- Page 1 ACR123 User Manual ACR123 User Manual V1.00 Name Signature Date Kit Au 2013-03-27 Prepared by: Reviewed by: Approved by: info@acs.com.hk Subject to change without prior notice www.acs.com.hk...
- Page 2 Version History Date Changes Version 2013-03-27 Kit Au ● First Release 1.00.00 ● Page 2 of 13 info@acs.com.hk ACR123 User Manual Version 1.00.00 www.acs.com.hk...
-
Page 3: Table Of Contents
Table of Contents 1.0. Introduction ....................... 4 2.0. Features ........................5 3.0. Architecture ....................... 6 4.0. ACR123 Operating Procedure.................. 7 4.1. Driver installation Procedure ......................7 4.2. Operation Example........................10 Appendix A. Parameter sheet ..................12 Page 3 of 13 info@acs.com.hk ACR123 User Manual Version 1.00.00... -
Page 4: Introduction
MasterCard PayPass and Visa PayWave standard. The compliance to the PayPass and PayWave standard widens the supported cards and strengthens the contactless product line’s salability especially in the payment industry. Page 4 of 13 info@acs.com.hk ACR123 User Manual Version 1.00.00 www.acs.com.hk... -
Page 5: Features
Linux • Compliance to standards CE/FCC VCCI RoHS REACH EMV Level 1 and EMV Level 2 • Certifications CE/FCC VCCI RoHS REACH EMV Level 1 and EMV Level 2 Page 5 of 13 info@acs.com.hk ACR123 User Manual Version 1.00.00 www.acs.com.hk... -
Page 6: Architecture
To perform communication between Main processor and contactless tag Carrier Frequency = 13.56MHz For software architecture, ACR123 built-in simple OS that used for tasks management, resource management, etc. Tasks included PICC Polling, SAM checking, Serial and USB communication flow, etc. Page 6 of 13 info@acs.com.hk... -
Page 7: Acr123 Operating Procedure
Driver “Microsoft CCID Driver Version 5.2.3790.2724.rar” Steps: 1. Extract the file “Microsoft CCID Driver Version 5.2.3790.2724.rar” 2. Plug-in the ACR123 to PC’s USB 3. Wait for driver install message 4. Select “Install from a list or specific location (Advanced)”, then “Next>”... - Page 8 5. Select “Don’t search. I will choose the driver to install”, then “Next>” 6. if present “USB Smart Card reader”, select it and then “Next>” Page 8 of 13 info@acs.com.hk ACR123 User Manual Version 1.00.00 www.acs.com.hk...
- Page 9 No, click “Have Disk…” Click “Browse…” to locate the driver (usbccid.inf) location, click “Open” Select “USB Smart Card reader”, and then “Next>” 7. Click “Continue Anyway” Page 9 of 13 info@acs.com.hk ACR123 User Manual Version 1.00.00 www.acs.com.hk...
-
Page 10: Operation Example
8. Wait until the below screen appear, click “Finish” to complete 9. Driver Installation Complete 4.2. Operation Example Hardware requires: ACR123 x 1 PC with OS windows XP or above Test card x 1 (provided by ACS) Software requires: APDU.exe (for example) Steps: 1. - Page 11 4. Select “T1”, and enter the APDU into Message Felid Message Felid 5. Press “Connect” 6. Press “Transmit” to start the testing 7. Complete the operation Page 11 of 13 info@acs.com.hk ACR123 User Manual Version 1.00.00 www.acs.com.hk...
-
Page 12: Appendix A. Parameter Sheet
Appendix A. Parameter sheet Device ACR123 Smart Card Reader/Writer Power supply Supply voltage........ Regulated 5V DC Supply current ........ <500mA Serial Interface Type ..........RS232/RS485 Connector ........supplied together with the reader Speed..........9600bps – 250Kbps Universal Serial Bus Interface Type .......... - Page 13 (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Page 13 of 13 info@acs.com.hk ACR123 User Manual Version 1.00.00 www.acs.com.hk...
