EBO VLCD-5 Reference Manual

For e-bikes with torque sensor

Table of Contents

Download this manual

EBO VLCD-5 for E-Bikes

with Torque Sensor

Reference Manual

Table of Contents

Need help?

Do you have a question about the VLCD-5 and is the answer not in the manual?

Page 1 EBO VLCD-5 for E-Bikes with Torque Sensor Reference Manual...
Page 2 Functions Display: To speedometer, odometer, pedal assist modes, battery capacity indicator, trip distance, average speed, maximum speed, run time, malfunctions, brake indicator and backlight display. Backlight  Press Power button for I second to turn ON and OFF Battery Capacity Indicator Speedometer, Maximum Speed and Average Speed: The LCD has 2 ways tracking speed depending on the system.
Page 3 Malfunction/Status Display  ERR-02 = Motor Hall Fault/Motor Short Circuit  ERR-03 = Controller Failure  ERR-04 = Turn ON Fault  EER-06 = No Motor Signal  ERR-08 = Low Battery Alarm Access to advanced parameters settings: į Press and POWER buttons simultaneously for 4 seconds to access advanced parameter settings.
Page 4: Technical Specifications
Technical specifications: Technical aspects: Item：VLCD-5 Voltage options: DC24V- 36V- 48V Maximum voltage: 70mA(11V) 32mA(50V) Type Display: 21*4 segment LCD Operating temperature: -20C - +70C Display light: White LED mode, brightness:200cd/m2 Contact information Electric Bike Outfitters, LCC 999 Tejon Street Denver CO, 80211 303-947-5416 Sales@electricbikeoutfitters.com...
