- Page 1 USER MANUAL DFCN-H1 NFC MOUDULE USER MANUAL & Operational description...
- Page 2 USER MANUAL I. Introduction DFCN-H1 is a kind of NFC (Near Field Communication) module that could be embedded in one IT system by simply connecting the module to his target microcontroller and start developing his application software. II. DESIGN REFERENCE DFCN-H1 reference design module consists of the following: •...
- Page 3 USER MANUAL III. FEATURE Contactless protocols: • ISO14443 A/B • ISO15693 • ISO18092 Contactless transmission of data and RF energy Peer-to-peer communication Card emulation NFC card reader/writer Programmable receiver sensitivity Carrier frequency: 13.56 MHz ...
- Page 4 USER MANUAL MECHANICAL DIMENSION VII. Certifications and Regulatory Item Feature Description RF: FCC part 15C EMI: FCC part 15B FCC grant: TCB Filing fee RF: EN302291 Class B EMC: EN301489-1/-3 Safety: EN 60950-1:2006/A11:2009 RSS-210 ISSUE 8 RSS-GEN ISSUUE 3 General: This modular approval is limited to OEM/Integrators installation only. OEM integrators are responsible for ensuring that the end-user has no manual instructions to remove or install module.
- Page 5 USER MANUAL End Product Labeling (FCC) When the module is installed in the host device, the FCC ID label must be visible through a window on the final device or it must be visible when an access panel, door or cover is easily re-moved. If not, a second label must be placed on the outside of the final device that contains the following text: “Contains FCC ID: NKR-DFCNH1”.
- Page 6 USER MANUAL End Product Labeling (IC) Labeling Requirements for the Host Device (from Section 3.2.1, RSS-Gen, Issue 3, December 2010): The host device shall be properly labeled to identify the module within the host device. The Industry Canada certification label of a module shall be clearly visible at all times when installed in the host device, otherwise the host device must be labeled to display the Industry Canada certification number of the module, preceded by the words ―Contains transmitter module, or the word ―Contains, or similar wording expressing the same meaning, as follows: "Contains transmitter module IC: 4441A-DFCNH1 ".
- Page 7 USER MANUAL...
