- Page 2 Genstar Technologies Co., Inc. (GENTEC®) manufactures continuous suction regulators in two ranges, 0 to 300mmHg (882VR-300) and 0 to 760mmHg (882VR- 760). These suction regulators provide three modes: REG (regulated vacuum), OFF (no vacuum) and FULL (whatever is available at the wall inlet). Please take a few minutes to familiarize yourself with the product by reviewing Figure 1 on the next page.
- Page 3 (typically above 480mmHg). A suction filter or vacuum trap assembly (GENTEC catalog #880VT) should be used to prevent aspirate from entering the suction regulator. Typically, the suction catheter is connected to the suction tubing, which is then connected to the inlet fitting on the suction canister.
- Page 4 vacuum trap assembly or the suction regulator. Doing so may permanently damage the suction regulator and void any and all warranties, express or implied. A collection canister (reusable or disposable) MUST be used between the patient and the suction regulator or vacuum trap, if used. If a vacuum trap is not used it is recommended that a disposable hydrophobic bacterial filter be used between the suction canister and the suction regulator to prevent overflow of the canister into the suction regulator.
- Page 5 The internal flow path can be cleaned by suctioning a cold sterilant through the unit, then allowing the unit to run for 30-45 minutes to dry the interior. The following repair assemblies can be purchased from your Authorized GENTEC distributor (refer to the exploded view on the next page):...
- Page 6 Part No. Description Part No. Description 300660110 Screw Kit (Set of 5) Shaft 200260010 Back Plate Spring Mode Selector Filter 203060040 204880020 Assembly Assembly 203060010 Regulator Assembly Protecting Cap Adjustment Knob 204880010 Sponge Filter Assembly Logo Sticker Orifice Union Screw Orifice Seat Knob 141742301...
- Page 7 Corrective Problem Probable Cause Measures Move the mode The regulator is in the “OFF” selector to the mode, or is not fully in the “REG” or “FULL” “REG” or “FULL” position. position. The vacuum gauge needle does not move The adjustment knob is in the Turn the off “0”...
