- Page 1 ISTFM420U V.06.2013 FM420U MULTI-CHANNEL 433.92 MHz RADIO CONTROL. Operation and programming instructions.
- Page 2 DISPLAY Fig. 1 CR2430 40.8 Fig. 2 dimensions in mm...
-
Page 3: Specifications
SPECIFICATIONS Multi-channel radio control for quick and intuitive control of 20 users with receivers in the series FM400U Innovative and stylish container with white led display which, located under semi-transparent plastic, shows the selected channel. At the centre of a rubber faced keypad with three function keys and two up-down channel selection keys. -
Page 4: Description Of Components
DESCRIPTION OF COMPONENTS Fig. 1 Fig. 2 channel decrease key Battery panel opening and CH1 transmission key external dimensions in mm channel increase key CH2 transmission key CH3 transmission key MAIN FUNCTIONS This transmitter can control up to 20 automations, each of which can be sent 3 different functions (for example OPEN, CLOSE and STOP). - Page 5 Use key 1 or 3 (indicated in the drawing) to scroll through to the flashing Use the central key to confirm The channel will start flashing. Use key 3 (indicated in the drawing) or 1 to scroll through the channels to Press key 2 to add the channel 02 to C2.
- Page 6 Use the central key to complete programming of C2. The text is displayed briefly, followed by after which the display turns off. Access to secondary menu This menu contains the following functions: Display shutdown delay setting Maximum channel number setting Channel 00 repetition function Firmware Version Procedure to enable secondary menu:...
- Page 7 Use key 2 (indicated in the drawing) or 4 to scroll through values corresponding to a display shutdown delay from approx. 2 to 10 seconds. Press key 5 to confirm. The text appears briefly and the radio control returns to normal operating status. To increase battery lifetime, set a short delay interval.
- Page 8 - Channel 00 repetition This new multi-channel control enables programming of channel 00 so that it repeats transmission sequentially for a set time interval. This function is useful when channel 00 is optimised for centralised commands, and repetition optimises reception of the radio signal. Press key 5 to select Use key 2 (indicated in the drawing) or 4 to scroll through values 00 to 40.
-
Page 9: Battery Replacement
BATTERY REPLACEMENT To replace the battery, open the battery compartment and remove the battery with the aid of a tool (for example the tip of a pen). Fit the new battery taking care to observe polarity. See fig. 2 on page 2. GUARANTEE The present guarantee covers possible faults and/or irregularities due to manufacturing defects and/or faults. - Page 10 NOTE...
- Page 11 NOTE...
- Page 12 Telcoma s.r.l. via L. Manzoni, 11 z.i. Campidui 31015 Conegliano (TV) Italy Tel. +39 0438-451099 - Fax +39 0438-451102 http://www.telcoma.it E-mail:info@telcoma.it...
