cable Press the key when you need to debug V101 after connected with PC...
Installation Connect HDMI Cable: a) Connect one end of the HDMI cable to the back/side of your TV; b) Connect the other end of the cable to HDMI port on the back of V101; Connect USB Cable: a) Connect one end standard USB port of the USB cable to the back/side of your TV;...
Page 5
Click “search” icon, seconds later choose “V101_******” item to connect with V101, then you can the menu UI as below, you can set wireless network, upgrade, setting V101 and so on. Touch Wi-Fi network Touch upgrade Touch to adjust display scale Touch to change language Touch to choose...
Tips: post magic tape QUICK START TO MIRROR TV will display the main UI after V100 be installed several seconds; Set your mobile device 1. click “Setting” -> “Display” -> “wireless display” -> “search”; 2. Please click “V101-****” item, then you can see the connection status on the UI.
c) V101 can connect with mobile device one to one only, so please disconnect the current mobile device when you want to connect with another mobile device; d) The mobile device should be connect with Wi-Fi network firstly then connect with V101, otherwise mobile device maybe can’t access internet.
Choose “Access Point”: set Wi-Fi network SSID and password for V101, V101 will start to connect Wi-Fi network after chick “connect”, you can check connection info on TV. Push media files to TV 1. Open Skifta on your mobile device, choose the first item to enter the next UI, then choose a media source on list;...
3. Choose the third item to enter the next UI, then choose a media file from your mobile device, you can see the media file playing on TV and also can control this file by mobile device. UPGRADE 1. Download new Firmware to your mobile device (smart phone or tablet) from our web site http://support.alcatelonetouch.com on “upgrade...
Page 10
2. Open TV Link tool on your mobile device, click “search” icon, seconds later choose “V101_******” item to enter menu: 3. Click ”Upgrade” -> ”P2P Upgrade(Local)”, browse new Firmware storage directory, choose new Firmware then smart devices will upload Firmware to V101, you can see uploading process as below on smart devices and TV;...
SAFETY AND USE We recommend that you read this chapter carefully before using the Wi-Fi display Dongle. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use of the Wi-Fi display Dongle or of use contrary to the instructions contained herein.
Page 12
you are near gas or flammable liquids. Strictly obey all signs and instructions posted in a fuel depot, petrol station, chemical plant, potentially explosive atmosphere. - When the Wi-Fi display Dongle is switched on, it should be kept at least 15 cm from any medical device such as a pacemaker, a hearing aid or insulin pump, etc.
Page 13
RoHs Approval The Wi-Fi display Dongle is in compliance with the restriction of the use of certain hazardous substances in electrical and electronic equipment Directive 2011/65/EU (RoHs Directive). Radio Waves Proof of compliance with international standards (ICNIRP) or with European Directive 1999/5/EC (R&TTE) is required of all Dongle models before they can be put on the market.
Page 14
The Wi-Fi Logo is a certification mark of the Wi-Fi Alliance. Your device uses non-harmonized frequency and is intended for use in all European countries. The WLAN can be operated in the EU without restriction indoors, but cannot be operated outdoors in France.
Page 15
RF exposure calculation is needed. it is safe during normal use. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 16
interference by one or more of the following measures: ‐ R eori ent or rel ocat e t he recei vi ng ant enna. ‐ I ncrease t he separat i on bet w een t he equipment and receiver. ‐C onnect t he equi pm ent i nt o an out l et on a circuit different from that to which the receiver is connected.
