- Page 1 REV.10.17.A Equipment Supply Company Instruction Manual OTR Large O-Ring Installer ESCO #40807 Copyright © 2017 Equipment Supply Co., All rights reserved...
- Page 2 ESCO OTR Large O-Ring Installer Model #40807 CAUTION: THIS PRODUCT, AS WELL AS ALL TIRE TOOLS, SHOULD NEVER BE USED BY PERSONS UNLESS THEY HAVE BEEN TRAINED PROPERLY ACCORDING TO OSHA REGULATIONS 29CFR 1910.177 ENTITLED “SERVICING SINGLE-PIECE & MULTIPIECE RIM WHEELS”.
-
Page 3: Product Description
ESCO OTR Large O-Ring Installer Model #40807 Product Description The ESCO OTR Large O-Ring Installer [Model #40807] is designed and built to manually install and remove O-Rings on OTR Tires 25”- 36”. The unit is also used to separate the inside and outside beads of OTR tires as well as assists in the removal and installation of the lock ring. -
Page 4: Maintenance And Inspection
• A qualified technician is available by ESCO to answer any questions regarding applications and proper use of the tool. • Improper use of the tool for which it is designed for may void warranty. -
Page 5: Product Details
ESCO OTR Large O-Ring Installer Model #40807 PRODUCT DETAILS: 1. Fixed Arm 2. Push Rod Adjustment 3. Slide Arm Adjustment Nut 4. Mobile Arm INSTRUCTIONS: • Before use of this tool always check all components. All components must be in perfect condition, there must be no oil leaks, dents, or marks on the cylinder. - Page 6 ESCO OTR Large O-Ring Installer Model #40807 INSTRUCTIONS: (cont’d) Bead Remover Connection • Connect the bead remover to the single effect command circuit, with suitable control systems using the fittings provided. • The system must operate at a pressure no higher than 700 bar with a flow rate no higher than 0.7 1/min.
-
Page 7: Handling And Storage
ESCO OTR Large O-Ring Installer Model #40807 INSTRUCTIONS: (cont’d) Precautions • The tire must be completely deflated. • Work only on tires that are locked in position and cannot rotate or turn, to avoid uncontrolled movement. • Keep the bead remover always perpendicular the the rim to avoid a bad operation. - Page 8 ESCO OTR Large O-Ring Installer Model #40807 NOTES: ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ 1.800.352.9852 • info@esco.net • www.esco.net...
- Page 9 Not only do we service our own products, but we also service our competitors’ products. In addition to ESCO’s 30 years of providing quality repair service, ESCO has reached out and partnered with more than 50+ hydraulic repair facilities across the US & Canada, to deliver quality repair and timely return of products.
- Page 10 ESCO website WWW.ESCO.NET CONTACT INFO: www.esco.net - info@esco.net 15270 Flight Path Drive Brooksville, FL 34604 PH. 352.754.1117 Toll Free. 1.800.352.9852 (US, Canada Only) Fax: 352.754.4508 ESCO - The Proper Tools to Keep Your Equipment Moving! Stay Connected with ESCO...
