AFK GENERIC ARBOUR
ASSEMBLY
INSTRUCTIONS
A TOP QUALITY PAINT/STAIN HAS BEEN USED IN THE MANUFACTURE
OF THIS ARBOUR
TO MAINTAIN THIS FACTORY FINISH WE RECOMMEND THE ARBOUR
SHOULD BE REPAINTED/ STAINED ANNUALLY WITH GENUINE AFK
GARDEN FURNITURE PAINT/STAIN
A handy assembly video can be viewed on the below website
www.afkgardenfurniture.co.uk
AFK
GARDEN
Use instructions for
Cottage Arbour
Orchard Arbour
Goodwood Arbour
(version 2018)
CONTENTS:
PACK 1 OF 3
Item 1
Item 2
Left Side Panel X 1
Right Side Panel X 1
Item 7
120mm Coach Bolt, Nut & Washer X 6
Item 9
40mm Flat Head
40mm CSK Screw X 8
Touch Up Paint X 2
(Painted Arbours Only)
Item 3
Item 4
Left Armrest X 1
Right Armrest X 1
(Not in Goodwood)
(Not in Goodwood)
Item 5
Roof Ridge X 1
Roof Joint Piece X 2
Item 8
60mm CSK Screw X 4
Item 10
Item 11
20mm Flat Head
Screw X 4
Screw X 44
Item 6
