User Manual

FX871
Fixed Wireless Phone

Advertisement

Table of Contents
loading

Related Manuals for Motorola FX871

Summary of Contents for Motorola FX871

  • Page 1: User Manual

    User Manual FX871 Fixed Wireless Phone...

  • Page 2: Safety Information

    10 inches (25centimeters) from your body when transmitting. 5. APPROVED ACCESSORIES  Use of accessories not approved by Motorola, including but not limited to batteries and antennas, may cause your phone to exceed RF energy exposure guidelines.
  • Page 3 6. RF ENERGY INTERFERENCE / COMPATIBILITIES  Nearly every electronic device is susceptible to RF energy interference from external sources if inadequately shielded, designed, or otherwise configured for RF energy compatibility. In some circumstances your phone may cause interference. 7. MEDICAL DEVICES Pacemakers Pacemaker manufacturers recommend that a minimum separation of 10 inches (25centimeters) be maintained between the fixed wireless phone and a pacemaker.
  • Page 4  Please don’t use any damaged battery or charger and use the battery only for its intended purpose.  Don’t apply extreme shock to the battery. It’s dangerous to disassemble a battery or to apply extreme shock to the battery via nail or heavy metal objects. ...

  • Page 5: Phone Overview

    PHONE OVERVIEW Antenna (10) Right soft key (11) Left soft key Volume key Up/Down / OK key (12) Loudspeaker Phonebook key (13) Microphone FM key (14) Query key Send key (15) Receiver End/Power key Speakerphone key Numeric key...

  • Page 6: Installation

    INSTALLATION [1] Connect the coil cord to both the handset and the transceiver (phone). [2] Install the antenna to the antenna connector. Hold the plastic portion of the antenna and turn the metal screw clock-wise. [3] Connect the adaptor to the AC Wall outlet and put adapter jack into the hole on the rear side of transceiver [4] Remove the battery door and Insert SIM card into the SIM slot in the right direction.

  • Page 7: Key Function

    KEY FUNCTION Left / Right Soft Key ( Menu / Call logs key ) Press the left soft key (Menu/OK) to perform the function indicated by the text on the screen above the key. Press the right soft key (Call Logs/Back) to directly access the Dial Record list Note: The functions of the soft keys depend on the guiding text shown above the keys.
  • Page 8 Press Volume up/down key to change volume level. Press Volume up/down key to move the cursor when entering letters or dialing number. [6] Speaker key If you are using the handset to call and you want to transfer the call to the speakerphone mode, press the Speaker key button and hang up the receiver to transfer the call to the speakerphone [7] FM Radio...

  • Page 9: Display Indicators And Icons

    DISPLAY INDICATORS AND ICONS The display indicators and icons provide information about the operation of the phone. The start screen is displayed when the phone is turned ON. Several features can be used only when the phone is at the start screen. Signal Strength Indicator Indicate the strength of the network signal Volume tone Indicator...

  • Page 10: Basic Operation

    BASIC OPERATION Switching the phone ON and OFF 1) To turn on your phone, press and hold “End key” for a few seconds or until the display turns on. 2) To turn off your phone, press and hold “End key” for a few seconds. Making a call 1) Dial a Call Raise your receiver and enter phone number which you want to call.
  • Page 11 Answering a call When your phone rings, just raise your receiver to answer, or press “Send key” or “Speaker key” to answer in speaker phone mode. Speaker mode. You can make or answer a phone call by pressing Speaker key when the handset is on the base To make a call: 1) Press the number you want to connect to without pick the handset up.
  • Page 12 Caller ID Requires a subscription to a calling plan that supports this feature. Not available in all areas. Contact you telephone service provider for availability and details. When Caller ID is active, your phone shows the caller’s phone number during an incoming call, as long as this number is a part of your service provider’s wireless network.

  • Page 13: Using Phone Menus

    USING PHONE MENUS Menus A menu is a list of choices you can make. Your phone has 5 menus. ( And your service provider may add STK menu extra depending on network service ) Each menu contains options that allow you to use the message, change the ring tone, etc. You can use menus and sub-menus in two ways: by scrolling or by using shortcuts.

  • Page 14: Enter Letters And Numbers

    ENTER LETTERS AND NUMBERS [1] Entering Letters When you want to add new names or when you view names in the Contacts, your phone automatically switches to the abc (ABC) mode and displays the abc icon on the right upper side in Display. ※: abc → Abc →ABC →123 rotated Characters Characters , .

  • Page 15: Overview Of Menu Tree

    OVERVIEW OF MENU TREE * For detail about menu tree and usage, please contact your service provider 1. Phonebook 1. View 2. Send text message 3. Call 4. Edit 5. Delete 6. Copy 1. To Phone 2. To SIM 7. Move 8.
  • Page 16 2. Channel settings 3. Languages 4. Read messages 7. SMS templates 8. SMS settings 1. SIM 2. Memory status 3. Save sent message 4. Preferred stroage 5. Character set 3. Call Center 1. Call history 1. Missed calls 2. Dialled calls 3.
  • Page 17 “as is.” Certain features may not be activated by your service provider, and/or their network settings may limit the feature’s functionality. Additionally, certain features may require a subscription. Contact your service provider for details. User Manual of FXP871 version 1.0 [ENG] 15/1/2014 Copyright 2014, Motorola Inc., All rights reserved.
  • Page 18 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications or changes to this equipment.
  • Page 19 receiver is connected. ‐Consult the dealer or an experienced radio/TV technician for help. Federal Communication Commission (FCC) Radiation Exposure Statement When using the device, maintain distance of 20cm from the body to ensure compliance with RF exposure requirements.
