User manual
CarDvRD(
)
BOSS800
Thanks for purchasing our 3 in 1, all our wishes is drive your life with safety
and enjoy your travel!
In order to use this device correctly and more efficiently, please follow up
instruction rules in this manual for your installment and setting. Once you
finished reading it, please kindly keep it handy for your any necessary
reference.
Dongguan Wanma Soaring Electronic Technology Co.,Ltd
Advertisement
Summary of Contents for Wanma Soaring Electronic Technology CarDvRD BOSS800
- Page 1 In order to use this device correctly and more efficiently, please follow up instruction rules in this manual for your installment and setting. Once you finished reading it, please kindly keep it handy for your any necessary reference. Dongguan Wanma Soaring Electronic Technology Co.,Ltd...
- Page 2 Standard Packages 1 * CarDvRD 3in1 Unit 1 * 12V Car Charger 1 * Bracket with tenon 1 * USB cable for update 1 * User manual 1 * Color box Main Features: 1. GPS data points alerts of fixed speed cameras in advance for safety driving 2.
- Page 3 2. Button setting of GPS-RD On working condition, please set the followings by below steps. 1. Volume adjustment Short press the Volume button “+/-”, the alert volume can be switched from 1-6 circulatory. 2. Radar Identification system Generally, the automatic doors in banks and petrol stations will send a micro signal wave, which we call it Interferential radar frequency(signal), the radar detector in CarDvRD may alarm it.
- Page 4 3. Menu setting Input Self-setting coordinates On working condition, short press button “M” once while you are driving arrived at the point of new cameras need to be added, you will hear voice prompt “Input self-setting coordinates”; then press the volume button “+/-” within 3 seconds to confirm the setting.
- Page 5 band lamp when meet the Interferential radar signal in the GPS memory. Note: This function can set on to make the GPS recognize the interferential radar frequency which takes noises, thus cut false alarms helpfully. Continue alarms for over-speed On working condition, short press button “M” 6 times until you heard the voice prompt “Continue alarms”, then press the volume button“+/-”...
- Page 6 Time Zone selection On working condition, short press button “M”11 times until you heard the voice prompt “Time zone selection”, then press the volume button to choose the right time zone for the GPS system. Factory default setting On working condition, short press button “M” 12 times, you can return to the factory default setting.
- Page 7 In Preview Mode Short press the REC button can exit the preview mode and start to record. Short press the MENU button can enter into the menu setting. Short press the OK mode button can start replay the videos. Short press the UP down button can go to the last and next video. Short press the Lock button can unlock the current video.
-
Page 8: Troubleshooting
Troubleshooting Problems Fast Solutions No power supply 1. check power 2. check fuse 3. check car charger Continues abnormal alarm 1. restart 2. check signal in car 3. check device broken No voice alarm but has display alarm 1. check radar alert mute setting 2. - Page 9 GPS + Radar Detector Specification Power supply DC 12V Current range 150-300Ma Work temperature -25-85 C° Save temperature -40-90 C° Radar band Frequency Range Sensitivity X band 10.42-10.62 GHz -120+/-2db K band 23.9-24.3 GHz -130+/-2db Ka band 34.1-35.82 GHz -130+/-2db DVR Specification SQ680S SDHC class 6 4GB-32GB, need use the...
- Page 10 APP Tool Instruction The TF card once being formatted by the CarDvRD 3in1 device, it can automatically generate a ADR player in the SD card，please operate as below steps to review the video. 1. Open the ADR player and enter into below interface by clicking the button corner bottom at the Left side.
- Page 11 The groups with yellow color is the ones that saved by lock button, which can not be overwrite when the TF card is full, you can delete them by unlocking by manually operation in the CarDvRD 3in1 device or in the PC. 3.
- Page 12 2. Delete the original format of the TF card. 3. Upload the ADR player to the TF card 4. Choose the map (Google map or Chinese map) 5. Setting the password, once being set, all files can not be opened without getting through the password.
- Page 13 (B)About the GPS track display on the map The record will remember the information from the GPS module every 1 second, When the GPS is well positioned, the record files can save the information of latitude, longitude, date, time and speed for the files, you can see this information when you connect the files to the Google map by the ADR player, you will have to press the button marked with red square at the right side corner to display the map.
- Page 14 (D) Save videos from the ADR Player Press the save button as below marked with red square, you can save the videos to the disc in the computer. About the GPS cameras database update To update the database, you must go to the website of the producer or the local distributors.
- Page 15 3. Click “open” button to choose the update database file and press “Update” button to update the database. 4. You can also clink “Setting” to enter into the configuration of some parameters as below. About the warranty All of our products will be warranty for 12 months from date of the delivery.
- Page 16 FCC Warning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
