Summary of Contents for AltoTech Cool Glass One
- Page 1 *This user guide depends on the software version. If there are any changes, we won’t notify you. Please refer to your current version for using this user guide.
- Page 2 6.1 Turn on/ off 6.2 Awaken methods 6.3 Charging Instruction 7. Initial Settings 7.1 Pair and bond Cool Glass One to your cell phone 7.2 WiFi connection 8. Main Features Instruction 8.1 Software System Update 8.2 Voice Command Control Instruction 8.3 Take Picture...
- Page 3 8.7 Third Party Applications 9. How to wear 10. Shortsighted Lenses 11. Accessories 12. Common Problems 13. Other Questions: Customer Service Trade Mark...
- Page 4 Cool Glass One is a smart glass that can be controlled by voice command. It also has a touch pad on the right side of the glass frame. Cool Glass One has the AR function and it is based on Android 4.3 operation system.
- Page 5 2. Specifications The main parameters Ingenic M200 System Cool Glass ROM (based on Android4.3) Screen LCD 800x480 pixels Resolution Storage Camera / video 800W camera, 720P video capture Battery capacity 400mAh Endurance Normal 8h, continuous recording> 150mins, standby time 48 h The whole 195mm length...
- Page 6 3. Software Application Map Swipe forward and backward to switch the interfaces; Click to enter the secondary interface and again, swipe forward and backward to switch. 4. Main icons unread messages missed calls voice supportive system upgrade delete turn off low battery full battery 5.
- Page 7 One is on when the monitor has its light on. Turn off: Press and hold the power button for three seconds when Cool Glass One is on. Cool Glass One is off when the monitor is in black. 6.2 Awaken methods 1.
- Page 8 Cool Glass One” 3. Choose “connect to cell phone” on Cool Glass One and then tap “scan QR code” on the App in order to pair and bond Cool Glass One to your cell phone. (Traditional pairing through bluetooth between Cool Glass One and cell phone on App also works.)
- Page 9 2. Open App for connected devices, then it will have the bonding process 7.2 WiFi connection There are two ways to connect to WiFi (Once Cool Glass One is bonded to your cell phone): 1. Choose WiFi connection on App settings: Choose WiFi connection in settings, search for available WiFi, enter password, after connecting successfully, now Cool Glass One can go on the internet.
- Page 10 Cool Glass Once WiFi connection 8. Main Features Instruction 8.1 Software System Update You can use Cool Glass One system update setting and upgrade it to the latest version. 8.2 Voice Command Control Instruction 1. Awaken by saying “Ok, Cool Glass” in primary and secondary interfaces 2.
- Page 11 1. Record video manually: When enter the video recording interface, the default time is 10 seconds. Within this 10 seconds, you can choose to extend recording or stop. After recording, you can use voice command or your hands to play back the video, share on youku, stop and exit. 2.
- Page 12 Cool Glass One is built. 9. How to wear 1. After putting on Cool Glass One, you can adjust the nose pad of the glass to make it more comfortable. 2. After the monitor is on, follow the signs on the monitor to adjust the prism (Be caution of the strength you put on the prism) After finding the right angle, you should see the full and clear image.
- Page 13 The headset has the L/R three-dimensional sound effect. L for long line and R for short line. This is exclusive for Cool Glass One. Use: Plug the headset into the right side of the glass’s bottom. There is a USB port.
- Page 14 2. Use QR code for glass and cell phone pairing. Try another time if the first time doesn’t work. 3. It is better for you to keep your Cool Glass One and cell phone within 10 meters when you are making phone calls, texting messages, live streaming and other features that require bluetooth connection.
- Page 15 We do not recommend you use it in theatre, swimming pool and other private places. Users should follow their local laws to use Cool Glass One. If it is the user who uses Cool Glass One illegally, Alto Tech will not take any responsibilities.
- Page 16 providers. Besides the above, unless you have the permission from contents and service providers, you cannot edit, copy. Paste, upload, mail, transfer, translate, sale, create derivative, develop or other forms of distribution. The third party contents and service will be followed as what they are.
