- Page 1 Aeroex Technologies Inc. Oil Mist Collector Model ARO-2500 Multi-Stage Installation & Service Manual www.aeroex.com Sales 905-655-7295 sales@aeroex.com orderdesk@aeroex.com Rev 1 June 20/2017 www.aeroex.com orderdesk@aeroex.com...
-
Page 2: Table Of Contents
Table Of Contents Specifications…………………………………….………….…………3 Installation instructions……….………..…………….……………4 Installation Kit.................5 Oil drain hose Kit................5 Electrical..................6 Online cleaning................7 Maintenance...................8 Filter options Coolant..............9 Filter options Oil................10 Drawings..................11 Warranty..................12 Rev 1 June 20/2017 www.aeroex.com orderdesk@aeroex.com... -
Page 3: Specifications
Model ARO-2500 Specifications AEROEX – Oil Mist Collector For highly effective separation of coolant and oil mists including smoke from metalworking machinery and oil reservoirs. Consisting of: Powdered coated mild steel housing. Motor and fan impeller or Motorized impeller -For Coolant, the primary separation pack consists of a 1st stage ME and 2 stage AG agglo, stage fiber bed filter. -
Page 4: Installation Instructions
Installation: • Mount mist collector level. • Units can be mounted directly on top of machines, on a post or on the wall. • Ensure that there is free space to change filters. • Minimize the length of ducting to avoid air flow loses. •... -
Page 5: Installation Kit
Installation kit: Three (3) standard installation kits as follows: Item Description Part # Installation Kit, 12” 099AIK-0005 Suction hose 12” 1(a) 099MPH-0012 Hose clamp 12” 1(b) 099MHH-0008 Machine adaptor 12” 1(c) 099AMS-0012 Chip strainer, 12.5”x14”x4” 1(d) 099ACS-0006 1(d) Optional chip deflector 099ACD-0006 Oil Drain Hose Kit : Item... -
Page 6: Electrical
Connect electrical wires on dual voltage motors (230/460/3/60) according to wire numbers on the motor data plate or the motor manual. Direction Of Rotation: Motor: (ARO-2500) - Motor direction arrow is located on the motor - Start/Stop motor - Check rotation direction - If incorrect, switch 2 electrical connections, ie L1 &... -
Page 7: Online Cleaning
Electrical Connection: Rev 1 June 20/2017 www.aeroex.com orderdesk@aeroex.com... -
Page 8: Maintenance
Maintenance: The mist collector can operate for long periods without maintenance. The maintenance period will depend on the type of oil, coolant & debris in air stream. Inspect the unit after 3 months, 6 months & 1 year to establish the maintenance interval. The mist collector has one magnehelic gauge measuring the pressure drop on 4 stage HEPA filter. -
Page 9: Filter Options Coolant
Filter Options Coolant Item # Description Quantity Part Number stage Mechanical Element pack A20FMS-0001 stage Agglomerator filter pack for A20FAF-0001 coolant stage fiber bed filter for coolant A20FCM-0004 stage filter HEPA 95% @ 0.3 microns 2000HF-2095 stage filter HEPA 99.97% @ 0.3 2000HF-2099 microns (Optional) -
Page 10: Filter Options Oil
Filter Options Oil Item # Description Quantity Part Number stage Mechanical Element pack A20FMS-0001 stage “DE” Demister Element A20FDE-0002 Stage “OM” #3 Oil Mist Pack A20FOM-0003 For low viscosity oils and high smoke. stage filter HEPA 95% @ 0.3 microns 2000HF-2095 stage filter HEPA 99.97% @ 0.3 2000HF-2099... -
Page 11: Drawings
Drawing: Rev 1 June 20/2017 www.aeroex.com orderdesk@aeroex.com... -
Page 12: Warranty
The Purchaser's sole remedy shall be as stated above. Aeroex Technologies will make good faith effort for prompt correction or adjustment with respect to any product that proves to be defective within warranty.
