IQBASE-N
User Manual
HME Wireless, Inc
Customer Service 800.925.8091
1400 Northbrook Parkway Suite #320 • Suwanee, GA 30024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IQBASE-N and is the answer not in the manual?

Questions and answers

Summary of Contents for HME IQBASE-N

  • Page 1 IQBASE-N User Manual HME Wireless, Inc Customer Service 800.925.8091 1400 Northbrook Parkway Suite #320 • Suwanee, GA 30024...

  • Page 2: Limited Warranty

    NOTICE This manual, software and electronic circuitry are copyrighted. All rights reserved. Under the copyright laws, this manual, software and electronic circuitry may not be copied, in whole or in part without written prior consent of Lee Technology. All information provided in this document is carefully prepared and offered in good faith as a guide in the installation, use and servicing of our products.

  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION RF EXPOSURE STATEMENT Your Pager Transmitter contains a radio frequency transmitter. When the button is pushed the transmitter sends our RF signals. CAUTION: To comply with FCC RF exposure compliance requirements, a separation distance of at least 8 inches (20 cm) must be maintained between the antenna of this trasmitter and all persons, during normal operation.
  • Page 4 Thank you for purchasing our brand-new “IQ Paging System” We are confident our cutting edge products and first rate service will satisfy your needs for years to come. Please read these instructions carefully before setting up your IQ Paging System! 1.

  • Page 5: Wall Mount

    1) DESKTOP You can use your transmitter with the 20 degree wedge attached or remove the wedge and lay the transmitter flat. 2) WALL MOUNT To mount your transmitter on a wall  Remove the plastic bracket (included) under the transmitter unit by unlocking the 2 latches ...
  • Page 6 “2580” followed by “ENTER” If the password is accepted, the display will show “use * to scroll to menu options” 1) Set Current Time  At the “Set Current Time” menu, set the hour then press “ENTER” key.  Set the minutes and press “ENTER” key. ...
  • Page 7  Remove a couple of pagers from the charger base.  At the range test menu, press “#” key to turn range test “ON”  Press “ENTER” to start the range test. As soon as range test is activated, you’ll notice the IQ pagers flash once every 10 seconds. Walk around your property.
  • Page 8 Be sure that all pagers are returned before performing this procedure. To change the alert mode of your pagers follow these instructions  Remove all the pagers from the charger base or unplug the power supply that is connected to the charger bases. ...
  • Page 9  Make it “ON” and then press “ENTER” key.  “Are All Pagers Returned??” is displayed and then press “ENTER” key.  “Unplug All Coasters” is displayed and then press “ENTER” key.  “Message Sent Plug In Pagers” is displayed and transmit message twice. Cf) Out of Range ON (Message 9494), Out of Range OFF (Message 9393) 8) Set DEFAULT MSG With this feature, you can setup the default message.

  • Page 10: Set Baud Rate

    Setting the Base ID  At the “SET Base ID” menu, “SYSTEM BASE ID:” is displayed.  Input the Base Id and then press “ENTER” key. 11) GROUP CALL ID With this feature, you can setup the GROUP CALL ID. Setting the Group Call ID ...
  • Page 11 Setting Frequency  At the “SET FREQUENCY” menu, you can select the frequency using “#” key. Frequency List (1) 450.0250 MHZ (2) 450.3750 MHz (3) 457.5750 MHz (4) 458.6625 MHz (5) 461.2625 MHz (6) 461.4750 MHz (7) 462.5750 MHz (8) 463.6375 MHz (9) 469.9750 MHz 4.
  • Page 12 the “OPEN / BUS” setion ※ Max 9 Table # can be displayed onto the each section and Max 19 Table # can be stored. ※ When the number of received Table # is over 9, you can scroll the table # by pressing “OPEN”...
  • Page 13 FCC ID: WDC­IQBASE­N This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications (including the antennas) made to this device that are not expressly approved by the manufacturer may void the user's authority to operate the equipment.
