Safety Warnings
Failure to abide by any of the safety warnings below may result in equipment failure and serious injury or death.
!
For models containing Liquid Block™: Slowly open the supply pressure so that the minimum differential pressure required to
}
shut-off the Liquid Block™ is not met or exceeded..
Valve off the sample flow before installation.
}
Do not exceed any equipment pressure
}
Tools Required
Four #10 screws for mounting bracket to panel.
}
Screwdriver for mounting bracket to panel.
}
Avenger™ Model 38M
Installation & Operation Instructions
Manufacturing
A+ Corporation, LLC
Call for expert product application assistance:
41041 Black Bayou Rd.
Phone: (225)-644-5255 Website: www.geniefilters.com
Gonzales, LA 70737
Fax:
Contact
Information
(225)-644-3975 E-mail: sales@geniefilters.com
©
2005 A+ Corporation, LLC. All rights reserved.
SCC-38M-InsInstallationOperation_100318
Advertisement
Summary of Contents for A+ Corporation Avenger 38M
- Page 1 Valve off the sample flow before installation. Do not exceed any equipment pressure Tools Required Four #10 screws for mounting bracket to panel. Screwdriver for mounting bracket to panel. © 2005 A+ Corporation, LLC. All rights reserved. An ISO 9001:2008 certified company SCC-38M-InsInstallationOperation_100318...
-
Page 2: Technical Specifications
Back View Side View MINIMUM MAINTENANCE CLEARANCE 8.100” 4.995” 2.626” 1.876” 4.270” 1.250” DIA. 3.700” 3.256” 3.700” 2.625” 2.000” PORT D 0.883” OPTIONAL MOUNTING BRACKET 0.355” © 2005 A+ Corporation, LLC. All rights reserved. An ISO 9001:2008 certified company SCC-38M-InsInstallationOperation_100318... - Page 3 “Port E” or it may be plugged. The Model 33M has 1/2” NPT ports (except for the 1/4” NPT gauge “Port E”) and the Model 38M has 1/4” NPT ports. Refer to the “Application” for tubing connection instructions. Application Drawing © 2005 A+ Corporation, LLC. All rights reserved. An ISO 9001:2008 certified company SCC-38M-InsInstallationOperation_100318...
-
Page 4: Application Drawing
Application Drawing © 2005 A+ Corporation, LLC. All rights reserved. An ISO 9001:2008 certified company SCC-38M-InsInstallationOperation_100318... - Page 5 Model Numbering & Additional Part Numbers Model Numbering & Additional Part Numbers Your model number is determined by your specific needs. Choose options below. Sealing material 0 = Fluoroelastomer 1 = Perfluoroelastomer (other materials available upon request) Element type 07CFS = 0.1 micron coalescer fluorocarbon SS10 = 10 micron stainless steel Membrane type 6 = Rejects ALL types of liquids from vapor...
